sd = addr
GOSUB WriteNeg
GOSUB ReadNeg
#ELSE
SHIFTOUT sdio, sclk, MSBFIRST, [addr\8]
INPUT sdio
SHIFTIN sdio, sclk, MSBPOST, [dat\8]
#ENDIF
RETURN
WriteAddr:
' WriteAddr writes data to a sensor chip register.
' Inputs: addr = address ($00 - $7F) to write.
' dat = data to write to the addressed register.
#IF (NEG_CLK) #THEN
sd = addr | $80
GOSUB WriteNeg
sd = dat
GOSUB WriteNeg
#ELSE
SHIFTOUT sdio, sclk, MSBFIRST, [addr|$80\8, dat\8]
#ENDIF
RETURN
WriteNeg:
' WriteNeg simulates the SHIFTOUT instruction, but with a
' negative-going (inverted) clock.
' Inputs: sd = data to write, MSB first.
OUTPUT sdio
FOR i = 0 TO 7
sdio = sd.BIT7
PULSOUT sclk, 25
sd = sd << 1
NEXT
INPUT sdio
RETURN
ReadNeg:
' ReadNeg simulates the SHIFTIN instruction, but with a
' negative-going (inverted) clock.
' Outputs: dat = data read from serial bus, MSB first.
FOR i = 0 TO 7
dat = dat << 1
PULSOUT sclk, 25
dat.BIT0 = sdio
NEXT
RETURN
