Internal Connectors

8
12
12
12
12
1) ATX_12V/ATX_12V1
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3/4
5) SYS_FAN5/6/7/8_PUMP
6) CPU_OPT
7) EC_TEMP1/EC_TEMP2
8) LED_CPU
9) LED_C1/LED_C2
10) D_LED1/D_LED2
11) SATA3 0/1/2/3/4/5
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
4 1 6
14 10 9 18 17 7 4 5 16
12)
13)
14)
15)
16)
17)
18)
19)
20)
21)
22)
- 25 -
3 5
9
10
19
2
5
4
7
15
20
11
16
22
21 13
M2A_CPU/M2B_SB/M2C_SB/M2D_SB
F_PANEL
F_AUDIO
F_U32C
F_U32_1/F_U32_2
F_USB1/F_USB2
TPM
NOISE SENSOR
THB_C
BAT
CLR_CMOS
Hardware Installation
