- Page 1 Compact Pellet Boiler Installation and User Manual ÜNLÜSOY Yapı Malzemeleri Sanayi ve Ticaret Ltd. Şti. Pancar Organize Sanayi Bölgesi, 2. Etap No:2, Torbalı – İZMİR Tel: 444 35 32, Faks: 0232 469 2412 www.unmak.com...
-
Page 2: Table Of Contents
Technopel Compact Pellet Boiler Installation and User’s Manual P a g e CONTENTS CONTENTS ............................... 1 INTRODUCTION ............................3 SAFETY ..............................3 SHIPPING AND HANDLING ........................4 SELECTION OF INSTALLATION PLACE ...................... 5 SAFETY PRECAUTIONS ..........................7 ELECTRICAL CONNECTION ........................8 TECHNICAL SPECIFICATIONS ........................ - Page 3 Technopel Compact Pellet Boiler Installation and User’s Manual P a g e This manual covers following models: TECHNOPEL 15-24-36-48 Please contact your local Authorized Technical Service for Commissioning, Start of the Warranty Period and Failure Report. Please call +90 444 35 32 for the Call Center.
-
Page 4: Introduction
P a g e INTRODUCTION Thank you so much for choosing the Ünmak brand Technopel Compact Pellet Boiler. Please carefully read the manual before installation for comfortable, long-lasting, high efficiency, and economic use. Do not touch any part of the boiler except for operation, adjustment, and maintenance purposes that specified in the manual. -
Page 5: Shipping And Handling
In order not to damage the outer plates of the boiler during transportation; transport equipment such as forklifts and pallet trucks can be used. The center of gravity of the Technopel series boilers is not in the middle and close to the left (in front view). Please be careful in handling process. -
Page 6: Selection Of Installation Place
Technopel Compact Pellet Boiler Installation and User’s Manual P a g e WARNING Please do not use sharp and cutting tools to avoid damaging the pellet boiler while unpacking WARNING Please avoid any crush injuries to hands and feet during transportation, installation, and assembly. - Page 7 Technopel Compact Pellet Boiler Installation and User’s Manual P a g e The fuels that burn in the boiler should be kept at a distance of at least 80 cm away from the boiler. It is recommended to store in a different room.
-
Page 8: Safety Precautions
It should not connect more than one boiler to the same chimney. Chimney of Technopel Pellet Boilers is individually used as well. The chimney and fresh air suction line can be taken out from the back of the boiler room. The flue cap must put to the outlet section of the chimney. -
Page 9: Electrical Connection
ELECTRICAL CONNECTION ÜNMAK Technopel Series Pellet Boilers requires 230 V~50 Hz electricity supply. The regulator should be used in the place that <10 % or >10 % of the mains voltage. All wiring and additional grounding outside the boiler must comply with local electrical wiring regulations. The heating system (room thermostat connection, frost protection thermostat, etc…) must be proper to use in mains voltage. -
Page 10: Technical Specifications
Technopel Compact Pellet Boiler Installation and User’s Manual P a g e TECHNICAL SPECIFICATIONS 1. Control Panel 6. Auger 11. Central Heating 16. Closed Expansion Tank Flow Line 2. Fume Extractor 7. Maintenance Door 12. Filling-Discharging 17. Cleaning Arm (Suction Fan) Line 3. -
Page 11: Installation System Rules
Technopel Compact Pellet Boiler Installation and User’s Manual P a g e | 10 INSTALLATION SYSTEM RULES The equipment such as circulation pump, expansion tank, the safety valve is included with the pellet boiler, and no need to add on to the installation when the hydronic connection of the boiler is completed. - Page 12 Technopel Compact Pellet Boiler Installation and User’s Manual P a g e | 11 Installation with Single Serpentine Hot Water Storage Tank Central Heating Flow Line (hot water) should be connected to the upper connection point of the boiler and central heating return line (warm water) should be connected to lower connection point.
- Page 13 Technopel Compact Pellet Boiler Installation and User’s Manual P a g e | 12 Warning Against Corrosion of Installation Please make sure that ÜNMAK boilers are highly resistant to corrosion. However, all ferrous components at the heating installation (including pipes and panel radiators) should be protected against corrosion.
-
Page 14: Control Board And User Interface
Technopel Compact Pellet Boiler Installation and User’s Manual P a g e | 13 CONTROL BOARD AND USER INTERFACE Press the on/off button for 5 seconds in order to open the ON/OFF button system. Press only one time for the close system. The system will shut down after the closure process complete. -
Page 15: Remarks Of User Interface
Technopel Compact Pellet Boiler Installation and User’s Manual P a g e | 14 REMARKS OF USER INTERFACE Pre-purge P2.4 Transition time (0-600 s) I0.1 Gearbox feeding time (0.0-40.0 s) I0.2 Gearbox pending time (0.0-2000 s) Power 3 I0.3 Fan speed (600-3000 rpm) P3.1... -
Page 16: Commisioning
Technopel Compact Pellet Boiler Installation and User’s Manual P a g e | 15 Cooling Circulation Pump Operation Times S2.1 Fan speed (0-3000 rpm) V4.1 Pump operation temperature (0-100 °C) S2.2 Cooling time 2 (0-20000 s) V4.2 Pump closure temperature (0-100 °C) V4.3 Feeding time in Pump temperature rise (0-255 s) -
Page 17: Maintenance & Cleaning Process
Technopel, Pelet Yakıtlı Sıcak Su Kazanı İşletme ve Bakım Kılavuzu S a y f a | 16 Press the ENTER button and use the arrow buttons to set the desired boiler temperature. After entering the desired value with the arrow buttons, press the ENTER button again and save the value. -
Page 18: Troubleshooting Guide
Technopel, Pelet Yakıtlı Sıcak Su Kazanı İşletme ve Bakım Kılavuzu S a y f a | 17 Cleaning: Cleaning must be done when the boiler is cool down. The electrical connection should be cut off in the cleaning stage. Please consider the below items while cleaning the boiler: •... - Page 19 Technopel, Pelet Yakıtlı Sıcak Su Kazanı İşletme ve Bakım Kılavuzu S a y f a | 18 PROBLEM POSSIBLE CAUSE SOLUTION Unsatisfied Flue draught may low Please carefully check the no holes and Combustion of the cracks on the chimney ...
