  • Page 2 SQUARELED NPQ818 IP65 18x8W RGBW USER MANUAL...

  • Page 3: Table Of Contents

    Catalogue Summary ........................1 Safety Instruction ......................1 Outside size picture ......................2 Main function ........................3 DMX control function ..................... 3 Display operation instruction ..................5 Menu instruction ......................5 Operating control instruction ..................7 XLR connection instruction .................... 8 Connecting picture ......................

  • Page 4: Safety Instruction

    1. Summary  Summary  Thank you for purchasing our NPQ818. Please read these instructions carefully before begin and operate the fixtures according to these instructions to avoid any possible damages and accidents causes by misusage  Product introduction casting aluminum housing The light uses , designed in a fashion of hydrodynamic form.

  • Page 5: Outside Size Picture

    good condition and appear no damage. ●This light is designed for indoor use; working temperature is lower than 40 degree. ●The fixtures maybe mounted in any position provided there is adequate room for ventilation. Make sure there are no inflammable and explosive items (ornaments) in 0.5 meters away. ●Yellow / green cabling earthling safety;...

  • Page 6: Dmx Control Function

     each color of LED with 16666 dimming. RGB can make over 16.7 million colors, adding W can achieve many effects.  Liner dimming from 0-100%, strobe, gradual change, jumping change etc effects  Touch Buttons, Unusual feeling to you. ...

  • Page 7: Display Operation Instruction

     DMX Channel（9CH） Channel DMX value Control Function Priority 0-255 General dimming 0——100% 0-255 red dimming0——100% 0-255 Green dimming0——100% 0-255 blue dimming0——100% 0-255 white dimming 0——100% 0-10 Close Strobe 11-255 Adjust Strobe Speed（1-20Hz） 0-14 Dimming 15-29 30-44 45-59 60-74 75-89 90-104 105-119 120-134...

  • Page 8: Menu Instruction

     MENU : access the menu or return to a previous menu option  ENTER: select the current menu option  UP: menu selection or parameter increments  DOWN: menu selection or parameters decrease 7. Menu Instruction Addr d001-d512 DMX mode Slave receiving SLAU SLAu...
  • Page 9 r000-r255 Red dimming rL-- Green dimming GL-- G000-G255 Blue dimming bL-- b000-b255 White dimming UL-- U000-U255 Display on/off LED- on/Off Operating instruction: MENU（UP/DOWN）+ENTER+UP/DOWN）+ENTER Remark: Exp: Select the DMX mode, Here are the operation details:  Press the MENU, go back to the initial setting ...

  • Page 10: Operating Control Instruction

     Press UP/DOWN，display ”CHnd”  Press ENTER to change the content, the display will glinting at this moment  Press UP/DOWN to select the DMX channels that you need, 5CH、6CH、9CH and so on  Press ENTER select and store the current menu options. DMX mode will be stored automatically and the screen will stop glinting.

  • Page 11: Connecting Picture

     XLR cable： The standard connection way of the XLR is: one end connects to the male plug, and the other connects to the female. As below: pin 1: ground, pin 2: negative signal, pin 3: positive signal Noted：In order to avoid failures and interference signal transmission，we connect a resistance120Ω...

  • Page 12: Trouble Shooting

    11. Trouble Shooting Problem Checking Way  Check the power source plug is in normal or not  Check the switch of the lights is off or on Can not turn on the  light Check the fuse if in normal ...
  • Page 13  When connect to the electricity，did the led flash one time? If so，the Display not bright power source is normal; If not，please check if the switch and the transformer has power out  Check if the power input of the IC board is normal ...

  • Page 14: Technical Specification

    12. Technical Specification ● Input voltage: AC 100V-264V/47-63HZ ● Output voltage:DC24V ● Consume:144W ● Lamp Type: 4IN1 LED ● Lamp Spec:4-in-1（18PCS） ● Life span: 50000~100000hours ● PWM Dimmer：600HZ(16666 grades) ● Control Signal：DMX512, , auto run ● Channel：5CH,6CH,9CH ● Color effect：RGBW mixing ●...
  • Page 15 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
