Technical Specifications - Powerfix Profi PLS 10 A1 User Manual And Service Information

Powerfix PLS 10 A1
These operating instructions have a fold-out cover. On the inside of the cover is a diagram of
the battery LED emitter with the components numbered. The meanings of the numbers are as
follows:
1 Handle
2 10 W Rechargeable Battery LED Working Light
3 Mounting bracket
4 Knurled screw
5 Stand
6 LED charging indicator
7 Rubber cover (for DC-IN receptacle)
8 DC-IN receptacle
9 On/Off switch
10 Knurled screws

Technical specifications

Battery LED emitter
Brand:
Model name:
Operating voltage:
Rechargeable battery:
Battery charging time:
Runtime with fully charged battery
Power consumption
complete battery LED emitter:
Safety class:
Degree of protection
4 - English
Powerfix
PLS 10 A1
12 – 24 V
Rechargeable Li-Ion battery 7.4 V / 5200 mAh
approx. 6 hours
approx. 3 hours at around 80% of luminous flux
approx. 10 W
(Extra Low Voltage, ELV)
IP65
