Summary of Contents for Squareled Storm1000

  • Page 2: Getting Started

    Manual | Storm1000 1. GETTING STARTED Unpacking • 1 x Storm1000 RGBW LED Strobe • 1 x Base Plate • A Sweet Safety Cable, An Eyebolt & Set of Mounting Brackets • An Ever-So-Handy Power Cord • This Lovely User Manual Carefully check the shipping carton for damage that may have occurred during shipping.

  • Page 3: Safety Instructions

    Manual | Storm1000 SAFETY INSTRUCTIONS   Please read these instructions carefully they include the important information about the installation usage and maintenance of this products   Please note: Certain people with epilepsy and photosensitivity may suffer a seizure if exposed to flashing or strobe lighting.

  • Page 4: Main Features

    Manual | Storm1000 2. MEET Storm1000 RGBW LED STROBE FIXTURE MAIN FEATURES • Super bright output via 1260 0.8w RGBW LEDs • Intense built-in strobe programs + random strobe • 2-segment pixel modes can safely be used as wash (max 40% brightness) •...
  • Page 5 Green Segment Intensity (0-100%) Green1 Intensity (0-100%) Blue Segment Intensity (0-100%) Blue1 Intensity (0-100%) White Segment Intensity (0-100%) White1 Intensity (0-100%) Red2 Intensity (0-100%) Green2 Intensity (0-100%) Blue2 Intensity (0-100%) White2 Intensity (0-100%) Figure 1: The Storm1000 RGBW Pin-Up Picture...
  • Page 6 3. SETUP Fuse Replacement CAUTION! The Storm1000 RGBW utilizes a high-output switch-mode power supply with an inter- nal fuse. Under normal operating conditions, the fuse should not require replacement. The fuse is field replaceable,however it is an advanced procedure suited to qualified individuals. Should your...

  • Page 7: Data/Dmx Cabling

    Manual | Storm1000 Connecting A Bunch of Storm1000 RGBW Fixtures: Follow the guide below to properly link fixtures. Power the first fixture in the chain with a standard cable (provided with fixture). Then jump each subsequent fixture with a properly rated jumper cable.
  • Page 8 Manual | Storm1000 CAUTION: Do not allow contact between the common and the fixture’s chassis ground. Grounding the common can cause a ground loop, and your fixture may perform erratically. Test cables with an ohm meter to verify correct polarity and to make sure the pins are not grounded or shorted to the shield or each other.

  • Page 9: Fixture Linking (Master/Slave Mode)

    Manual | Storm1000 Fixture Linking (Master/Slave Mode) 1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the first fixture. 2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin connector to the input connector of the next fixture consisting of a (male) 3 pin connector.

  • Page 10: Operating Adjustments

    The Control Panel All the goodies and different modes possible with the Storm1000 RGBW are accessed by using the control panel on the front of the fixture. There are 4 control buttons below the LCD display which allow you to navi- gate through the various control panel menus.
  • Page 11 Manual | Storm1000 Menu Sub-menu Address Set DMX Address 001-512 Auto Mode 1 Auto Mode 1 Mode 2 Auto Mode 2 Mode 3 Auto Mode 3 Auto Mode 4 Mode 4 Auto Mode 5 Mode 5 Mode 6 Auto Mode 6...

  • Page 12: Dmx Mode

    Manual | Storm1000 DMX Mode Allows the unit to be controlled by any universal DMX controller. Set the Starting DMX Address: The default mode for the fixture is DMX, so the first menu item that you can edit is the starting DMX address.

  • Page 13: Additional Features

    Manual | Storm1000 Additional Features: Never thought you would ever see so many nifty neato features in a strobe light did you? Temperature: IMPORTANT - Brightness will decrease when the LED temperature rises over 55ºC. If a temperature of +70ºC is reached, the overheat protection sensor will activate, initiating blackout until a safe temperature is reached.

  • Page 14: Dmx Values In-Depth (16-Channel Mode)

    Manual | Storm1000 DMX Values In-Depth (16-Channel Mode) Value Function 000 <--> 255 Master Dimmer (0-100%) Red segment Intensity (0-100%) 000 <--> 255 Green segment Intensity (0-100%) 000 <--> 255 000 <--> 255 Blue segment Intensity (0-100%) 000 <--> 255 White segment Intensity(0-100%) 000 <-->...

  • Page 15: Dmx Values In-Depth (7-Channel Mode)

    Manual | Storm1000 DMX Values In-Depth (7-Channel Mode) Menu Sub-menu Function Master Dimmer (0-100%) 000 <--> 255 Red segment Intensity (0-100%) 000 <--> 255 Green segment Intensity (0-100%) 000 <--> 255 000 <--> 255 Blue segment Intensity (0-100%) 000 <--> 255 White segment Intensity(0-100%) 000 <-->...

  • Page 16: Troubleshooting

    Manual | Storm1000 DMX Values In-Depth (4-Channel Pixel Mode) Menu Sub-menu Function 000 <--> 021 No Function 022 <--> 255 Red/Segment Intensity (0% <--> 100%) 000 <--> 021 No Function 022 <--> 255 Green/Segment Intensity (0% <--> 100%) 000 <--> 021 No Function 022 <-->...

  • Page 17: Tech Specs

    Manual | Storm1000 5. APPENDIX Your fixture will require regular cleaning to prevent a build up of dust and smoke debris on the optics and housing. After disconnection of power, wipe down the fixture with a damp cloth. Never use alcohol or solvents as this may damage the finish.
  • Page 18 Manual | Storm1000 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
