OWNER' S MANUAL
SUBMERSIBLE PLASTIC
SUMP PUMPS
MANUAL DEL USUARIO
BOMBAS SUMERGIBLES
PARA SUMIDEROS
176958
176953,
176952
Chicago, IL 60631
Phone: 1-800-628-9439
www.masterplumberpump.com
2018 TRU973 (07/13/18)
©
ENGLISH: PAGES 2-7
Installation/Operation/Parts
For further operating, installation, or
maintenance assistance:
Call 800-628-9439
ESPAÑOL: PÁGINAS 8-13
Instalación/Operación/Piezas
Para mayor información sobre el
funcionamiento, instalación o mantenimiento
de la bomba: Llame al 800-628-9439
Model
176958,
176953, 176952

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Master Plumber 176958 and is the answer not in the manual?

Questions and answers

Joel Cyr
March 23, 2025

Please translate the date code on my sump pump. It is 033K17F

Summary of Contents for Pentair Master Plumber 176958

  • Page 1 Model 176958, OWNER’ S MANUAL 176953, 176952 SUBMERSIBLE PLASTIC SUMP PUMPS MANUAL DEL USUARIO BOMBAS SUMERGIBLES PARA SUMIDEROS ENGLISH: PAGES 2-7 Installation/Operation/Parts For further operating, installation, or maintenance assistance: Call 800-628-9439 ESPAÑOL: PÁGINAS 8-13 176958 Instalación/Operación/Piezas Para mayor información sobre el funcionamiento, instalación o mantenimiento de la bomba: Llame al 800-628-9439 176953,...
  • Page 2 Safety Important Safety Instructions 10. Personal Safety: a. Wear safety glasses at all times when working with SAVE THESE INSTRUCTIONS - This manual contains pumps. important instructions that should be followed during b. Keep work area clean, uncluttered and properly installation, operation, and maintenance of the product.
  • Page 3: Float Switch Installation

    Specifications . Installation Specifications This pump is designed for use in a residential sump only. Only pump water with this pump. Power supply required........115V, 60 HZ. NOTICE This unit is not designed as a waterfall or fountain Liquid Temp. Range......32°F to 70°F(0°-21°C) pump, or for applications involving salt water or brine! Individual Branch Circuit Required (min.).....15 Amps Use with waterfalls, fountains, salt water or brine will void...
  • Page 4: Operation

    Operation 4. Install discharge plumbing. Use rigid plastic pipe and wrap threads with PTFE pipe thread sealant tape. Hand tighten pipe into pump plus 1-1/2 turns. Risk of flooding. Can cause personal injury and/or property damage. If a flexible discharge hose is used, make sure pump is secured in sump to prevent movement.
  • Page 5: Troubleshooting

    Operation ∙ Troubleshooting Operation automatically and restart motor. If protector trips repeatedly, pump should be removed and checked. Low voltage, long extension cords, clogged impeller, Risk of electric shock. Can shock, burn or very low head or lift, or a plugged or frozen discharge kill.
  • Page 6: Repair Parts

    Repair Parts PLASTIC SERIES Description 176958 176953 176952 Power Cord Assembly PS117-54-TSU Tethered Float Assembly FP18-15BD Vertical Float Switch Assembly FPS17-66 Screw #8-32 x 7/8” • Motor Upper Volute PS1-325 PS1-327 Screw #8-32 x 1/2” • Impeller PS5-286 Lower Volute PS1-326 Screw #8 x 5/8”...
  • Page 7: Warranty

    Warranty Retain Original Receipt For Warranty Eligibility Limited Warranty This Limited Warranty is effective June 1, 2011 and replaces all undated warranties and warranties dated before June 1, 2011. MASTER PLUMBER warrants to the original consumer purchaser (“Purchaser” or “You”) that its products are free from defects in material and workmanship for a period of twenty-four (24) months from the date of the original consumer purchase.
  • Page 8 Especificaciones y Seguridad 10. Seguridad Personal: Instrucciones importantes a. Use lentes protectores en todo momento cuando de seguridad trabaje en la bomba. b. Mantenga el lugar de trabajo limpio, despejado y Guarde estas instrucciones - Este manual contiene debidamente iluminado - guarde todas herramientas y instrucciones importantes que se deben seguir durante la el equipo que no se use.
  • Page 9 Instalación prematuramente. Especificaciones Esta bomba ha sido diseñada sólo para uso en sumideros Fuente de alimentación ........115 V, 60 Hz domésticos. Bombee solamente agua con esta bomba. Gama de la Temperatura AVISO Este aparato no está diseñado como bomba de cas- del Líquido ..........0˚-21˚C (32˚F a 70F˚) cada o fuente, ni para aplicaciones con agua salada o de mar.
  • Page 10: Instalación

    Instalación AVISO No use obturador de juntas de tubería en las tuberías de plástico. El obturador de juntas de tubería puede dañar el plástico. 4. Instale la tubería de descarga. Use tuberías de plástico rígido y envuelva las roscas con cinta sellante de PTFE para roscas de tubería.
  • Page 11 Funcionamiento ∙ Solución de problemas Funcionamiento ponerse en marcha. Si el protector se desengancha en forma continua, la bomba debe ser sacada y revisada para verificar cual es el problema. Baja Risque de secousses électriques. Pouvant tensión, cables de alargue largos, impulsor causer des brúlures, voire la mort.
  • Page 12 Refacciones Serie de plastico Ref. Descripción Cant. 176958 176953 176952 Tornillo de abrazadera de cordon PS117-54-TSU Unidad del interruptor de flotador anclado FP18-15BD Unidad del interruptor de flotador vertical FPS17-66 Tornillo # 8-32 x 7/8 “ • Motor Voluta (superior) PS1-325 PS1-327 Tornillo # 8-32 x 1/2 “...
  • Page 13 Garantia Retener el recibo original a fin de determinar la elegibilidad para la garantía Garantía limitada Esta Garantía Limitada entra en vigor el 1 de junio de 2011 y sustituye toda garantía sin fecha o garantía con fecha anterior al 1 de junio de 2011.
  • Page 14 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 15 THIS PAGE INTENTIONALLY LEFT BLANK...
