Introduction
Ring Alarm Outdoor Siren is a wireless device for the Ring Alarm system to notify users of
an emergency. The Outdoor Siren can help others quickly identify your home with an
adjustable volume siren and flashing LED lights. The Ring Alarm Base Station is required to
enable Outdoor Siren features and functions within the Ring app.
Installation & Set Up
Ring Alarm Outdoor Siren – Basic Setup & Installation
In-app Setup
1. Ensure your Ring Alarm system is disarmed.
2. In the Ring app, tap Set Up a Device and find the Outdoor Siren in the Security Devices menu.
3. Follow the in-app instructions to complete setup.
Installation
1. Choose a location for installing your Outdoor Siren.
a)
Visibility. Your Outdoor Siren's LED lights and siren should be able to signal anyone passing by your home when your alarm
system is triggered.
b) Close to your power source. If using the Plug-in adapter or hardwiring the Outdoor Siren, it should be close to an outlet or
electrical wiring. If you're using the Solar Panel, make sure the spot gets good sunlight.
c)
Safe access. You should install the Outdoor Siren in a spot where you can access the batteries safely. If you need to use a
ladder, make sure it's on solid ground.
Note:
•
This product can be operated in any Z-Wave
mains operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network.
•
This is a SmartStart enabled product which can be added into a Z-Wave network by scanning the Z-Wave QR Code present
on the product with a controller providing SmartStart inclusion. No further action is required and the SmartStart product will be
added automatically within 10 minutes of being switched on in the network vicinity. This product can also be operated in any
Z-Wave network with other Z-Wave certified devices from other manufacturers.
Date:
TM
network with other Z-Wave certified devices from other manufacturers. All
Ring Alarm Outdoor Siren User Manual
Version: 0.1
Page:
- 1 -
Advertisement
Related Manuals for ring Z-Wave
Summary of Contents for ring Z-Wave
- Page 1 • This is a SmartStart enabled product which can be added into a Z-Wave network by scanning the Z-Wave QR Code present on the product with a controller providing SmartStart inclusion. No further action is required and the SmartStart product will be added automatically within 10 minutes of being switched on in the network vicinity.
- Page 2 1. Initiate add flow for Security Devices in the Ring mobile application – Follow the guided add flow instructions provided in the Ring mobile application. 2. Select add manually and enter the 5-digit DSK pin found on the package of the Ring Alarm Outdoor Siren or the 5-digit DSK pin found under the QR code on the device.
- Page 3 2. Locate the reset button on the back of the device under the battery compartment. 3. With the controller in Remove (Z-Wave Exclusion) mode, use a paper clip or similar object and tap the pinhole button. The device’s red LED turns on solid to indicate the device was removed from the network.
- Page 4 Note: Use this procedure only in the event that the network primary controller is missing or otherwise inoperable. Wake-Up Notification Not applicable. Ring Alarm Outdoor Siren is a Frequently Listening Receiver Slave (FLiRS) device and does not support Wake Up Command Class.
- Page 5 Application Level Retry Base 5 (0x05) 1 (0x01) 60 (0x3C) 0x01 Wait Time Period: Unsigned The number base seconds used in the calculation for sleeping between retry messages. Ring Alarm Outdoor Siren User Manual Date: Version: 0.1 Page: - 5 -...
- Page 6 QRBP switch Threshold: 0 (0x00) 100 (0x64) 0x01 (percentage) (0x0A) Unsigned Once the rechargeable battery has charged to this threshold, device can switch to it if running on D-cells Ring Alarm Outdoor Siren User Manual Date: Version: 0.1 Page: - 6 -...
- Page 7 State: 0x03 AC mains reconnected Notification Report Type: 0x08 Power Management 1 (Lifeline) AC mains power disconnected State: 0x02 AC mains disconnected Notification Report Watchdog Notification 1 (Lifeline) Ring Alarm Outdoor Siren User Manual Date: Version: 0.1 Page: - 7 -...
- Page 8 State Parameter Value = 0x56 Notification Report Type: System 0x09 Software Fault (Ring) 1 (Lifeline) State Value: 0x04 System Software Failure State Parameter Value = 0xAA (Ring Value for Soft Fault) Notification Report Type: System 0x09 Software Fault (SDK) 1 (Lifeline)
- Page 9 1 (Lifeline) State Value: 0x04 System Software Failure State Parameter Value = 0xAD Notification Report Type: Home Security 0x07 Tampered 1 (Lifeline) State: Tampering Product Covering Removed 0x03 Ring Alarm Outdoor Siren User Manual Date: Version: 0.1 Page: - 9 -...
- Page 10 Type: Home Security 0x07 Tamper Cleared 1 (Lifeline) State: Previous Events Cleared 0x00 Event Parameter: 0x03 Notification Report Comm Test Button Pressed Type: System 0x09 1 (Lifeline) Event: Heartbeat 0x05 Ring Alarm Outdoor Siren User Manual Date: Version: 0.1 Page: - 10 -...
- Page 11 1523 26th St. Santa Monica, CA 90404 Supplier’s Declaration of Conformity – Compliance Information Statement Unique Identifier: Ring Alarm Outdoor Siren Responsible Party and Party issuing Supplier’s Declaration of Conformity Ring LLC dba Ring 1523 26th Street Santa Monica, CA 90404 U.S.A.
- Page 12 ATTENTION : Danger d’explosion si la pile n’est pas remplacée correctement. Remplacez la pile uniquement par une pile identique ou par une pile du même type que celle recommandée par le fabricant. Suivez les instructions du fabricant pour jeter les piles usées. Ring Alarm Outdoor Siren User Manual Date: Version: 0.1...
- Page 13 Ring Alarm Outdoor Siren User Manual Date: Version: 0.1 Page: - 13 -...
