- Page 1 BEAUTY SOFT LIGHT DESK PAD USER MANUAL Mar 2019...
-
Page 3: Table Of Contents
Contents Contents [Fixture Information] Fixture Information Dimensions Technical Specifications Charging and Power Connection [Screen Explantion] Screen Explation [Setting] Brightness (Intensity) Adjust CCT (Correlated Color Temperature) Adjust - 3 -... -
Page 4: Fixture Information
CRI LED light sources can increase lifetime, reduce maintenance cost and power consumption. DS-PAD is used to set up on the desk for a person in newsroom. Buil-in battery for easy installation and positioning, and the battery can continuously operate for about 2.5 hours can be used. -
Page 5: Dimensions
Dimensions (DS-PAD) (inch) (9.44) (8.46) (1.14) (~1.85) (0.86) (7.71) (0.86) (1.57) (2.95) (0.98) (3.89) (4.72) - 5 -... -
Page 6: Technical Specifications
Technical Specifications DS-PAD Physical Size 240x90x29mm Beam Angle 135° Weight (g/lbs) 620 / 1.36 LED Chip 0.2W / 0.5W Power Consumption White Light (CCT) Full 2,900~6,000K (Bi-Color) Color Rendition CRI 95~98 Dimming 0~100% Continuous Control Jog Switch Controller Housing Color... -
Page 7: Charging And Power Connection
Charging and Power Connection This fixture requires an external power adapter of 12.6V DC. Power Switch Turn the fixture off and on. Menu switching, brightness and color temperature Jog Switch can be adjusted. Connect the 12.6V power supply to charge the device. Power Input It can be used with the power adapter connected. -
Page 8: Screen Explation
Screen Explation PUSH The menu screen changes Screen Switching each time press the jog. Current Status Brightness CCT Adjustment Start Screen Screen Adjustment Screen Screen Visible screen at start up. Current battery status (25% each Current battery status (25% each Current battery status (25% each , 4 bars), color temperature , 4 bars) and the light brightness... -
Page 9: Brightness (Intensity) Adjust
Brightness (Intensity) Adjust The value is The value automatically increased 1% by increases when hold each time lift up the jog switch up. the jog switch. Can be set up to 100%. Can be set up to 100%. DOWN The value is The value automatically decreased 1% by decreases when hold... -
Page 10: Cct (Correlated Color Temperature) Adjust
CCT (Correlated Color Temperature) Adjust The value is The value automatically increased 50K by increases when hold each time lift up the jog switch up. the jog switch. Can be set up to Can be set up to 6,000K. 6,000K. DOWN The value is The value automatically... - Page 11 LED Intelligent Lighting Solution For more information and questions, please visit our website or call. ALPHA LITE Co., Ltd. Floor, 5-8, Gyeongin-ro 88-gil, Yeongdeungpo-gu, Seoul, Republic of Korea, 07363 Email hello@alpha-lite.net (+82) 2-6317-0464 (+82) 2-2039-0464 www.alpha-lite.net...
