Clinical Imaging
Macro images captured from a fixed distance
1
Turn On
Push & hold power
button for 1-2 sec.
2
Move Extension Arm
Push or pull forward
3
Turn Focus Lever
To Bottom Position
4
Press Shutter Button
Push to take photo,
which will be dis-
played on screen.
Press shutter button
to return to live view,
press again to take
another photo.
Dermoscopic Imaging
Lesion images captured with skin contact
1
Turn On
Push for
1-2 sec.
2
Move Extension Arm
Push or pull back
3
Choose Polarization
On-screen icon color
indicates status:
X
= Polarized
X
= Non-Polarized
4
Turn Focus Lever
To Top Position
5
Press Shutter Button
Push to take photo,
which will be dis-
played on screen.
Press shutter button
to return to live view,
press again to take
another photo.
