- Page 1 USER MANUAL WELD ON POINT COMPACT CODE: 103901, 103902, 103904, 103906, 103909 1300 100 120 www.austlift.com.au Australian Lifting Centre Pty Ltd...
- Page 2 Weld on Point Compact (Type WPC) Austlift WPC type weld on lifting points can be welded on any carbon steel surface as a lifting point, or to be used as a be used as an anchor point for load restraint applications.
- Page 3 DIMENSIONS (mm) CODE (kg) 103901 40.5 70.5 103902 0.48 48.5 81.5 103904 0.69 42.5 103906 104.5 103909 67.5 124.5 Welding Instructions Warning Under no circumstances should you exceed the work load limit of this product. WLL reduction must be taken into account when using in a cold or hot environment.
- Page 4 1560 1560 WPC-9-8 1780 1780 General To properly install and weld an Austlift weld-on lifting point it requires a competent person who has experience in the lifting or load restraint industry and in the welding job. Positioning • This product shall be in the correct position to withstand all angles of the load strain.
- Page 5 Any welding of this product should be carried out by a low alloy or non-alloy steel. Electrodes must be free from any moisture and wire free from rust before any kind of welding is to be carried out. Recommended welding electrode; AS/NZS 1553 or equivalent. www.austlift.com.au...
- Page 6 • All bare and unwelded areas should be painted to avoid rust. • All moving parts should be well lubricated after welding. • MIG welding has less penetration than others and it is not recommended for welding G80 components. www.austlift.com.au...
- Page 7 Triple weld runs may have to be conducted in order to reach minimum weld fillet area (A). Inspection • Check for bends, nicks, wear, stretching or elongation of the components. • Check for any signs of corrosion. • Check for any scoring or cracks on all welds and components. •...
- Page 8 Lifting your business to a higer level. 1300 100 120...
