INTRODUCTION
This server allows portable dispensing of up to 4-gallons of iced tea. It should be placed either on a Bunn Iced
Tea brewer or on a PTD 4 stand.
CLEANING
CAUTION - CLEAN AND SANITIZE YOUR ICED TEA DISPENSER DAILY
1. Twist the faucet wing nut(12) in a clockwise direction and remove the faucet(5) from the dispenser.
2. Thoroughly clean the entire inside surface of the dispenser and the faucet shank(13) using the #00674.0000
brush using a mild detergent and water solution. Rinse the dispenser and shank with warm water.
3. Disassemble the faucet(5). The faucet cleaning procedure requires a 3-compartment sink. Thoroughly wash
all faucet parts in a mild detergent and water solution in the first sink. Rinse the parts in hot water in the second
sink. Sanitize the parts for one minute in 75 warm chlorine solution (at least 50 ppm) in the third sink.
Reassemble the faucet and attach it to the dispenser.
4. Sanitize all exposed surfaces of the dispenser with a 75 warm chlorine solution (at least 100 ppm). Empty
the dispenser and thoroughly rinse everything.
5. Wash the entire outside surface of the dispenser with a clean damp cloth.
CAUTION - DO NOT KEEP BREWED ICED TEA OVERNIGHT.
10291.0000 6/03 ©1988 Bunn-O-Matic
USE & CARE INSTRUCTIONS
BUNN-O-MATIC CORPORATION
POST OFFICE BOX 3227
SPRINGFIELD, ILLINOIS 62708-3227
PHONE: (217) 529-6601 FAX: (217) 529-6644
PTD 4
www.bunnomatic.com
