- Page 1 TURNTABLE INSTRUCTION MANUAL ENGLISH INVI TUS...
- Page 2 Operation Manual, so port damages will not affect the warranty period. The war- that you can get the best out of your INVICTUS. ranty extends only to the turntable and the motor inclusive We have tried to put all the necessary information you power pack.
- Page 3 Setup of the turntable / explosion drawing of packing To avoid damage during transport your turntable comes carefully packed. Unpack all the parts in the 2 boxes. Please be aware that the parts of the INVCITUS are very heavy. Ensure that a second person is available to assist you.
- Page 4 Place the base frame on top of your desired stand or rack. Please ensure that the rack is able to handle the total weight of the INVICTUS which is arround 142 kg or 313 lb! 2. Leveling the base frame...
- Page 5 4. Placing the chassis on top Please carefully take out the chassis (ask a second person for help) and put it on the top of the base frame. Ensure that the four circular pockets in the bottom of the chassis fit onto the decouplers. 5.
- Page 6 (blue), mounted in groove 1, run around motors 2, 4, 6. Note: the mentioned colours are only for explanation in this document. Real belts are black! Looking on top of your INVICTUS after mounting the belts it will look like this. 7. Mounting the platter Place the platter carefully on top of the subplatter as shown in the picture.
- Page 7 10. Changing armboards Your INVICTUS is able to handle up to four tonarms at the same time. To change the armboards simply open and remove the 2 screws in the middle of the armboard.
- Page 8 Dimensions H 34,0 cm W 80,0 cm D 70,0 cm Weigth: turntable approx. 142 kg / 313 lb rack approx. 175 kg / 386 lb Acoustic-Signature Made by AS-Distribution GmbH Hillenbrand Straße 10 D-73079 Süssen Tel: +49 7162 9474450 Fax: +49 7162 9474459 www.acoustic-signature.com E-Mail: info@as-distribution.de...
