- Page 1 {InstallationInstructs}{Production}{HealthImaging} Publication No. 9B8948 15JUN98 Supersedes 9B8948 July 1997 HEALTH IMAGING INSTALLATION INSTRUCTIONS for the Kodak X-Omat 1000, 1000A and 1000J PROCESSOR © Eastman Kodak Company, 1999...
-
Page 2: Table Of Contents
Eastman Kodak Company prior to publication. No patent license is granted by this information. Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from any use of this information, even if loss or damage is caused by Kodak’s negligence or other fault. -
Page 3: General Information
General Information Section 1: General Information Electrostatic Discharge Overview ESD, electrostatic discharge, can damage sensitive electronic parts and assemblies. You cannot detect a static charge of 3,500 Volts, but a static charge of only 30 Volts can damage some electronic components. -
Page 4: Unpacking The Processor
INSTALLATION INSTRUCTIONS Section 2: Unpacking the PROCESSOR The Processor and accessories are packed in 2 cartons. Before unpacking, check the cartons for damage. If the cartons are damaged contact the Dealer before unpacking the cartons. Important When removing packing material, be careful not to cut through the wrapping material which can cause damage to components. -
Page 5: Components
Components Section 3: Components Components of the processing systems are identified by different color LABELS: • Developer components have red LABELS. • Fixer components have blue LABELS. • Wash components either have white LABELS, or they are unlabeled. WASH SECTION DRYER FIXER SECTION FEED TRAY... -
Page 6: Processor Frequency
INSTALLATION INSTRUCTIONS Section 4: PROCESSOR Frequency Changing the PROCESSOR Frequency Check the frequency of the main power at the site. The PROCESSOR must be set for the same frequency as the main power. The PROCESSOR has two HELICAL GEARS: • The 50 Hz HELICAL GEAR is white. •... - Page 7 PROCESSOR Frequency SLOT CONTROL BOARD CONTROL SWITCHES BOX COVER H164_0003HCB H164_0003HC Possible damage from electrostatic discharge. [10] Remove the 4 SCREWS and the CONTROL BOX COVER for access to the SWITCHES inside. [11] Place the TAB on the CONTROL BOX COVER in the SLOT on the PROCESSOR. [12] Set the PROCESSOR to the correct frequency: (a) Move SW02-1 to the “ON”...
-
Page 8: Processor Voltage
INSTALLATION INSTRUCTIONS Section 5: PROCESSOR Voltage Checking and setting the PROCESSOR voltage If the PROCESSOR is a 1000A or 1000J, advance to Installing the PROCESSOR on Page If the PROCESSOR is a 1000, you must check the internal voltage setup and change the voltage setup if necessary: [1] Open the PROCESSOR: 2 SCREWS (a) Remove the 2 SCREWS on top of the feed... - Page 9 PROCESSOR Voltage WIRE 6 SCREW ELECTRICAL COVER TERMINALS 5, 6, and 7 H164_0077HCA H164_0077HC [2] Remove the ELECTRICAL COVER. [3] Determine the voltage of the power source at the site. It must be 220, 230 or 240 V AC. [4] Locate TERMINAL BLOCK TB51 inside the PROCESSOR. [5] Use the following table to select the correct voltage setup for the PROCESSOR.
-
Page 10: Installing The Processor
INSTALLATION INSTRUCTIONS Section 6: Installing the PROCESSOR Connecting the Plumbing Warning • Drains must be made of chemically resistant, non-corrosive material. Use PVC or equivalent. • The Drain must have a minimum diameter of 7.6 cm (3 in.) and be free of obstruction. •... - Page 11 Installing the PROCESSOR HOSE CLAMP WATER WATER SUPPLY OVERFLOW HOSE FITTING WATER DRAIN FIXER HOSE/ORIFICE OVERFLOW HOSE DEVELOPER OVERFLOW HOSE HOSE CLAMP HOSE FIXER CLAMP DRAIN HOSE DEVELOPER DRAIN HOSE FIXER TUBE/HOSE/FILTER ASSEMBLY DEVELOPER TUBE/HOSE/FILTER ASSEMBLY DEVELOPER WASH WATER FIXER DRAIN DEVELOPER FIXER DRAIN...
-
Page 12: Installing The Feed Tray
INSTALLATION INSTRUCTIONS Installing the FEED TRAY GROMMET 4 NUTS Possible damage from electrostatic discharge. FILM SENSOR FEED TRAY CABLE [1] Remove the 4 NUTS and WASHERS from the CONTROL BOX COVER. [2] Insert the FILM SENSOR CABLE through the hole in the top of the CONTROL BOX. [3] Press the GROMMET on the CABLE into the hole on the CONTROL BOX. -
Page 13: Function Checkout
Installing the PROCESSOR [3] Remove the tape from the SCREENS in the bottom of the DEVELOPER and FIXER TANKS. [4] Check the RACKS for squareness. Use the Adjustments and Replacements Section of the SERVICE MANUAL if necessary. [5] Install all RackS and CROSSOVERS. Note Check that the clear EVAPORATION COVER is correctly installed and snapped into position on the DEVELOPER RACK. - Page 14 INSTALLATION INSTRUCTIONS [5] Check the flow of developer and fixer solution in the DEVELOPER and FIXER TANKS. [6] If there is solution flow in both TANKS, advance to Step 8. [7] If there is no solution flow in a TANK, there might be air in the RECIRCULATION PUMP. Use the following steps to correct the problem: (a) With the PROCESSOR energized, open the DRAIN VALVE for the TANK to release some of the water from the TANK.
-
Page 15: Setting The Developer Temperature
Installing the PROCESSOR Setting the Developer Temperature Possible damage from electrostatic discharge. [1] To set the developer temperature between ° ° ° ° 32.0 C and 35.0 C (89.6 F and 95.0 (a) Move SW05-1 to the “OFF” position. (b) Adjust SW03 using the following table: °... -
Page 16: Setting The Developer And Fixer Replenishment Rates
INSTALLATION INSTRUCTIONS Setting the Developer and Fixer Replenishment Rates Possible damage from electrostatic discharge. [1] Use the following table to select the correct replenishment rate: (a) Adjust SW06 to set the developer replenishment rate. (b) Adjust SW07 to set the fixer replenishment rate. -
Page 17: Setting The Processor To The "Regular" Replenishment Mode
Installing the PROCESSOR Setting the Processor to the “Regular” Replenishment Mode Possible damage from electrostatic discharge. [1] Move SW05-3 to the “OFF” position. [2] Install the CONTROL BOX COVER. SW05 SW07 SW06 H164_0039AC Setting the Processor to the “Flooded” Replenishment Mode Possible damage from electrostatic discharge. -
Page 18: Setting The Dryer Temperature
INSTALLATION INSTRUCTIONS Setting the DRYER Temperature Dryer Temperature High H164_0037AC [1] Use the following table to select and set the DRYER temperature. Count the increments between the “LOW” and “HIGH” positions. DRYER Temperature Positio Position Temperature Temperature ° ° ° °... - Page 19 Installing the PROCESSOR Publication History Print Date Pub. No. ECO No. Affected Pages File Name Notes July 1997 9B8948 2504-470 All Pages ii3482_1_22jul97.doc First printing. June 1998 9B8948 All Pages ii3482_1_15jun98.doc Second printing. 9B8948 – 15JUN98...
- Page 20 Kodak and X-Omat are trademarks. Printed in U.S.A. • ii3482_1.fm EASTMAN KODAK COMPANY HEALTH IMAGING Rochester, NY 14650...
