Summary of Contents for Ocean Breeze OBZ-12NPF
- Page 1 OBZ-12NPF OBZ-14NPF WWW.OCEANBREEZECOMFORT.COM Read this owner’s manual thoroughly before operating the appliance and keep it handy for reference at all times.
- Page 2 Troubleshooting Tips Read This Manual Inside you’ll find many helpful hints on how to use and maintain your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your air conditioner. You’ll find many answers to common problems in the troubleshooting tips - you should be able to fix most of them quickly before calling service.
- Page 3 Control panel Upper air filter (behind the grille) Handle Horizontal louver (both sides) Upper air intake blade Drain outlet Air outlet Lower air filter Lower air intake Power plug socket Power cord outlet Caster Power cord buckle Bottom tray drain outlet FRONT REAR...
- Page 4 Please read through these instructions before you start the - DO NOT install your air conditioner in a wet room such as installation process. Improper installation can cause a bathroom or laundry room. Too much exposure to water damage to the unit, your personal property, and also poses can cause electrical components to short circuit.
- Page 5 - This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. - Children should be supervised to ensure that they do not play with the appliance.
- Page 6 Your installation location should meet the following requirements: - Make sure that you install your unit on an even surface to minimize noise and vibration. - The unit must be installed near a grounded outlet, and the Collection Tray Drain (found on the back of the unit) must be accessible. - The unit should be located at least 19.7 inch from the nearest wall to ensure proper air conditioning.
- Page 7 - Medium Phillips screwdriver; Step One: Preparing the exhaust hose assembly. - Tape measure or ruler; Press the exhaust hose into the window slider adaptor and the unit adaptor. Each adaptor will snap into the exhaust hose automatically with plastic clips. - Knife or scissors;...
- Page 8 Foam seal B (Short adhesive foam seal for right and left sides) Window slider B (if required) Window slider A Foam seal A (Long adhesive foam seal for top and bottom sides) Insert the window slider assembly on the bottom sash channel. Use care when installing the window Foam seal B (Short adhesive slider assembly, which will now...
- Page 9 In order to ensure the optimal performance of our products, the design specifications of the unit and remote control are subject to change without prior notice. inches the exhaust system to work purposes...
- Page 10 Constant CONSTANT FAN(Press 3s) Selects the desired operating mode. Each time Swing you press the button, a mode is selected in a Mode Timer Swing sequence that goes from AUTO, COOL, DRY, (>) (<) and FAN. The mode light illuminates and indicates the selected mode.
- Page 11 and read P1 on the LED display (it will stay like this until the unit is drained). If this happens, you should drain the water from the lower drain (located at the bottom of the unit). - When you set the air conditioner in AUTO mode, it will automatically select cooling or fan only operation depending on what temperature you have selected and the current room temperature.
- Page 12 - The system will automatically revert back to display the previous temperature - During dehumidifying modes, remove the setting if there is no operation within 5 seconds. upper drain plug from the back of the unit - Turning the unit ON or OFF at any time or adjusting the timer setting to 0.0 will and install the drain connector (5/8"...
- Page 13 down the grille Be sure to store the unit in a cool, dark place. Exposure to direct sunlight or extreme heat can shorten the lifespan of the unit.
-
Page 14: Troubleshooting Tips
Troubleshooting Tips Before calling for service, review this list. It may save you time and expense. This list includes common problems that may not be the result of defective workmanship or materials in this appliance.
