MIN / MAX /AVG Display Function
In the MIN MAX mode the meter tracks the lowest (MIN), highest (MAX), and average
(AVG) readings while displaying elapsed time.
1.
Press the MIN MAX button to start the Elapsed Timer (bottom left side of LCD)
2.
Begin taking measurements
3.
The secondary display (lower right) will display only the primary display's highest
reading (the MAX icon will be visible on the bottom of the LCD).
4.
Press the MIN MAX button to see the MIN (minimum) reading.
5.
The secondary display (lower right) will display only the primary display's lowest
reading (the MIN icon will be visible on the bottom of the LCD).
6.
Press the MIN MAX button to see the AVG (reading)
7.
The secondary display (lower right) will display only the primary display's average
reading (the AVG icon will be visible on the bottom of the LCD).
8.
Press and hold the MIN MAX button for three (3) seconds to exit this mode and return
to normal operation (the MIN, MAX, and AVG display icons should switch off when
this mode is successfully exited).
9.
Note that in MIN MAX mode, the T1 T2 / T1-T2 button is active allowing the user to
view the MIN/MAX/AVG of the T1, T2, or T1-T2 displays.
Auto Power OFF (Sleep Mode)
The meter will automatically turn off if no keys are pressed during any twenty (20) minute
period. To configure the Sleep Mode ON or OFF:
1.
With the meter ON, press the SETUP button to enter the SETUP mode (the SETUP
display icon will appear on the LCD)
2.
Repeatedly press the UP arrow button until the SLP (sleep) icon appears on the LCD
3.
Press the ENTER button (on or off will appear on the LCD under the SLP icon)
4.
Use the UP/DOWN arrow buttons to select ON (sleep mode on) or OFF (sleep mode
defeated)
5.
Press ENTER again to save the selection
6.
Press SETUP again to exit the setup mode and to return to normal operation.
Display OFFSET adjustment
Use the display OFFSET feature to compensate for thermocouple irregularities and to
better match two thermocouples. The allowable offset range is ± 9
1.
With the meter ON, press the SETUP button to enter the SETUP mode (the SETUP
display icon will appear on the LCD)
2.
Use the UP arrow button to select input T1 or input T2 (icons are shown on left side
of LCD)
3.
Press the ENTER button; the temperature reading will appear in the primary display
area. The offset will be shown in the smaller secondary display area
4.
Use the UP/DOWN arrow buttons to program an offset. The available range is ± 9
o
(±5
C)
5.
Press ENTER again to save the selection
6.
Press SETUP again to exit the setup mode and to return to normal operation.
Turning Power OFF
Press the
button to turn power off.
4
o
o
F (±5
C).
o
F
TM200 V4.1 11/06
