Self-Contained Siren
or Siren/Strobe
Installation Manual
Model
SH-816S-BQ
SH-816S-SQ/x*
*Replace "x" with the first letter of the lens color, amber, blue, clear, or red.
The ENFORCER Siren/Strobe is a multi-purpose device: siren, speaker, and (SH-816S-SQ only)
an LED strobe. It can serve as a regular siren, but also has an audio input that can be used to play
audio or broadcast messages. Audio input will override the siren for the duration of the broadcast.
The SH-816S-SQ strobe light is available with amber, blue, clear, or red lenses.
• 9~15 VDC and low current draw
• 120dB Warble-tone siren
• 25W Speaker for audio or broadcast system input (broadcast will interrupt the siren)
• Built-in tamper alarm output
• Weatherproof for outdoor/indoor use, IP65
• Mount directly to wall or to most common back boxes
In addition to the above, SH-816S-SQ adds:
• Bright LED strobe light
• Strobe can be triggered separately from siren
• Strobe available in amber, blue, clear, or red
Product
Siren
Siren with Strobe
Mount
Surface or back box (single-gang, double-gang, or C-type)
Surface or back box (single-gang, double-gang, or C-type)
SH-816S-SQ/R shown
Advertisement
Related Manuals for SECO-LARM ENFORCER SH-816S-SQ Series
Summary of Contents for SECO-LARM ENFORCER SH-816S-SQ Series
- Page 1 Self-Contained Siren or Siren/Strobe Installation Manual SH-816S-SQ/R shown Model Product Mount SH-816S-BQ Siren Surface or back box (single-gang, double-gang, or C-type) SH-816S-SQ/x* Siren with Strobe Surface or back box (single-gang, double-gang, or C-type) *Replace "x" with the first letter of the lens color, amber, blue, clear, or red. The ENFORCER Siren/Strobe is a multi-purpose device: siren, speaker, and (SH-816S-SQ only) an LED strobe.
- Page 2 1-lb 13-oz (812g) 2-lb 2-oz (957g) *Replace "x" with the first letter of the desired LED lens color – amber, blue, clear, or red. Overview " (155mm) " (115mm) Siren " (126mm) " (155mm) " (115mm) Siren/Strobe 7" (178mm) SECO-LARM U.S.A., Inc.
- Page 3 AUDIO (+) STROBE (+) engaged (see Fig. 1). AUDIO (–) SIREN (+) TAMPER 8. Attach the main unit to the base using TAMPER P.A. (+) the two screws removed in step 2. SECO-LARM U.S.A., Inc.
- Page 4 SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
