Summary of Contents for Buhler BuhlerVision HMT-1

  • Page 1 BühlerVision Quick Start Guide. Innovations for a better world.
  • Page 2 Welcome to the next generation of remote support with BühlerVision. The BühlerVision solution will make the support process easier, faster and cheaper by utilizing the latest remote support software and the latest generation of smart glasses. With the head mounted camera and display the BühlerVision service desk member can give you real-time support and see what you see.
  • Page 3: Table Of Contents

    Table of Contents Page No. Chapter 1: Initial setup hardware 1.1 Familiarize yourself with the HMT-1 Using the HMT with a Hard Hat 1.2 Check your eye dominance 1.3 Put the HMT-1 on 1.4 Charging the HMT-1 1.5 Battery 1.6 Turn the HMT-1 on Chapter 2: Initial setup software 2.1 Getting started with setup: 2.2 Troubleshooting Wi-Fi Configuration &...
  • Page 4: Chapter 1: Initial Setup Hardware

    Chapter 1: Initial setup hardware. 1.1 Familiarize yourself with the HMT-1. Rear Head Pad (removable) Speaker Power Button Action Button MicroSD Door Elbow Joint Camera Pod...
  • Page 5 Display Window USB-C Audio Mic B2 Jack Removable Battery Micro USB Overhead Strap (removable) Mic B1 Shoulder Joint Display Pod Mic A1 (A2 on opposite side) Wrist Joint Locking Ring Boom Arm...
  • Page 6: Using The Hmt With A Hard Hat

    Using the HMT with a Hard Hat. To attach your HMT to a hard hat, you’ll need Hard Hat Clips which you can purchase at shop.realwear.com. When you have the clips ready, complete the following steps: 1. Hook the Hard Hat Clips into the HMT band and snap them into place. 2.
  • Page 7: Check Your Eye Dominance

    1.2 Check your eye dominance. Eye dominance is the tendency to prefer visual input from one eye to the other. Most people are right-eye dominant; however, in a small portion of the population neither eye is dominant. It is best to use your dominant eye when viewing the display. To determine which eye is dominant: 1.
  • Page 8: Charging The Hmt-1

    1.4 Charging the HMT-1. 1. Connect the USB-C charge cable to the USB-C port located under the rear cover on the same side as the boom arm. 2. Connect the charge cable to the regional wall charger and then plug the charger into the wall Regional wall charger socket.
  • Page 9: Turn The Hmt-1 On

    1.6 Turn the HMT-1 on. Press and hold the Power Button for 3 seconds to turn on the device. Rotate camera up/ down to get best view. When using the HMT-1 device you can always say “Show Commands” to get a list with all available voice commands for the step you are in.
  • Page 10: Chapter 2: Initial Setup Software

    Part A: Wi-Fi Configuration Step 1: On the HMT-1, go to “Settings” Step 2: Say “Connect to Wi-Fi Network” Step 3: Go to Chrome browser on your PC and type in: https://buhler.apps.newforgetech.com Please note that only WPA and WPA2 encrypted networks are supported...
  • Page 11 Say “Continue” to get to the home screen. “Wi-Fi” successfully connected. Part B: User Login Step 1: Go to: https://buhler.apps.newforgetech.com/ Step 2: Enter your username and password. Step 3: Once you are logged in, go to “User Profile” and then “My Login” and scan the code...
  • Page 12: Chapter 3: How To Start A Remote Support Call

    Chapter 3: How to start a remote support call. 3.1 Create a case at https://myBühler.com As the first step, always open a case in the myBühler system. ƒ Please refer to your service guidelines to submit a ticket for an issue and start a ƒ...
  • Page 13: Conducting A Remote Support Call

    You will be on the home screen now. The HMT-1 is controlled by using your voice. ƒ Simply say what you see on the screen. 3.3 Conducting a remote support call. Make a call: When you are ready to, you can say “call support” The support person(s) will be listed who are available and online.
  • Page 14: Functionalities Within A Support Call

    Receiving a call: The flashlight of the HMT-1 will start to flash and an audible ringtone will sound when you receive an incoming call. Once you see the screen below say “Accept” 3.4 Functionalities within a support call. To see a list of all available functions you can say “Show Commands” this will display a menu with all commands and functions that are available during a remote support call.
  • Page 15: Settings Menu

    Flashlight On/Off: Switches the flashlight of the HMT-1 on or off ƒ Turn Screen On/Off: Switches the display of the HMT-1 on or off ƒ Say “Exit Application” and press the Power Button until the device shuts down. Please ƒ charge the device while you are not using it.
  • Page 16 Step 1: On the HMT-1 say “Connect to Wi-Fi Network” Step 2: Go to Chrome browser on your PC and type in: ƒ https://buhler.apps.newforgetech.com/then login with your username and password Step 3: Go to “Wi-Fi Configuration” tab and enter the name of your Wi-Fi network ƒ...
  • Page 17 Volume This is only for the volume of the notification sounds not for the volume in a call: ƒ You can set the volume level to a value between 0-100%: e.g. say ƒ “Volume 40” to set the volume level to 40% ƒ...
  • Page 18 Smart Technology Features. 100% Hands Free Outdoor Display Voice based operating system with Appears size of 7” tablet, viewable in local speech recognition in loud areas bright sunlight Unmatched Noise Cancellation Water Resistant Four digital microphones and IP66 – Protected against heavy seas advanced algorithms or powerful jets of water Powerful Audio...
  • Page 19 For the latest version of this quick start guide, manuals and instructional videos check out the “Extra” tab on the BühlerVision Portal: https://buhler. apps.newforgetech.com...
  • Page 20 Bühler Inc. 13105 12th Avenue North Plymouth MN 55441-4509 T 763-847-9900 F 763-847-9911 www.buhlergroup.com...
