- Page 1 Installation & Owner’s Manual Model 438K 25 Gallon Electronic Preservative Applicators Forage Harvester 438K-21-INST-Imp&Metric 04/21...
- Page 2 European Parliment and the Council of 17 May 2006 and other applicable European Directives including Directive 2004/108/EC on the Electromagnetic compatability. The application of preservatives for hay Harvest Tec system will be turned on after being installed on a farm press has been declard in conformity with the Machinery Directive.
-
Page 3: Table Of Contents
Resulting in the warranty being void. For your convenience we have included a parts break down for the model 438K applicator. If something goes wrong bring this manual into the dealer so they can order the correct parts for you. Ordering the correct part number is very important. -
Page 4: Installation Of Applicator
Installation of Applicator Installation of Mounting Brackets, Tank, and Drain / Fill Line Locate the frame mount stiffener brackets (001-4704KS) and the left and right mounting brackets (001-4704KE & 001-4704KF) as seen in figure 1. Fasten one 001-4704KS to each the left and right mounting brackets at point A using two 3/8”... -
Page 5: Installation Of Mounting Brackets, Tank, And Drain / Fill Line
Installation of Mounting Brackets, Tank, and Drain / Fill Line (continued) Locate the tank saddle U-bracket (001-4704KB) and line it up over the baler tongue so it matches up with the tank saddle legs (001-4704KE & 001-4704KF) at point C and D as shown in figure 3. Fasten 001-4704KB to the left saddle leg (001-4704KE) at point C using two 1/2”... - Page 6 Installation of Mounting Brackets, Tank, and Drain / Fill Line (continued) If your baler has a sidewind jack, complete the next steps. If your baler does not have a sidewind jack, skip to the tank installation on page 7. Locate the jack bracket assembly (001-4704KM) and fasten it to the existing jack mounted on the baler shown at point G in figure 7 using two 1/2”...
- Page 7 Installation of Mounting Brackets, Tank, and Drain / Fill Line (continued) Locate the mounting bracket (001-4704KR) and fasten it to the outside of the U-Bracket (001-4704KB) shown at point J in figure 10 using 3/8” x 1 ¼” bolts, locks, flats, and nuts. Drill a 3/8” hole in the baler tongue and fasten 001-4704KR to the baler tongue using a 3/8”...
- Page 8 Installation of Mounting Brackets, Tank, and Drain / Fill Line (continued) Locate the drain/fill kit and drill two 9/32” holes in the U-bracket (001-4704KB) and fasten the drain/fill kit with the supplied hardware in the drain/fill kit (5/16” self-tapping bolts). Figure 12 Mount Pump Plate Assembly Use four 3/8”...
- Page 9 Installation of Gauge and Hose Manifold Mount the gauge to the tank frame or the frame of the baler. If you mount the gauge to the baler, make sure it does not interfere with any of the baler’s operation, or be in an area where it could be tripped over when servicing the baler.
-
Page 10: Installation Of Plumbing
Screw the 003-EL3412 (3/4” to 1/2” elbow) into the bottom of the tank. Then route the 002- 9001(1/2” hose) from bottom of the tank to the ball valve. Secure with hose clamps. B. Outlet round baler with 438K-SO Run hose from the pump outlet to the gauge. The gauge is assembled with two straight fittings;... -
Page 11: Operation
Operation The 438K applicator is very simple to operate. After installing the applicator, fill the tank with 5 gallons of water. With control box connected to the applicator and the power cord hooked to the 12-volt battery we can start the test. First flip on the toggle switch. You might hear the buzzing of the motor. Turn the dial on the control box until the gauge starts to climb. -
Page 12: Calibration
Harvest Tec applicators come with the red, green, and blue sets of tips. If your chemical requires rates other than what these tips deliver you will need to purchase... -
Page 13: Selecting Tips And Setting Pressure
Calibration (continued) CALIBRATION REMINDERS *Watch the pressure gauge as the setting will vary with tractor’s electrical output, temperature and other factors. *Check your application rate by measuring product used against actual tons baled. REMEMBER, ONLY YOU CAN CONTROL HOW MUCH PRODUCT IS APPLIED AND THAT WILL DETERMINE IF YOUR HAY WILL KEEP!!! SELECTING TIPS AND SETTING PRESSURE Once you have determined your tons per hour and the amount of chemical needed... - Page 14 GENERAL CALIBRATION CHART IN POUNDS PER HOUR Use the following chart for all applications that require pounds measurements. POUNDS PER HOUR WITH THREE NOZZLES INCLUDED IN KIT YELLOW GREEN BLUE BLACK 650067 XR11001 XR110015 XR11002 XR11004 CENTER 650033 650050 6501 6502 6503 OUTSIDE...
-
Page 15: Routing Maintenance
Clean the tip strainers and main strainer every 10 hours of operation or more frequently if required. Depending on the product being used, the system may need to be flushed with water at a regular interval (consult with manufacturer of the chemical.) If Harvest Tec product is being used, flushing is not necessary. -
Page 16: Trouble Shooting Checks
TROUBLE SHOOTING CHECKS PROBLEM POSSIBLE CAUSE SOLUTION Pump will not run. 1. Circuit breaker tripped 1. Check for short, low voltage, and on electronic unit. reset breaker. 2. Pump locked up. 2. Clean or rebuild pump if motor is 3. Damaged wire. 3. -
Page 17: Base Kit
Model 438K Base Kit Description Part # Description Part # Tank Bracket (V2) 001-4704KA Elbow 003-EL3434 U-Bracket (V2) 001-4704KB Street Elbow 003-SE34 Frame Mount Stiffener Bracket (V1) 001-4704KS Tank Fitting 005-9100 Mounting Bracket LH (V2) 001-4704KE 20 Gallon Tank 005-4705T... - Page 18 002-4315 003-TT14 Street elbow 003-SE12 Straight fitting 003-A1412 Nipple fitting 003-M1212 Pump Bracket 001-4704KL MODEL 438K DRAIN/FILL KIT, & CONTROL BOX Ref Description Part # Ref Description Part # Jiffy clip-large 008-9009 Female coupler 002-2204A Jiffy clip-small 008-9010 Straight fitting...
- Page 19 438K-SO INSTALLATION KIT Ref Description Part # Description Part # Shield bracket 001-4704E2 Tip Kit (Complete) 030-9002 Spray shield 001-4703GK Plastic Box 008-9000 Hose 002-9001 Red Cap 004-1207B 003-TT14 Outside Tip (Red Set) 004-650050-SS Straight fitting 003-A1412 Inside Tip (Red Set)
- Page 20 Warranty and Liability Agreement Harvest Tec, Inc. will repair or replace components that are found to be defective within 12 months from the date of manufacture. Under no circumstances does this warranty cover any components which in the opinion of Harvest Tec, Inc. have been subjected to negligent use, misuse, alteration, accident, or if repairs have been made with parts other than those manufactured and obtainable from Harvest Tec, Inc.
