Introduction
System Setup Planning
AC Power
System Supervisor Unit
09/08/00
This chapter describes installation and interface procedures for
the Lynx System Supervisor Unit (SSU). It also includes a quick
initialization check, to verify that the SSU is communicating
properly.
As the SSU offers almost no operational features on its own, this
chapter will concentrate on installations utilizing various
TimeLine and other manufacturers equipment.
Part I of this chapter describes SSU installation logistics. Part II
describes SSU installation with TimeLine controllers, Lynx
Modules, and console automation computers. The interface dia-
grams in Part II of this chapter will also help you determine the
appropriate configuration. Part III is an SSU communications
check procedure.
These procedures assume that you know the optimum system con-
figuration for your facility, or that you have studied the applica-
tions chapter of this manual.
Before you install and configure your equipment, there are several
fundamental issues to consider
An AC outlet is required for the SSU. If there is more than one
piece of equipment in the rack, use a surge-protected power
distribution strip, fitted with an adequate extension cable.
Each SSU comes with a 3-wire, IEC power cable. The SSU is
fitted with an internally fused power supply, which operates
without adjustment over a wide range of conditions: 90-265 VAC,
50-60 Hz.
Installation
3-1
