DATE:
09/11/95
MODEL:
Micro Lynx
REVISION:
All
SERIAL NO:
All
SOFTWARE:
All
REQUIRED TOOLS:
Static safe workstation
Grounding wrist strap
REQUIRED PARTS:
TimeLine Part Number 71B007, Micro Lynx M3 Option Card
PROCEDURE:
1. Turn off the power and place the Micro Lynx System Unit on a static safe
workstation. Ground yourself and the workstation anti-static mat.
2. On the back of the System Unit, remove cover labeled
3. Remove the six phillips screws securing the top cover to the System Unit.
4. Position the System Unit so that the front panel faces you and remove the top cover.
If your Micro Lynx System Unit Serial Number is 1024 or higher, you have new metal work. The
new metal work does not require the Option Card Bracket. Please turn to Page Four of this
ECC NO. 763
Phillips screwdriver
installation guide for instructions on installing the M3 Card.
Micro Lynx M3 Option Card
THIRD MACHINE EXPANSION
Note:
Page 1
Installation Guide
1755 LA COSTA MEADOWS DRIVE, SUITE B
SAN MARCOS, CA 92069
TEL. 760-761-4440
(FAX 760-761-4449)
SUPPORT@DIGAUDIO.COM
.
73631 REV. B
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TimeLine Micro Lynx M3 Option Card
Summary of Contents for TimeLine Micro Lynx M3 Option Card
- Page 1 Phillips screwdriver Grounding wrist strap REQUIRED PARTS: TimeLine Part Number 71B007, Micro Lynx M3 Option Card PROCEDURE: 1. Turn off the power and place the Micro Lynx System Unit on a static safe workstation. Ground yourself and the workstation anti-static mat.
- Page 2 Micro Lynx M3 Option Card PROCEDURE (continued): Install the Option Card Bracket 5. The Back Panel PCB is located at the top back of the chassis, horizontal to the back panel. Remove the "L" shaped bracket supporting the Back Panel PCB by removing the phillips screws;...
- Page 3 Micro Lynx M3 Option Card 10. Tilt and slide the left side of the card into the groove along the bottom of the Micro Lynx Side Panel. PROCEDURE (continued): Figure 3. Installation of M3 Card 11. As the card slides into the groove, lie it flat in the chassis.
- Page 4 Micro Lynx M3 Option Card PROCEDURE (continued): Install the M3 Option Card (New Metal Work) 5. The M3 Card is mounted on the left side of the System Unit, component side up. The M3 Card will lie flat in the chassis.
- Page 5 Micro Lynx M3 Option Card Page 5 ECC NO. 763 73631 REV. B...
