The type of cables used can also influence the quality of the sound. For best results, use good-quality
balanced signal cables with TRS jack plugs or XLR connectors. Using unbalanced cables is also possible but
this can have a negative influence on the volume of the incoming signal and makes it more sensitive to
interference.
In general, studio and recording equipment is always fitted with balanced outputs. Consumer products like
smartphones and laptops tend to have unbalanced outputs.
Making Volume Adjustments
These Devine studio monitors are equipped with a volume control that can regulate the incoming signal if
necessary. It is designed to be used to adjust the monitors, not to correct issues with the incoming signal.
When using devices like a smartphone or laptop, the incoming signal may be relatively weak. In this case, a
DAC or a device that is capable of boosting the signal, like an audio interface, a mixer or a DI box should be
used.
Ideally, you'll be able to control the volume of the signal your DAC or interface sends to your monitors. This
can also be software-controlled like the volume control on your computer, laptop or mobile device, for
instance. It could also be a separate passive or active volume controller that regulates the level of the
analogue signal. These often have simple 'dim' or 'mute' buttons that allow you to easily hal ve the sound or
mute it entirely. These features are handy when you need to discuss the sound with someone while listening,
for example.
Crossover
The RX-10SA is equipped with a built-in low-pass crossover, which filters the sound of the input signal and
takes out any lows up to a certain limit. This limit can be set between 50 Hz and 120 Hz using the crossover
control. Again, feel free to experiment with the settings to find what best suits your set-up.
Thanks to the filtering and removing of the lows, your regular speakers or monitors are able to focus on a
narrower frequency range. Since the reproduction of lows costs more energy than that of other frequencies,
this not only boosts the performs of your complete set-up, but the overall energy efficiency and the level of
definition in the audio.
Phase switch
The phase switch enables you to mirror the sound reproduction of the subwoofer by 180 degrees. This can
be useful when you're dealing with a combination of factors, including:
– Fading frequencies caused by the crossover not setting a hard dividing line but instead, creates an X-
shaped gradient with a specific slope. This then causes certain frequencies to partly overlap.
– Acoustic interference that causes a 'pounding' sound effect.
Experiment with the settings to find what best suits the situation.
Status LED
The subwoofer is equipped with a status LED on the front (behind the Devine logo) that lights up when it is
powered on.
Overload and security
There is no overload indicator on this subwoofer because it is not designed to be used for listening at high
volume levels, especially for longer periods of time. Pay careful attention when listening to the subwoofer to
determine whether it is set at a suitable volume level. If there is any distortion and/or crackling noises, lower
the volume immediately to prevent damaging any components.
This subwoofer is not designed to perform continually at a high volume and should not be used for parties or
events. It should be used for its intended purpose only, which is listening to audio at a comfortable volume.
This can include recreational activities like listening to background music or amplifying the sound from your
television.
Devine cannot be held responsible for any components damaged due to overload and as such, any instance
of damage caused by overload is not covered under warranty.
The information in this user manual is subject to change at any time without notice.
Version 1.0 Date of creation and author's initials:21-07-2020 RV Revision date and author's initials: -
