CAPACITANCE
Range
50.00nF, 500.0nF
5.000µF
50.00µF
500.0µF
9999µF
*Accuracies with film capacitor or better
FREQUENCY, AC LINE LEVEL
Range
Accuracy
Sensitivity
FREQUENCY, LOGIC LEVEL
Range
Accuracy
Sensitivity

% DUTY CYCLE

Range
Accuracy
Input Frequency
dBm
Range
Accuracy
Reference Impedance
*Input impedance 10MΩ, 30pF nominal
Accuracy*
0.8% + 3d
1.0% + 3d
2.0% + 3d
3.5% + 5d
5.0% + 5d
5.0000Hz to 200.000kHz
0.002% + 4d
500mV range
5V range
50V range
500V range
1000V range
5.0000Hz to 2.00000MHz
0.002% + 4d
2.5Vp square wave
0.10% to 99.99%
3d/kHz + 2d
5Hz-500kHz, 5V logic family
-11.76dBm to 54.25dBm (@ 600Ω)
0.25dB + 2d (@40Hz to 20kHz)
Selectable: 4, 8, 16, 32, 50, 75,93, 110, 125,
135, 150, 200, 250, 300, 500, 600, 800, 900,
1000, 1200Ω
7
0.1V min
1V min
10V min
100V min
900V min
