Selecta MACRO Manual page 12

GUIDE DE L'UTILISATEUR
4. Programming menu:
S ºC MIN PR STA
1 125 30 1 STP
+ 5 seg.
S ºC MIN PR STA
1 125 30 1 PRG
Validate
S ºC MIN PR STA
1 125 30 1 PRG
Validate
S ºC MIN PR STA
1 125 30 1 PRG
Validate
S ºC MIN PR STA
2 125 20 1 PRG
•
•
•
S ºC MIN PR STA
3 145 OFF 1 PRG
Validate
S ºC MIN PR STA
1 145 31 1 STP
5. Checking program parameters:
The temperature / time parameters can be checked from the STP state.
S ºC MIN PR STA
1 1 2 5 3 0 1 STP
Use keys
J.P. SELECTA s.a.
S ºC MIN PR STA
CODE 80158.02 REV 0 02/10/09
Select the program to edit. Use keys
(Default: program 1)
Select the step to edit. Use keys
(Default: step 1)
Set temperature for the step. Use keys
(Temperature must be always higher than the previous step)
(Default: previous step temperature)
Set time (minutes) for the step. Use keys
(Default: OFF)
Automatically jump to the next step.
Program finish when there is an step with the time set at value OFF.
Once, a step with the time set at value OFF, is validated, it left pro-
gramming status and returns to STOP status.
It jumps to STOP state. Ready to RUN the program.
Select the program to check. Use keys
to move at step position on the display
