What You Need To Provide - Parallax 28560 Manual

Part Parallax No.
C1 201-01070
C2, C3 201-01063
J1 450-00104
452-00057
J2 450-00105
721-00011
700-00089
710-00028
711-00004
713-00018
Additional Parts for Interfacing
805-00002
451-00303
500-00008
500-00003
150-02200
150-04710

What You Need to Provide

For Assembly
Fine-tipped
soldering iron and
•
Wire clippers
•
Needle-nosed pliers
•
99% isopropyl alcohol and an old (clean) toothbrush
•
Miniature (#0) Phillips screwdriver
•
Pointed tweezers
•
Eye protection
•
Copyright © Parallax Inc.
Description
100 F aluminum
electrolytic capacitor
(color may vary)
0.1 F ceramic
capacitors (marked
"104")
2 x 3 header (2mm)
2mm shunts
2x3 header (0.1")
Two-piece black Delrin
rectangular base set
Black plastic snap
rivets
#2 x ¼" Phillips pan
head machine screws
#2 hex nuts
White nylon spacers
14" servo extension
cable
3-pin header
2N3904 NPN transistor
(marked 2N3904)
2N3906 PNP transistor
(marked 2N3906)
2.2K ¼ W resistors
(red, red, red)
470Ω ¼ W resistor
(yellow, violet, brown)
small diameter
(1/32") rosin-core solder (lead-free or leaded)
Mouse Sensor Kit (#28560)
Illustration (not to scale)
v1.0 6/1/2010 Page 2 of 18
Quan.
1
2
1
2
1
1
4
4
4
4
2
2
1
1
3
1
