Summary of Contents for FujiFilm FM-DP L

  • Page 1 FM-DP L Service Manual INSTALLATION...
  • Page 2 B1-10, B2-18, B2-19, B2-19.1~B2-19.4, B2-23, B2-54, B2-55, B3-2, B3-3, B4-4, B4-5, B5-2 06/30/01 Revised(FM3040) B-1~B-5, B-9~B-10, B-12, B-14, B-15, B1-1, B1-2, B1-9, B2-14, B2-16~B2-20, B2-22, B2-23.1~B2-25, B3-2~B3-5, B4-4, B4-5, B5-2, B7-3~B7-11, B8-1~B8-3, B9-1~B9-7 006-252-05 FM-DP L Service Manual 06.30.01 FM3040...
  • Page 3 2.3.3 Transport Unit (Left side of equipment) 2.3.4 Before-Sub-scanning/Sub Scanning Unit (Left side/Front side of equipment) 2.3.5 Storing Fixtures Securing the Unit (rear of Equipment) 2.3.6 Removal Unit (Front of equipment) 2.3.7 Heat Development Unit (Top of equipment) FP3B0001.EPS 006-252-02 FM-DP L Service Manual 10.22.99 FM2569...
  • Page 4 2.5.1 Setting Film Tray Size for Machine Numbers to #3024, #3027 to #3099 2.5.2 Setting Film Tray Size for Machine Numbers #3025, #3026, and #3100 Onwards 2.5.3 Attaching Position of Guide (For All Machine Numbers) FP3B0002.EPS 006-252-05 FM-DP L Service Manual 06.30.01 FM3040...
  • Page 5 2.11 Checking the Short-Circuiting of NFB 2.11.1 Front Side of Equipment 2.11.2 Right Side and Rear Side of the Equipment 2.11.3 Left Side of the Equipment 2.11.4 Sorter 2.12 Reinstalling Covers FP3B0003.EPS 006-252-05 FM-DP L Service Manual B-10 06.30.01 FM3040...
  • Page 6 2.15.2 Starting the M-Utility 2.15.3 Turning ON the Power of the Optical Transmission Unit Type-II (Refer to APPENDIX 2 OPTICAL TRANSMISSION UNIT TYPE-II) 2.15.4 Turning ON the Sorter Power FP3B0004.EPS 006-252-02 FM-DP L Service Manual B-11 10.22.99 FM2569...
  • Page 7 2.18.1 Checking the Upper Cover Interlock 2.18.2 Checking the Front Cover Interlock 2.18.3 Checking the Film Tray Interlocks 3. SYSTEM SETTINGS 3.1 Setting the System Date and Time 3.2 Parameter Continuous Setting 3.3 Setting Input CH FP3B0005.EPS 006-252-05 FM-DP L Service Manual B-12 06.30.01 FM3040...
  • Page 8 (Initialize optical head position of the density measurement unit may caused move during transportation.) 5.4.2 Automatic Density Correction (24-steps pattern [AUTO F. D. C.]) 5.4.3 Checking Density (24-steps pattern [Check Density]) FP3B0006.EPS 006-252-02 FM-DP L Service Manual B-13 10.22.99 FM2569...
  • Page 9 Films in Host Control Exposures from the Connected Devices 7.7 Checking Film Output and Images Checking the Equipment Termination from Connected Devices 7.8 Checking the Termination of the Equipment by Remote Operations FP3B0007.EPS 006-252-05 FM-DP L Service Manual B-14 06.30.01 FM3040...
  • Page 10 9.2.1 Checking the Error Log 9.2.2 Deleting Error Logs 9.3 Reinstalling and Cleaning Covers 9.4 Installing the Equipment 9.4.1 Installing the Equipment and Securing with Fixtures 9.4.2 Installing the Equipment without Using Fixtures FP3B0008.EPS 006-252-05 FM-DP L Service Manual B-15 06.30.01 FM3040...
  • Page 11 Be sure to wear a wristband for grounding when performing maintenance of boards and optical units. Otherwise static electricity in the body may cause damage to electronic parts on the boards and optical units. 006-252-05 FM-DP L Service Manual B1-1 06.30.01 FM3040...
  • Page 12 After completing wiring work (when connecting both connectors), remove the spiral tube for wiring protection to prevent drop in the optical communication performance due to bending of the spiral tube for wiring protection of the cord with connector. 006-252-05 FM-DP L Service Manual B1-2 06.30.01 FM3040...
  • Page 13 Do not remove the vinyl directly covering the equipment. Japan specifications Protective materials (One-side cardboard) Vinyl Equipment main body Bands Separately packaged items Carrier pallet FP3B0301.EPS Overseas specifications Vinyl Equipment Bands main body Separately packaged items Carrier pallet FP3B0310.EPS 006-252-02 FM-DP L Service Manual B1-3 10.22.99 FM2569...
  • Page 14 To avoid damage to the equipment, do not push the upper cover and front cover (shaded portions in the figure below). <SUPPLEMENTARY NOTE> The carrier pallet is about 15 cm high. FP3B0313.EPS 006-252-02 FM-DP L Service Manual B1-4 10.22.99 FM2569...
  • Page 15 B1-5 INSTALLATION 1. WORK BEFORE INSTALLATION Sorter Remove the protection covering the sorter and accessories. Remove the sorter from the base pad. 006-252-04 FM-DP L Service Manual B1-5 03.22.00 FM2742...
  • Page 16 • When carrying the equipment, support it so that it does not turn over. • When moving the equipment over any bump, slowly move it to avoid shock. The bump over which the equipment may move is about 10 mm high at the most. 006-252-02 FM-DP L Service Manual B1-6 10.22.99 FM2569...
  • Page 17 (DA-85) will be required. When installing the sorter, use the spanner provided on the sorter. Spanner FP3B0S01.EPS Embedding Anchor Nuts If securing the equipment to the floor using fixtures, embed anchor nuts. 006-252-02 FM-DP L Service Manual B1-7 10.22.99 FM2569...
  • Page 18 When installing the equipment main body and sorter 600~800 Rear 600~800 DP-LS451 Equipment Unit: mm Front 200~300 FP3B0S02.EPS Lower the adjustable foot of the equipment to secure the equipment. Equipment main body [Turn] Nut Caster Adjustable foot FP3B0309.EPS 006-252-02 FM-DP L Service Manual B1-8 10.22.99 FM2569...
  • Page 19 Screw (T4x12) Replace with fixing screws of covers during installation Screw (T4 x 25) Screw cover Cap (BNC) Attach to unplugged connector of image I/F board. Cap (D-SUB) Label For Eurpe only TP3B0302.EPS 006-252-05 FM-DP L Service Manual B1-9 06.30.01 FM3040...
  • Page 20 For writing bin information Rail Separately Interface cable Connected to rail Front side packaged Bracket accessories 2 Bracket Rear side Cover For sorter Screw BR4x8 Binding parts For securing power cable TP3B0S03.EPS 006-252-04 FM-DP L Service Manual B1-10 03.22.00 FM2742...
  • Page 21 B1-11 INSTALLATION 1. WORK BEFORE INSTALLATION BLANK PAGE 006-252-02 FM-DP L Service Manual B1-11 10.22.99 FM2569...
  • Page 22 Removing the External Packaging of the Equipment Main Body Remove the packaging material securing the cover. Protective sheet Shutter Tape FP3B0401.EPS Pull out the shutter forward. #1 [Peel off] Tape Film tray #2 [Remove] Shutter FP3B0442.EPS 006-252-02 FM-DP L Service Manual B2-1 10.22.99 FM2569...
  • Page 23 Upper left-hand side cover Upper rear cover Kapton belt cover Lower rear cover Lower left-hand side cover Upper right-hand side cover Front cover Lower front cover Arm cover Lower right-hand side cover FP3B0408.EPS 006-252-02 FM-DP L Service Manual B2-2 10.22.99 FM2569...
  • Page 24 FP3B0404.EPS Removing the foam block securing the lower squeezing roller Cut the band securing the arm. Release the tray lock by hands. #1 [Cut] Band #2 [Move] Arm Release by hands FP3B0458.EPS 006-252-02 FM-DP L Service Manual B2-3 10.22.99 FM2569...
  • Page 25 #1 [Remove] Tape/foam block #2 [Turn] Flywheel Kapton belt FP3B0410.EPS Removing the fixtures securing the unit #1 [Remove] 2-BR4 x 16 #2 [Remove] Fixtures x 2 FP3B0445.EPS 006-252-02 FM-DP L Service Manual B2-4 10.22.99 FM2569...
  • Page 26 2.3.3 Transport Unit (Left side of equipment) Removing the protective sheet securing the open/close guide plate #2 [Peel off] Tape #3 [Remove] Protective sheet Open/close guide plate #1 [Peel off] Tape FP3B0416.EPS 006-252-01 FM-DP L Service Manual B2-5 06.15.99 FM2514...
  • Page 27 Before-Sub-Scanning Conveyor/Sub Scanning Unit (Left side/Front side of equipment) Removing the tape securing the left guide plate [Peel off] Tape FP3B040A.EPS Removing the tape securing the left guide plate [Peel off] Tape Left guide plate FP3B0412.EPS 006-252-01 FM-DP L Service Manual B2-6 06.15.99 FM2514...
  • Page 28 B2-7 INSTALLATION 2. INSTALLATION Cutting the bands securing the grip arm [Cut]Band Grip arm FP3B0411.EPS Removing the fixtures securing the unit #1 [Remove] 2BR4 x 16 #2 [Remove] Fixtures x 2 FP3B0444.EPS 006-252-01 FM-DP L Service Manual B2-7 06.15.99 FM2514...
  • Page 29 B2-8 INSTALLATION 2. INSTALLATION 2.3.5 Storing Fixtures Securing the Unit (Rear of equipment) Fixtures FP3B0447.EPS 006-252-02 FM-DP L Service Manual B2-8 10.22.99 FM2569...
  • Page 30 Lower squeezing roller Film tray [Remove] Foam block FP3B0407.EPS Removing the film tray, upper tray cover #3 [Remove] #4 [Remove] 2-T4 x 6 Upper tray cover #2 [Remove] Tray #1 [Push] Stopper (Left/Right) FP3B0454.EPS 006-252-01 FM-DP L Service Manual B2-9 06.15.99 FM2514...
  • Page 31 Foam block FP3B0451.EPS Removing the protective sheet securing the weight Peel off tape pasted to the stay, and remove the whole protective sheet. Weight #2 [Remove] Protective sheet #1 [Peel off] Tape FP3B0405.EPS 006-252-01 FM-DP L Service Manual B2-10 06.15.99 FM2514...
  • Page 32 Second rack #3 [Remove] Protective sheet #2 [Remove] Bracket #1 [Remove] Screws x 2 (BR4x10) FP3B0452.EPS Removing the foam blocks securing the changeover guide Changeover guide solenoid (SOLG1) [Remove] Foam block FP3B0418.EPS 006-252-02 FM-DP L Service Manual B2-11 10.22.99 FM2569...
  • Page 33 Insert the pre-rotary idler roller straight in until it rests against the rear side plate. Attaching position Wheel Rubber roller Rear side plate Rear side Wheel Rubber roller Pre-rotary idler roller Front side FP3B0415.EPS 006-252-01 FM-DP L Service Manual B2-12 06.15.99 FM2514...
  • Page 34 • When holding the cleaning roller, hold the metal portion shown in the figure. Cleaning roller FP3B0419.EPS Attach the cleaning roller Cone Bearing FP3B0420.EPS <NOTE> Check that the cleaning roller is not riding onto the flange of the bearing. FP3B0421.EPS 006-252-02 FM-DP L Service Manual B2-13 10.22.99 FM2569...
  • Page 35 256M (Memory board x 5) CR (20 Pix/mm) x 1 CH + IM x 2 CHs (88 M for total of 2 CHs) CR (20 Pix/mm) x 2 CHs 256M (Memory board x 5) TP3B0400.EPS 006-252-05 FM-DP L Service Manual B2-14 06.30.01 FM3040...
  • Page 36 Image memory boards Notches FP3B0456.EPS Removing <SUPPLEMENTARY NOTE> To remove the image memory board, press the eject buttons on each side of the slot. #1 [Push] Eject button #2 [Remove] Image memory board FP3B0457.EPS 006-252-01 FM-DP L Service Manual B2-15 06.15.99 FM2514...
  • Page 37 B2-16 INSTALLATION 2. INSTALLATION 2.4.4 CPU Board for DICOM Connection To connect to the DICOM network, use a CPU90G board of version B or later. 006-252-05 FM-DP L Service Manual B2-16 06.30.01 FM3040...
  • Page 38 Insert the MEM11A board diagonally into the CN3 connector of the CPU board, and lock the MEM11A board with the hooks of the CN3 connector. [Secure] MEM11A [Insert] MEM11A Hooks for locking CPU90G CPU90G #2 [Secure] MEM11A #1 [Insert] MEM11A CPU board FP3B0S28.EPS 006-252-05 FM-DP L Service Manual B2-17 06.30.01 FM3040...
  • Page 39 Insert the memory card into the slot at the back of the CPU90G board. <NOTE> Insert until the memory card eject buttons eject out. Memory card Triangle mark Memory card eject button FP3B0476.EPS 006-252-05 FM-DP L Service Manual B2-18 06.30.01 FM3040...
  • Page 40 Insert the board into the slot, and secure with the two screws. #1 [Loosen] BR4 x 8 #3 [Remove] #2 [Remove] BR4 x 8 Board retainer #4 [Attach] Board #5 [Loosen] Screws x 2 FP3B0460.EPS Install the board retainer. 006-252-05 FM-DP L Service Manual B2-19 06.30.01 FM3040...
  • Page 41 Lower squeezing roller 6-BR4 x 10 3-BR4 x 14 Spacer Spacer Storage place of screws FP3B0477.EPS <NOTE> Attach screws which are no longer required after changing the tray size to the spacer to store. 006-252-05 FM-DP L Service Manual B2-19.1 06.30.01 FM3040...
  • Page 42 • When attaching the spacer, secure while pushing to the back. • After attaching, check that the spacer is attached at the position shown below. Film tray 0.5 mm or less Spacer FP3B0503.EPS 006-252-05 FM-DP L Service Manual B2-19.2 06.30.01 FM3040...
  • Page 43 B2-19.3 INSTALLATION 2. INSTALLATION <NOTE> If not using the spacer when setting the film tray size, keep it in the following place. Spacer FP3B0314.EPS 006-252-05 FM-DP L Service Manual B2-19.3 06.30.01 FM3040...
  • Page 44 INSTALLATION 2. INSTALLATION 2.5.3 Attaching Position of Guide (For All Machine Numbers) 26 x 36 cm film size 35 x 43 cm film size :Guide :Guide 20 x 25 cm film size :Guide FP3B0478.EPS 006-252-05 FM-DP L Service Manual B2-19.4 06.30.01 FM3040...
  • Page 45 Remove the two screws and remove the shield plate. Remove the two screws and remove the bracket and spacer. #4 [Remove] Bracket #5 [Remove] Spacer #1 [Remove] 2-T4 x 6 #3 [Remove] 2-B3 x 6 #2 [Remove] Shield plate FP3B0481.EPS 006-252-05 FM-DP L Service Manual B2-20 06.30.01 FM3040...
  • Page 46 #1 [Remove] Screws x 2 #2 [Remove] Conveyance guide FP3B0483.EPS Cut the band binding the connectors (CNB1, CNB3, CNB4, CNMB2) to the lower removal unit secured to the rear side of the equipment. 006-252-02 FM-DP L Service Manual B2-21 10.22.99 FM2569...
  • Page 47 Attach the spacer and bracket to the shield plate sparately packaged, and attach them to the equipment. #1 [Attach] Spacer, bracket #4 [Tighten] 2-T4 x 6 #2 [Tighten] 2-B3 x 6 #3 [Attach] Shield plate FP3B0485.EPS 006-252-05 FM-DP L Service Manual B2-22 06.30.01 FM3040...
  • Page 48 Connect the hose to the upper removal unit. SVA1 #1 [Connect] Hose FP3B048A.EPS Connect the four connectors from the rear side of the equipment. #2 [Connect] Connectors CNB3 CNB1 CNMB2 CNB4 #1 [Connect] Connectors CNB3, CNMB2 CNB4 FP3B048B.EPS 006-252-04 FM-DP L Service Manual B2-23 03.22.00 FM2742...
  • Page 49 Material: Rubber Material: Rubber Color: Cream Color: Black Roller C Roller C Material: Rubber Material: Resin Color: Cream Color: White FP3B0S29.EPS Arrangement of Rollers Roller A Roller B FRONT Roller C FP3B0S30.EPS 006-252-05 FM-DP L Service Manual B2-23.1 06.30.01 FM3040...
  • Page 50 Remove the extension springs, and remove the housings together with the roll bearings. Housing Bearing (4)#1 [Remove] Extension spring L=78.4mm FRONT (4)#2 [Remove] 4-E6 Housing Bearing (4)#1 [Remove] Extension spring L=75.9mm FP3B0S32.EPS 006-252-05 FM-DP L Service Manual B2-23.2 06.30.01 FM3040...
  • Page 51 The timing belt wheel attached to roller A is of the one-way type. (7)#2 [Remove] (7)#1 [Remove] Timing belt wheel Timing belt wheel for roller B Roller A (7)#2 [Remove] Free direction Roller B Timing belt wheel for roller A (One-way) Washer FRONT FP3B0S34.EPS 006-252-05 FM-DP L Service Manual B2-23.3 06.30.01 FM3040...
  • Page 52 (10) Remove rollers A, B, and C. <SUPPLEMENTARY NOTE> The timing belt wheel attached to roller A is of the one-way type. Timing belt wheel Free direction Roller B Roller A Roller C FRONT FP3B0S36.EPS 006-252-05 FM-DP L Service Manual B2-23.4 06.30.01 FM3040...
  • Page 53 • Engage the extension spring at the center of the housing. • Attach the housing so that the flat sides face each other. Engage the extension spring here. Housing FP3B0S37.EPS 006-252-05 FM-DP L Service Manual B2-23.5 06.30.01 FM3040...
  • Page 54 A rotates. Check that when the timing belt is rotated in direction B of the figure with the hand, roller A does not rotate. Timing belt Roller A FRONT FP3B0S39.EPS 006-252-05 FM-DP L Service Manual B2-23.6 06.30.01 FM3040...
  • Page 55 B2-23.7 INSTALLATION 2. INSTALLATION BLANK PAGE 006-252-05 FM-DP L Service Manual B2-23.7 06.30.01 FM3040...
  • Page 56 B2-23.8 INSTALLATION 2. INSTALLATION BLANK PAGE 006-252-05 FM-DP L Service Manual B2-23.8 06.30.01 FM3040...
  • Page 57 • Cross head small screw (inch screw) (4) 2.7.2 Installing the HDD Kit Set the HDD settings. 4.5GB Short plug FP3B0488.EPS Pin1 J6 (No setting is required) Reserved Pin1 Short plug FP3B0315.EPS 006-252-05 FM-DP L Service Manual B2-24 06.30.01 FM3040...
  • Page 58 #1 [Attach] HDD assembly CN33 #2 [Tighten] Screws x 2 BR4 x 8 CNJ1 #4 [Connect] Connectors CN29, CN33 CNJ2 #5 [Fix] Clamps 2-BR4 x 8 #4 [Connect] Connectors CNJ1, CNJ2 FP3B0472.EPS 006-252-05 FM-DP L Service Manual B2-25 06.30.01 FM3040...
  • Page 59 INSTALLATION 2. INSTALLATION Assembling the Optional Optical Transmission Unit-II Refer to "INSTALLATION Appendix 2. Optical Transmission Unit Type-II" and assemble the optical transmission unit type-II. "A 2.1 Assembling the Optical Transmission Unit Type-II". 006-252-02 FM-DP L Service Manual B2-26 10.22.99 FM2569...
  • Page 60 #1 [Loosen] Two screws FP3B0S03.EPS Remove the cap from the upper right-hand side cover of the FM-DP L removed. Push out the cap from the rear of the upper right-hand side cover to remove. Attach the brackets (front/rear) to the upper right-hand side cover.
  • Page 61 Connect the sorter to the FM-DP L bracket. FP3B0S23.EPS Check that the height from the ground to the FM-DP L and that to the sorter are the same in the connected state. Check the gap between the sorter and FM-DP L.
  • Page 62 To adjust, rotate the caster height adjusting nut of the sorter using the spanner, and adjust the sorter within the specified range. BR4 x 8 Spanner FP3B0S06.EPS (10) Separate the sorter from the FM-DP L, and return the spanner to its original position. (11) Attach the rail. 2-BR4 x 8 Rail FP3B0S05.EPS...
  • Page 63 #3 [Remove] Resin cover #2 [Remove] Right-hand side cover FP3B0433.EPS Overseas use: Reconnect the power supply cable to the terminal for the power supply used. CAUTION Tighten the screws firmly. 230V 120V FP3B0498.EPS 006-252-02 FM-DP L Service Manual B2-30 10.22.99 FM2569...
  • Page 64 Connect the power supply cable to the equipment, and turn ON the power switch on the rear side of the equipment. CAUTION Use the exclusive FM-DP L power cable. Using a tester, measure the resistance between the terminals of the power plug and check that they have not short-circuited.
  • Page 65 Measure the resistance between the terminals of the power plug using the tester and check that they have not shorted. ∞Ω ∞Ω 1.7 Ω (Reference value) FP3B0S21.EPS Turn OFF the power switch of the sorter, and disconnect the power cable. 006-252-02 FM-DP L Service Manual B2-32 10.22.99 FM2569...
  • Page 66 Remove the front side cover of the power supply unit, and check that all nine NFBs of the power supply board are ON. Protrusion Front side cover FP3B0434.EPS Attach the front side cover of the power supply unit. 006-252-02 FM-DP L Service Manual B2-33 10.22.99 FM2569...
  • Page 67 B2-34 INSTALLATION 2. INSTALLATION Check that the three NFBs in front of the DRV11A board are ON. NFB4 NFB9 NFB6 From the front side DRV11A (three NFBs) FP3B0497.EPS 006-252-02 FM-DP L Service Manual B2-34 10.22.99 FM2569...
  • Page 68 Check that the four NFBs on the DRV11A board and one NFB on the SCN11A board are ON. NFB8 NFB2 NFB5 NFB1 NFB7 From the rear side From the right side SNS11A (One NFB) DRV11A (three NFBs) DRV11A (One NFB) FP3B0496.EPS 006-252-02 FM-DP L Service Manual B2-35 10.22.99 FM2569...
  • Page 69 B2-36 INSTALLATION 2. INSTALLATION 2.11.3 Left Side of the Equipment Check that the two NFBs on the MTH11A board are ON. FRONT NFB1 NFB2 FP3B0462.EPS 006-252-02 FM-DP L Service Manual B2-36 10.22.99 FM2569...
  • Page 70 Remove the control board cover, and check that the three NFBs on the SRT11A board are ON. #1 [Loosen] #2 [Remove] 4-BR3 x 12 Control board cover FP3B0S09.EPS SRT11A board NFB1 FP3B0S10.EPS 006-252-02 FM-DP L Service Manual B2-37 10.22.99 FM2569...
  • Page 71 Upper cover 4-T4x25 Upper left-hand side cover Upper rear cover 4-T4x12 Kapton belt cover 4-T4x12 Lower rear cover Upper right-hand 4-T4x25 side cover Front cover 4-T4x25 Arm cover Lower right-hand side cover FP3B0495.EPS 006-252-02 FM-DP L Service Manual B2-38 10.22.99 FM2569...
  • Page 72 <NOTE> For details on connection of the FM-DP image interface board and external device connected, refer to "A1. Setting, Connecting, and Adjusting the Image I/F Board". FP3B0430.EPS 006-252-02 FM-DP L Service Manual B2-39 10.22.99 FM2569...
  • Page 73 Connect the remote panel interface cable to the MAIN connector. If a hand switch or foot switch is available, connect it to the EXT. SW connector. (3) [Connect] Hand switch or foot switch cable (4) [Connect] Remote panel I/F cable FP3B0436.EPS 006-252-02 FM-DP L Service Manual B2-40 10.22.99 FM2569...
  • Page 74 (SWA1502W) AC adapter power cable FP3B0489.EPS Connect the remote panel interface cable to the PANEL connector of the image interface board attached to SLOT1, SLOT2, or SLOT3. Remote panel interface cable FP3B0439.EPS 006-252-02 FM-DP L Service Manual B2-41 10.22.99 FM2569...
  • Page 75 "A 2. Connecting to Optical Transmission Unit Type-II" 2.13.5 Connecting Interface Cables Between the Sorter and Equipment Remove the two screws. Connect the sorter to the bracket of the FM-DP L, and fix the sorter to the rail by the removed screws. 006-252-02 FM-DP L Service Manual B2-42 10.22.99 FM2569...
  • Page 76 B2-43 INSTALLATION 2. INSTALLATION #1 [Remove] 2-BR4 x 8 #2 [Fix] 2-BR4 x 8 FP3B0S07.EPS Connect the interface cable, and tighten the fixing screws of the connectors. [Connect] Two connectors FP3B0S08.EPS 006-252-02 FM-DP L Service Manual B2-43 10.22.99 FM2569...
  • Page 77 Use a tester to check the power supply voltage of the outlet. For domestic use in Japan : 100V±10% : 110V/120V/200V/220V/230V/240V ±10% For overseas use 006-252-02 FM-DP L Service Manual B2-44 10.22.99 FM2569...
  • Page 78 The startup screen appears on the touch panel. Remote/Local switch FP3B0441.EPS <NOTE> Normally, use the Remote/Local switch to turn ON/OFF the power of the equipment. Leave the Power switch at the rear side at ON. 006-252-02 FM-DP L Service Manual B2-45 10.22.99 FM2569...
  • Page 79 Refer to "INSTALLATION Appendix 2. Optical Transmission Unit Type-II" and connect the optical transmission unit type-II and turn its power ON. "A 2.3 Connecting to Power Supply" and "A 2.4 Power ON" 006-252-02 FM-DP L Service Manual B2-46 10.22.99 FM2569...
  • Page 80 (U. K., etc.) Canada, etc.) Spain, Sweden, etc.) Binder FP3B0S22.EPS Remove the interlock release jig from the FM-DP L, and attach to the interlock switch of the sorter. Interlock release jig FP3B0S16.EPS Turn ON the power switch of the sorter.
  • Page 81 Open the upper cover, and attach the interlock release jig to the upper cover interlock. FP3B0492.EPS Touch [Heat-Developper], [Fan Operation], [FanG1&FanG2], and then [ON]. Check the operations and wind direction of all fans. Touch [OFF]. Remove the jig and close the upper cover. 006-252-02 FM-DP L Service Manual B2-48 10.22.99 FM2569...
  • Page 82 Checking the Operations of the Optical Transmission Unit Type-II Fan Refer to "INSTALLATION Appendix 2. Optical Transmission Unit Type-II" and check the fan operations of the optical transmission unit-II. "A 2.5 Checking Fan Operations" 006-252-02 FM-DP L Service Manual B2-49 10.22.99 FM2569...
  • Page 83 +15V±2% SCN11A board +15V (+14.70~+15.30V) TP51-TP46 (GND) +15V±2% SCN11A board +15VM (+14.70~+15.30V) TP54-TP46 (GND) +24V±2% SCN11A board +24V(+24VC) (+23.52~+24.48V) TP53-TP46 (GND) +5V±2% MTH11A board +5VS (+4.90~+5.10V) TP21-TP4 (GND) TP3M0202.EPS Remove the jig. 006-252-02 FM-DP L Service Manual B2-50 10.22.99 FM2569...
  • Page 84 TP44 TP52 TP51 TP54 TP53 TP47 (GND) (-5.2V) (+5V) (+12V)(-15V)(+15V)(+15VM)(+24V)(GND) FP3B0459.EPS Measured point (MTH11A board) FRONT TP21(+5VS) TP4(GND) FP3B0449.EPS Adjusting volume (Power supply board) -5.2V +5V +12V -15V +15V +15VM +24V +5VS FP3B0453.EPS 006-252-02 FM-DP L Service Manual B2-51 10.22.99 FM2569...
  • Page 85 TP2 TP4 TP6 TP8 -5V +15V -15V +5V Power supply unit FP3B0493.EPS If the voltage differs from the specified value, turn the voltage adjusting volume (ADJ), and adjust the voltage to the specified range. 006-252-02 FM-DP L Service Manual B2-52 10.22.99 FM2569...
  • Page 86 Measured point (SRT11A board) 24V GND 5V FP3B0S13.EPS Adjustment volume Power supply unit of sorter Voltage adjustment volume FP3B0S15.EPS Remove the interlock release jig, and return to the original position. Attach the control board cover. 006-252-02 FM-DP L Service Manual B2-53 10.22.99 FM2569...
  • Page 87 Touch [Check Mechanism], [Motor Operation], [MG1], and then [CCW]. → The MG1 drives. Open the upper cover. Check that the operating sound of the MG1 stops. Close the upper cover. Touch [STOP]. 006-252-04 FM-DP L Service Manual B2-54 03.22.00 FM2742...
  • Page 88 Touch [Initial Check]. The self-diagnosis of the scanner is executed, and the message "Failed" appears with error code "0512". This allows the interlock function to be checked if it is normal. Touch [QUIT]. 006-252-04 FM-DP L Service Manual B2-55 03.22.00 FM2742...
  • Page 89 Touch [Check Mechanism], [Motor Operation], [MB2], and then [CCW]. Check that no operating sounds of the MB2 can be heard. Touch [STOP] and then [QUIT]. Close the film tray and pull out the shutter. 006-252-02 FM-DP L Service Manual B2-56 10.22.99 FM2569...
  • Page 90 B2-57 INSTALLATION 2. INSTALLATION BLANK PAGE 006-252-02 FM-DP L Service Manual B2-57 10.22.99 FM2569...
  • Page 91 • To correct the values entered, touch [DEL]. Touching [DEL] deletes one character on the left side of the cursor. • Changes can be made from the time the settings have been made. 006-252-01 FM-DP L Service Manual B3-1 06.15.99 FM2514...
  • Page 92 Film tray 1/26 x 36 cm and Film tray 2/35 x 43 cm..NG Film tray 1/26 x 36 cm and Film tray 2/26 x 36 cm..OK *1: Main unit software version B03 or later. 006-252-05 FM-DP L Service Manual B3-2 06.30.01 FM3040...
  • Page 93 External Machine Name : Set a 14-character long name consisting of alphabets, numbers, and spaces for each channel. *1: Main unit software version B01 or later. *2: Main unit software version B03 or later. 006-252-05 FM-DP L Service Manual B3-3 06.30.01 FM3040...
  • Page 94 Perform the same procedure for all channels connected. <NOTE> At "Film Size", set the size of the film actually loaded for all channels used. End the M-Utility. Turn ON/OFF the power of the equipment. 006-252-05 FM-DP L Service Manual B3-4 06.30.01 FM3040...
  • Page 95 B3-5 INSTALLATION 3. SYSTEM SETTINGS BLANK PAGE 006-252-05 FM-DP L Service Manual B3-5 06.30.01 FM3040...
  • Page 96 → The 24-stops pattern is output and automatic density correction is executed. Check the recording image format. "5.1 Checking for Film Image Unevenness, Flaws, Recording Image Format, and Conveyance Operations". End the M-Utility. 006-252-01 FM-DP L Service Manual B4-1 06.15.99 FM2514...
  • Page 97 Touch [System Management], [HD], and then [HD R/W Test]. Touch [YES]. → Start the HD read write test. After ending the test, check that the "Completed" message is displayed, and touch [QUIT]. End the M-Utility. 006-252-01 FM-DP L Service Manual B4-2 06.15.99 FM2514...
  • Page 98 4.3.1 Setting the Sorter Presence Connect the sorter to the bracket of the FM-DP L. Turn ON the Remote/Local switch of the FM-DP L, and start the M-Utility during initialization. Touch [System Management], [System Config.], [Set Parameters], [Sorter Setting], [Sorter Connection], and then [With Sorter].
  • Page 99 Only the following symbols can not be entered. “,”, “@”, “;” DICOM connection Within maximum 16 digits of the AE Title sent from the FN-PS551 to FM-DP L, enter top two digits at [Channel Code] and following digits (maximum 8 digits) at [Department Code].
  • Page 100 B4-5 INSTALLATION 4. SETTING OPTIONS Toshiba protocol connection The modality code (equivalent to the channel code of FM-DP L) is sent to FM-DP L from FN-PS551. Depending on the FN-PS551 software version, the host name sent from the modality may or may not be sent to FM-DP L. Consequently, the setting for [Department Code] at FM-DP L may or may not be required.
  • Page 101 Modality code set at the MF-300/L FP3B0S20.EPS <SUPPLEMENTARY NOTE> Above examples • The [Channel Code] is 01 when FCR is connected to CH1. • The [Channel Code] is 03 when FCR is connected to CH3. 006-252-02 FM-DP L Service Manual B4-6 10.22.99 FM2569...
  • Page 102 INSTALLATION 4. SETTING OPTIONS Example of setting Connection conditions Connect the CH1 input of the MF-300/L #2 to CH1 of FM-DP L #1, and output to Bin 10. Connect the FCR9000 to CH2 of the FM-DP L #1, and output to Bin 8.
  • Page 103 1 to 3, and set modality codes to the group. When connected to DICOM • Select the desired [Group #] excluding 1 to 3, and set the AE Title to the group. FP3B0S26.EPS 006-252-02 FM-DP L Service Manual B4-8 10.22.99 FM2569...
  • Page 104 DICOM connected to Bins 1 and 2, and the input from the TOSHIBA protocol connected to Bins 6 and 7. Connect the CT directly to CH2 of the FM-DP L, and output to Bins 3, 4, 5. CH3 of the FM-DP L is not connected.
  • Page 105 • Check that no abnormal sounds nor smell are produced from the equipment. • Check that no film jamming has occurred. • Check that the recording image format has not changed. • Check that there is no image unevenness and flaw. 006-252-02 FM-DP L Service Manual B5-1 10.22.99 FM2569...
  • Page 106 F - G 35 x 43cm Position 35 x 43 cm ≤1.2 A - B C, C' 352±1.2 D, E 1.0±1.0 ≤1.2 D - E 428±1.2 ≤0.6 F - G (Unit:mm) FP3B0711.EPS 006-252-05 FM-DP L Service Manual B5-2 06.30.01 FM3040...
  • Page 107 INSTALLATION 5. CHECKING THE OPERATIONS OF THE EQUIPMENT Checking the sorter Interlock Separate the sorter while executing the M-Utility, and check the interlock function. Connect the sorter to the FM-DP L. Touch [Check Mechanism], [Sorter Unit], [Motor MT1], and then [ON]. → The sorter motor starts driving.
  • Page 108 → Cleaning film is output to each bin. <CONFIRM> • No abnormal noise or smell is produced from the sorter. • Film does not jam. • There are no scratches on the film image. 006-252-02 FM-DP L Service Manual B5-4 10.22.99 FM2569...
  • Page 109 Touch [F.D.C.], [AUTO F.D.C.], and then [TRAY1]. The 24-steps pattern is output and automatic density correction is executed. If using film tray 2, perform the same procedure for that tray. Touch [QUIT]. 006-252-02 FM-DP L Service Manual B5-5 10.22.99 FM2569...
  • Page 110 2.46±0.07 2.70±0.10 2.64±0.07 3.00±0.10 TP3M0201.EPS Check the densities of gradation types 2.64 and 3.0 for film tray 1 and film tray 2. End the M-Utility. Turn off the power of the equipment. 006-252-02 FM-DP L Service Manual B5-6 10.22.99 FM2569...
  • Page 111 B5-7 INSTALLATION 5. CHECKING THE OPERATIONS OF THE EQUIPMENT BLANK PAGE 006-252-02 FM-DP L Service Manual B5-7 10.22.99 FM2569...
  • Page 112 Turn OFF the power of the external device. Check that the equipment starts system termination, and the power goes OFF. Check that the equipment ends by remote operations in all the channels connected to the equipment. 006-252-01 FM-DP L Service Manual B6-1 06.15.99 FM2514...
  • Page 113 WAIT A MINUTE Initialization in progress. Wait a minute. Start-up screen Initialization processing screen FP3B0512.EPS After entering the maintenance mode, the main menu appears on the screen about 30 seconds to 1 minute later. 006-252-01 FM-DP L Service Manual B7-1 06.15.99 FM2514...
  • Page 114 Turn ON the power of the remote panel, and check that the equipment starts up normally. Check that the equipment starts up from the remote panel for all channels connected to the equipment. 006-252-02 FM-DP L Service Manual B7-2 10.22.99 FM2569...
  • Page 115 Install the software of the language selected at step (3) above. "MAINTENANCE 5.5.4 Installing the Remote Panel Software " Turn OFF/ON the power of the remote panel, and check that the language set is displayed. 006-252-05 FM-DP L Service Manual B7-3 06.30.01 FM3040...
  • Page 116 The connector terminals of each board come with a protective cap for preventing static electricity damage. To prevent discharge to the signal pin of connectors, be sure to attach this protective cap to unused connector terminals. 006-252-05 FM-DP L Service Manual B7-4 06.30.01 FM3040...
  • Page 117 "MAINTENANCE 5.5.3 Installing Host Control Software of Other Manufacturers". "MAINTENANCE 5.5.3 Installing Host Control Software of Other Manufacturers". <NOTE> Main unit software versions B01 or later need not be installed as they are included in the main unit software FD. 006-252-05 FM-DP L Service Manual B7-5 06.30.01 FM3040...
  • Page 118 The following 20 x 25 cm film size formats cannot be selected. Portrait: MP03: B2, MP08: B5 Landscape ML03: C3, ML08: C6 Execute film output, and check that 20 x 25 cm film format is output nor- mally. 006-252-05 FM-DP L Service Manual B7-6 06.30.01 FM3040...
  • Page 119 Set the input channel of the host connected. Select 20 x 25 cm size format to be used. Execute film output, and check that 20 x 25 cm film format is output nor- mally. 006-252-05 FM-DP L Service Manual B7-7 06.30.01 FM3040...
  • Page 120 Set the input channel of the host connected. Select 20 x 25 cm size format to be used. Execute film output, and check that 20 x 25 cm film format is output nor- mally. 006-252-05 FM-DP L Service Manual B7-8 06.30.01 FM3040...
  • Page 121 • Check that there is no image unevenness. • Check the image density. • Check that there is no density inconsistency in the main scanning direction. • Check the recording image format and output characters. 006-252-05 FM-DP L Service Manual B7-9 06.30.01 FM3040...
  • Page 122 Turn OFF the power of the remote panel. Check that the equipment starts system termination, and the power goes OFF. Check that the equipment ends by remote panel in all the channels con- nected to the equipment. 006-252-05 FM-DP L Service Manual B7-10 06.30.01 FM3040...
  • Page 123 B7-11 INSTALLATION 7. CHECKING IMAGER CONNECTION BLANK PAGE 006-252-05 FM-DP L Service Manual B7-11 06.30.01 FM3040...
  • Page 124 • Tie the two cables together with the tie band. <SUPPLEMENTARY NOTE> UTP: Unshielded type Connect the 10BASE-T/100BASE-TX cable (UTP) to CN7 of the LAN90A board. Attach the protective cap provided to metal connectors which are not connected. 006-252-05 FM-DP L Service Manual B8-1 06.30.01 FM3040...
  • Page 125 Check that there is no image unevenness. • Check the image density. • Check that there is no density inconsistency in the main scanning direction. • Check the recording image format and output characters. 006-252-05 FM-DP L Service Manual B8-2 06.30.01 FM3040...
  • Page 126 INSTALLATION 8. CHECKING THE NETWORK CONNECTION Checking the Equipment Termination Check that the Remote/Local switch on the operation panel is set to OFF. Check that the equipment starts system termination, and the power goes OFF. 006-252-05 FM-DP L Service Manual B8-3 06.30.01 FM3040...
  • Page 127 Set the backup floppy disk (DOS formatted) in the floppy disk drive. <SUPPLEMENTARY NOTE> The floppy disk can be formatted in this equipment. Touch [System Management], [FD], [Individual Data], [Save to FD], and then [Save All]. Touch [QUIT]. 006-252-05 FM-DP L Service Manual B9-1 06.30.01 FM3040...
  • Page 128 Deleting Error Logs Touch [System Management], [Error Log Data], and then [Clear]. Touch [YES]. → All the error log data are cleared. End the M-Utility and turn OFF the power of the equipment. 006-252-05 FM-DP L Service Manual B9-2 06.30.01 FM3040...
  • Page 129 B9-3 INSTALLATION 9. INSTALLING THE EQUIPMENT Reinstalling and Cleaning Covers Reinstall the lower left-hand side cover and lower front cover. Clean all covers with a moist cloth. 006-252-05 FM-DP L Service Manual B9-3 06.30.01 FM3040...
  • Page 130 Clamp the hex socket head bolt onto the rear side spacer and fixture at the base of the equipment. "INSTALLATION 1.2 Unpacking, Unloading" Spacer Fixture M12x25 bolt FP3B0706.EPS Secure the fixture with the buried anchor nut. Adjustable foot Fixture Fixture Fixture FP3B0704.EPS 006-252-05 FM-DP L Service Manual B9-4 06.30.01 FM3040...
  • Page 131 • Check that the clearance between the equipment and sorter is within the specified range. "INSTALLATION 2.9 Installing the Optional Sorter" 006-252-05 FM-DP L Service Manual B9-5 06.30.01 FM3040...
  • Page 132 • Check that the clearance between the equipment and sorter is within the specified range. "INSTALLATION 2.9 Installing the Optional Sorter" 006-252-05 FM-DP L Service Manual B9-6 06.30.01 FM3040...
  • Page 133 B9-7 INSTALLATION 9. INSTALLING THE EQUIPMENT BLANK PAGE 006-252-05 FM-DP L Service Manual B9-7 06.30.01 FM3040...
  • Page 134 128µs 2µs 2µs 1µs 256µs 4µs 4µs 8µs 8µs 2µs 512µs 16µs 16µs 4µs 1.024ms 32µs 32µs 8µs 2.048ms 64µs 64µs 16µs 4.096ms 102µs 102µs 32µs 8.192ms Invalid Invalid 64µs 16.384ms FP3B0901.EPS 006-252-01 FM-DP L Service Manual BA1-1 06.15.99 FM2514...
  • Page 135 RS422 interface, and DPI board-specific interfaces (those specific to Siemens auto-filming and Picker MR auto-filming, etc.). Connect the remote panel I/F cable to CN5 (labeled PANEL on the board retaining panel) of the DPI06A or DPI06B board. 006-252-01 FM-DP L Service Manual BA1-2 06.15.99 FM2514...
  • Page 136 HOST I/F RS232c/RS422 select switch (S1, S2) board input channel select (S4, S5) IN ch (SLOT) (ADR) RS232C setup Fixed to OFF DVI board setup because not (factory default setup) used Invalid Other RS422 setup FP3B0902.EPS 006-252-01 FM-DP L Service Manual BA1-3 06.15.99 FM2514...
  • Page 137 DVI90A board. <NOTE> The HOST auto-filming I/F cable should be connected only when the HOST auto-filming specification is applicable. There are two interface types: RS232C and RS422. 006-252-01 FM-DP L Service Manual BA1-4 06.15.99 FM2514...
  • Page 138 Acquisition start line EVEN setting (for G/J version, only Q1 is labeled on the EVEN side.) PANEL HOST CN450 DIGITAL VIDEO Sync phase signal adjustment switch (S1) Phase delay 10ns 12ns 14ns FP3B0903.EPS 006-252-01 FM-DP L Service Manual BA1-5 06.15.99 FM2514...
  • Page 139 (one line is recorded twice by splitting it into odd and even pixels). For example, if pixel offset occurs only during acquisition of odd pixels, an improper image with every other pixel offset results. 006-252-01 FM-DP L Service Manual BA1-6 06.15.99 FM2514...
  • Page 140 • Adjustment procedure If the DVI90A board of version G or later is used, images are acquired properly, so there is no need for adjustment. 006-252-01 FM-DP L Service Manual BA1-7 06.15.99 FM2514...
  • Page 141 Change the interlace switching in VIDEO ADJUST of the Service Option back to ODD from EVEN End of adjustment (Check to see that the setting on the DVI90A board is ODD) FP3B0938.EPS 006-252-01 FM-DP L Service Manual BA1-8 06.15.99 FM2514...
  • Page 142 Conditions 2 and 3 will result in an improper image due to improper interlaced line format. By optimally adjusting the VIDEO ADJUST value under Condition 4, a proper image acquisition can be achieved without white blank or line omission at the beginning. 006-252-01 FM-DP L Service Manual BA1-9 06.15.99 FM2514...
  • Page 143 HOST I/F RS232C/RS422 select switch (S1, S2) board input channel select (S4, S5) CN8 configuration IN ch (SLOT) (ADR) RS232C setting Fixed to OFF because Invalid Other HAV board setup not used (factory default setup) RS422 setting FP3B0907.EPS 006-252-01 FM-DP L Service Manual BA1-10 06.15.99 FM2514...
  • Page 144 Termination connector HOST VIDEO COMPOSITE SYNC For COMPONENT & HD & VD signals • • • HAV90A board Keep the supplied termination connector attached to the A•OUT connector. Termination connector HOST VIDEO FP3B0941.EPS 006-252-01 FM-DP L Service Manual BA1-11 06.15.99 FM2514...
  • Page 145 HAV90A board. <NOTE> The HOST auto-filming I/F cable should be connected only when the HOST auto-filming specification is applicable. There are two interface types: RS232C and RS422. 006-252-01 FM-DP L Service Manual BA1-12 06.15.99 FM2514...
  • Page 146 R301 R302 TP12 TP105 OFF(S2)ON OFFSET GAIN ADIN AGND View seen from the side View seen from the side FP3B0908.EPS NOTE The adjustment procedures described below must be performed in order named. 006-252-01 FM-DP L Service Manual BA1-13 06.15.99 FM2514...
  • Page 147 • Therefore, it is recommended that if CN7 and CN8 are set to TH (through output) and • OP (termination OFF), respectively, the connection cable be as short as possible. 006-252-01 FM-DP L Service Manual BA1-14 06.15.99 FM2514...
  • Page 148 More types of applicable host equipment than indicated in the table above are possible. Specification Vertical sync signal waveform 1 1 line No serrated pulse FP3B0910.EPS Vertical sync signal waveform 2 1 line No serrated pulse FP3B0911.EPS 006-252-01 FM-DP L Service Manual BA1-15 06.15.99 FM2514...
  • Page 149 Adjust OFFSET with trimmer R301. Pedestal level = Black level When the "setup" is zero Correct Incorrect Incorrect Pedestal level When the "setup" is not zero Black level Correct Incorrect Incorrect FP3B0913.EPS 006-252-01 FM-DP L Service Manual BA1-16 06.15.99 FM2514...
  • Page 150 • The character or other signal level may overshoot the white level. However, be sure to adjust the white level to –2V. • If this adjustment is not made properly, optimum gradation conditions will not be obtained. 006-252-01 FM-DP L Service Manual BA1-17 06.15.99 FM2514...
  • Page 151 Wait until the PLL lock indicator LED (D8) lights, and press the STORE key. When the switch is changed, it may take some time for the PLL lock indicator LED (D8) to light. 006-252-01 FM-DP L Service Manual BA1-18 06.15.99 FM2514...
  • Page 152 (one line is recorded twice by splitting it into odd and even pixels). For example, if pixel offset occurs only during acquisition of odd pixels, an improper image with every other pixel offset results. 006-252-01 FM-DP L Service Manual BA1-19 06.15.99 FM2514...
  • Page 153 To apply filtering, set the short pins of CN9 as needed. No filtering F80M F40M F20M 80MHz low-pass filtering F80M F40M F20M 40MHz low-pass filtering F80M F40M F20M 20MHz low-pass filtering F80M F40M F20M FP3B0915.EPS 006-252-01 FM-DP L Service Manual BA1-20 06.15.99 FM2514...
  • Page 154 CN17 (vertical sync) Remarks (horizontal sync) H37K 27.027~37.037µs 27~37kHz LA (factory default LA (factory default Use the factory Negative H27K 37.037~50.000µs 20~27kHz setup) setup) default setting fixed. Positive H20K 50.000~64.516µs 15.5~20kHz FP3B0921.EPS 006-252-01 FM-DP L Service Manual BA1-21 06.15.99 FM2514...
  • Page 155 COMPOSITE VIDEO HOST For COMPONENT & COMPOSITE SYNC signals • • • HAV90B board HOST VIDEO COMPOSITE SYNC For COMPONENT & HD & VD signals • • • HAV90B board HOST VIDEO FP3B0922.EPS 006-252-01 FM-DP L Service Manual BA1-22 06.15.99 FM2514...
  • Page 156 HAV90B board. <NOTE> The HOST auto-filming I/F cable should be connected only when the HOST auto-filming specification is applicable. There are two interface types: RS232C and RS422. 006-252-01 FM-DP L Service Manual BA1-23 06.15.99 FM2514...
  • Page 157 • If one or more vacant slots cannot be secured above the HAV90B board when it is assembled into this machine, first power OFF the machine and remove the board from it before changing the filter selection setting. 006-252-01 FM-DP L Service Manual BA1-24 06.15.99 FM2514...
  • Page 158 • Therefore, it is recommended that if CN7 and CN8 are set to TH (through output) and • OP (termination OFF), respectively, the connection cable be as short as possible. 006-252-01 FM-DP L Service Manual BA1-25 06.15.99 FM2514...
  • Page 159 CN15 should be set to SP1. Examples of special input spec Vertical sync signal waveform 1 1 line No serrated pulse FP3B0925.EPS Vertical sync signal waveform 2 1 line No serrated pulse FP3B0926.EPS 006-252-01 FM-DP L Service Manual BA1-26 06.15.99 FM2514...
  • Page 160 Adjust OFFSET with trimmer R301. Pedestal level = Black level When the "setup" is zero Correct Incorrect Incorrect Pedestal level When the "setup" is not zero Black level Correct Incorrect Incorrect FP3B0928.EPS 006-252-01 FM-DP L Service Manual BA1-27 06.15.99 FM2514...
  • Page 161 • The character or other signal level may overshoot the white level. However, be sure to adjust the white level to -2V. • If this adjustment is not made properly, optimum gradation conditions will not be obtained. 006-252-01 FM-DP L Service Manual BA1-28 06.15.99 FM2514...
  • Page 162 16 ns (0 when OFF, +16ns when ON) with S2. Adjust both S1 and S2 in combination so as to obtain an optimal image over a range from 0 to 31 ns. 006-252-01 FM-DP L Service Manual BA1-29 06.15.99 FM2514...
  • Page 163 In order to delay the count start signal (about 6 ns delay), set CN16 to IR. IR RG CN16 With delay in the count start signal of the sampling clock IR RG CN16 With no delay in the count start signal of the sampling clock 006-252-01 FM-DP L Service Manual BA1-30 06.15.99 FM2514...
  • Page 164 No filtering CN18 80MHz low-pass filtering CN18 CN18 CN9 40MHz low-pass filtering CN18 HAV90B board 20MHz low-pass filtering CN18 FP3B0936.EPS 006-252-01 FM-DP L Service Manual BA1-31 06.15.99 FM2514...
  • Page 165 I/F cable, connect the power remote cable and existing inter-module I/F cable together via the adapter box. Normal case OPR06A When the existing inter-module I/F Power remote cable cable is used Existing inter-module I/F cable Adapter box FP3B0943.EPS 006-252-01 FM-DP L Service Manual BA1-32 06.15.99 FM2514...
  • Page 166 • Do not remove the connector cover unless the connector is to be connected. • Make sure that the optical fiber cable is protected by the tension member when it is pulled. 006-252-01 FM-DP L Service Manual BA1-33 06.15.99 FM2514...
  • Page 167 Check if the icon of the service option Rebooting after Power OFF is dimmed out. FP3B0946.EPS <NOTE> For more details on the operating procedures of the Maintenance Mode and Service Option, see “MAINTENANCE 5. SERVICE MODE.” 006-252-01 FM-DP L Service Manual BA1-34 06.15.99 FM2514...
  • Page 168 • For inputs of interlaced image, if the starting line for interlaced image acquisition is • improper, perform the following procedure depending on the type of image input • board used. · For HAV90A/B board or DVI90A board Switch the interlace ODD/EVEN mode during VIDEO SADJUST. 006-252-01 FM-DP L Service Manual BA1-35 06.15.99 FM2514...
  • Page 169 TYPE-II A2.1 Assembling Optical Transmission Unit Type-II Removing Optical Transmission Unit Type-II Cover Remove the top cover (retaining screw x5) from the optical transmission unit type-II. [Remove] Top cover Screw ×5 FP3B0801.EPS 006-252-01 FM-DP L Service Manual BA2-1 06.15.99 FM2514...
  • Page 170 HAV90B board to be installed in the optical transmission unit type-II should be set to match the setting of the input channel select switch located on the OPR06A board to be connected to the optical transmission unit type-II. 006-252-01 FM-DP L Service Manual BA2-2 06.15.99 FM2514...
  • Page 171 [Install] HAV90A/HAV90B/DVI90A board Screw ×2 HAV90A/HAV90B/ DVI90A board OTM06A board FP3B0803.EPS <NOTE> Make sure that the card puller is snapped into the front notch when the HAV90A, HAV90B, or DVI90A board is assembled. 006-252-00 FM-DP L Service Manual BA2-3 03.18.99 FM2437...
  • Page 172 • Do not remove the connector cover unless the connector is to be connected. • Make sure that the optical fiber cable is protected by the tension member when it is pulled. 006-252-00 FM-DP L Service Manual BA2-4 03.18.99 FM2437...
  • Page 173 FP3B0806.EPS Connect the power cable to the optical transmission unit type-II. For 100/120V For 220V/230V For 240V (Japan, U.S., (Germany, France, (U.K., etc.) Canada, etc.) Spain, Sweden, etc.) Power cable FP3B0807.EPS 006-252-01 FM-DP L Service Manual BA2-5 06.15.99 FM2514...
  • Page 174 BA2-6 INSTALLATION APPENDIX 2 OPTICAL TRANSMISSION UNIT TYPE-II Set the REMOTE/LOCAL select switch in the REMOTE position, and then reinstall the switch cover. [Attach] Switch cover Screw 110V REMOTE/LOCAL select switch FP3B0808.EPS 006-252-00 FM-DP L Service Manual BA2-6 03.18.99 FM2437...
  • Page 175 The startup screen appears upon turning ON the operation panel. <NOTES> • If there is more than one input channel, the FM-DP L is powered by turning ON the power switch of one of the remote panels. After that, turn ON the power switch of the remaining operation panel(s).
  • Page 176 Checking Fan Operation Check if the power supply unit fan and front fan are operating, and if there is no offensive noise or odor emitted. Front fan Power supply unit fan FP3B0809.EPS 006-252-01 FM-DP L Service Manual BA2-8 06.15.99 FM2514...
  • Page 177 TP1 TP3 TP5 TP7 OTM06A board TP2 TP4 TP6 TP8 –5V +15V –15V +5V Power supply unit FP3B0810.EPS If the measured voltage is out of the specified range, turn the voltage adjustment trimmers (ADJ). 006-252-01 FM-DP L Service Manual BA2-9 06.15.99 FM2514...
  • Page 178 If the optical transmission unit type-II cannot be placed securely with the feet attached, then place the unit without attaching them. [Attach] Feet ×4 Screw ×4 FP3B0811.EPS Secure the optical transmission unit type-II in place for final placement. 006-252-01 FM-DP L Service Manual BA2-10 06.15.99 FM2514...
  • Page 179 BA2-11 INSTALLATION APPENDIX 2 OPTICAL TRANSMISSION UNIT TYPE-II BLANK PAGE 006-252-00 FM-DP L Service Manual BA2-11 03.18.99 FM2437...
  • Page 180 BA3-1 INSTALLATION APPENDIX 3 1-BYTE (ALPHABETIC CODE) TABLE APPENDIX 3 1-BYTE (ALPHABETIC CODE) TABLE <NOTE> Use ASCII code. & < > 006-252-00 FM-DP L Service Manual BA3-1 03.18.99 FM2437...

Table of Contents
