Summary of Contents for Lionel 72-4272-250
- Page 1 72-4272-250 02/09 Lionel Train Orders Building Owner’s Manual...
- Page 2 Wiring the accessory using an insulated track section Replacing the interior lamp Replacing the lamppost lamp Notes Limited Warranty/Lionel Service The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel ® , TrainMaster ®...
- Page 3 Installing the accessory and the 153C Contactor lace the accessory along any straight section of track on your layout. Be sure that all of your trains clear the accessory. If you choose to trigger the accessory using the 153C Contactor, install the Contactor approximately 14 inches from the accessory in the direction of the train’s approach.
- Page 4 3. Attach another wire to the accessory SWITCH terminal and connect it to the #2 terminal on the 153C Contactor. 4. Finally, attach another wire to the #3 terminal on the 153C Contactor and connect it to the remaining accessory SWITCH terminal. POWER SUPPLY Lionel Lockon FasTrack Accessory Power Wire Figure 2. Accessory connections...
- Page 5 Installing the lamppost s illustrated in Figure 3, plug the two prongs on the bottom of the lamppost into the socket on the platform. Be sure that the prongs line up with the holes. The lamppost may be installed in either direction. Platform socket Figure 3.
- Page 6 Wiring the accessory with the 153IR Controller ou may choose to connect this accessory with a 153IR Controller (available separately, 6-14111) and a 12-volt DC Relay (SPDT, 1A Contact rating) with a Diode (IN4001, IN4002, IN4003, or IN4004) available from your electronics supply store. The trains trigger the 153IR Controller by reflecting an infrared beam, so it is not necessary to install a pressure- sensitive Contactor under the track.
- Page 7 Wiring the accessory using an insulated track section ou may choose to connect this accessory with an Insulated Track Section (available separately, 6-12841 for O-27 track, 6-12840 for O-gauge track, or 6-12029 Accessory Activator Pack for FasTrack) and a 12-volt DC Relay (SPDT, 1A Contact rating) with a Diode (IN4001, IN4002, IN4003, or IN4004) available from your electronics supply store.
- Page 8 Replacing the interior lamp he interior of your accessory is illuminated by one lamp, Lionel part no. 610-4143-300. During the course of normal operations, this lamp may require replacement. Replacement lamps are available at your authorized Lionel Service Center or from Lionel Service in Chesterfield, MI.
- Page 9 Notes...
- Page 10 Station MUST be accompanied by the original receipt for purchase (or copy) from an Lionel Authorized Retailer*, will at the discretion of Lionel LLC, be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a suitable replacement is not available, Lionel will offer to replace the product with a comparable model (determined by Lionel LLC), if available.
