- Page 1 Perfect Fit Dado Jig Instructions Effective August 2020 Review full instructions prior to use for important safety information. Always check Rockler.com to confirm that you are using the most recent version of instructions for your product.
-
Page 2: General Safety Warnings
This product is designed only for specific applications as defined in the instructions and should not be modified or used for any manner not described in these instructions. Use only recommended accessories. Before using the Perfect Fit Dado Jig: READ, UNDERSTAND and FOLLOW ALL INSTRUCTIONS AND SAFETY WARNINGS. - Page 3 ALL knobs on the Perfect Fit Dado Jig have been tightened. > The Perfect Fit Dado Jig works only with 1/4"-, 3/8"- and > Make sure that your router’s power cord and dust hose 1/2"-diameter router bits. Do NOT use undersized plywood won’t obstruct the path of the jig or catch on anything...
- Page 4 The bit MUST not extend below the Router Plate (1) during setup. The Perfect Fit Dado Jig works only with 1/4"-, 3/8"- and 1/2"-diameter router bits. Do NOT use undersized plywood router bits.
- Page 5 1. Engage your clamp guide on a flat piece of plywood or other sheet material. Lock it down to keep it from shifting. 2. Place your Perfect Fit Dado Jig with mounted router on the clamp guide so that the clamp guide is between the Perfect Fit Fence (4) and the Tension Fence (5).
- Page 6 3. Fit the offcut piece in the stepped area formed by the fence of the Jig Base (2) and the Perfect Fit Fence (4). Make sure to place the offcut on the step that corresponds to the diameter of the router bit you are using. Fig. 5. 4.
- Page 7 7. Loosen the two 5/16"-18 x 1" Tall Five-Star Knobs (9) and remove the offcut from the jig. 8. Slide the Jig Base (2) toward the Perfect Fit Fence (4) as far as it will go. Make sure the fit is tight and then tighten the two 5/16"-18 x 1"...
- Page 8 Maintain consistent Check Rockler.com for updates. If you have further questions, please pressure on the router as you make the cut, and be sure to fully contact our Technical Support Department at 1-800-260-9663 exit the other side of the workpiece.
