Additional information
TBS CLOUD
All TBS CROSSFIRE transmitters and the FUSION video receivers include a built-in WiFi module that allows
you to connect all your gear through the TBS CLOUD. This allows using features like VTX follow, dynamic
VTX power with a FUSION module, and other upcoming features.
Menu
WiFi Client
●
○ AP Mode: enables/ disables the WiFI module
Default SSID: enables/ disables the SSID broadcast of CROSSFIRE TX hotspot
○
○ SSID: SSID/ name of the selected external hotspot
Password: password for the externally selected hotspot
○
○ Connect: manually connect to the network. Only necessary when a new network is chosen
in the SSID option
Scan: scans for WiFI networks. Found networks can be chosen under SSID , manually
○
reconnect by Connect is required
Forget WiFi: erases all saved networks and their passwords
○
○ Upgrade: starts the self-update for the WiFi firmware. FW 2.03 or later required
MAVLink (UDP/ TCP)
●
○ MAVLink: select the protocol (UDP or TCP) or turn the MAVLink stream off.
Port: change the UDP/ TCP port where the telemetry will be sent (WiFi 2.03 sues TCP)
○
○ UPLINK CNT etc: Status of the MAVLink stream, works only with TCP
WebUI
●
○ WEB UI: enables/ disables the WEB UI
AP Lock: enables/ disables password authentication for CROSSFIRE TX internal WiFi
○
hotspot
Password: set up a password for CROSSFIRE TX internal WiFi hotspot
○
○ Login: enables/ disables password authentication for CROSSFIRE TX internal Web Ui
Password: set up a password for CROSSFIRE TX internal Web Ui
○
● PRO
WiFI Power: power level of the WiFI module
○
○ TBS CLOUD: enables/ disables the TBS CLOUD connection
Autoscan: enables/ disables the scanning for previously bound Hotspots
○
