f) Single / Quad mode

Use the "QUAD" button (10, 37) to switch between the various display modes:
• Single mode
The selected channel (1, 2, 3 or 4) is displayed permanently. Briefly press the "
DVR or the IR remote control to manually switch to another channel. The associated channel number of the cur-
rently active channel is shown at the top left of the display.
Unused channels can be disabled in OSD menu (e.g. if you use only two wireless cameras on channels 1
and 2, channels 3 and 4 can be disabled; you can then use the arrow buttons to switch between channels
1 and 2).
• Quad mode
All four channels are displayed at the same time. The display is reduced to a quarter of the normal size. The associ-
ated channel number is displayed at the top left of each of the small images.
Unused channels can be disabled in OSD menu (e.g. if you use only two wireless cameras on channels
1 and 2, channels 3 and 4 can be disabled; the images from channels 1 and 2 are then displayed next to
each other).

g) Starting/stopping recording manually

To start or stop the recording, press the "REC" button (9) on the monitor/DVR or the "REC/STOP" button (29) on the
IR remote control.
When recording is in progress, a flashing symbol "• REC" appears in the display. Some control functions
are disabled during recording.
" or " " button on the monitor/
