DATE:
09/11/95
MODEL:
Micro Lynx
REVISION:
All
SERIAL NO:
All
SOFTWARE:
All
REQUIRED TOOLS:
Static safe workstation
Grounding wrist strap
REQUIRED PARTS:
TimeLine Part Number 71B015, Micro Lynx VITC Option Card
PROCEDURE:
1. Turn off the power and place the Micro Lynx System Unit on a static safe
workstation. Ground yourself and the workstation anti-static mat.
2. On the back of the System Unit, remove the cover labeled
3. Remove the six phillips screws securing the top cover to the System Unit.
4. Position the System Unit so that the front panel faces you, and remove the top cover.
If your Micro Lynx System Unit Serial Number is 1024 or higher, you have new metal work. The
new metal work does not require the Option Card Bracket. Please turn to Page Four of this
ECC No. 763
Phillips screwdriver
1/4" Nut driver
installation guide for instructions on installing the VITC Card.
Micro Lynx VITC Option Card
VITC READER
Note:
Page 1
Installation Guide
1755 LA COSTA MEADOWS DRIVE, SUITE B
SAN MARCOS, CA 92069
TEL. 760-761-4440
(FAX 760-761-4449)
SUPPORT@DIGAUDIO.COM
.
73632 REV. C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TimeLine Micro Lynx VITC Option Card
Summary of Contents for TimeLine Micro Lynx VITC Option Card
- Page 1 Grounding wrist strap 1/4" Nut driver REQUIRED PARTS: TimeLine Part Number 71B015, Micro Lynx VITC Option Card PROCEDURE: 1. Turn off the power and place the Micro Lynx System Unit on a static safe workstation. Ground yourself and the workstation anti-static mat.
- Page 2 Micro Lynx VITC Option Card PROCEDURE (continued): Install the Option Card Bracket 5. The Back Panel PCB is located at the top back of the chassis, horizontal to the back panel. Remove the "L" shaped bracket supporting the Back Panel PCB by removing the phillips screws;...
- Page 3 Micro Lynx VITC Option Card 10. Place the VITC Card under the lip on the mounting bracket and slide against the back panel so that the jacks are seated in the appropriate cutouts VITC IN VITC THRU in the back panel. Insert the washers and nuts onto the BNC connectors.
- Page 4 Micro Lynx VITC Option Card PROCEDURE (continued): 11. Insert the three phillips screws through the VITC Card into the Option Card bracket, as shown in Figure 3, and tighten. Figure 3. Securing the VITC Card 12. Insert the Option Card cable connector into J1 on the VITC board.
- Page 5 Micro Lynx VITC Option Card PROCEDURE (continued): Install the VITC Option Card (New Metal Work) 5. Locate and remove the black rubber bumper on the corner of the VITC Card. 6. The VITC Card is mounted to the left of the Main Board, component side up. The VITC Card will lie flat in the chassis.
