Evolveo Salvarix Quick Start Manual

Salvarix
wireless emergency SOS button

Description

Button with two modes of attachment makes it very comfortable to wear. You can hang the
button around your neck with a pendant, add it to your key case, or hang it in an available
place. The button can also be attached to the wrist with a wristband, making it always at
hand. After pressing the button, an SOS signal is sent and the control panel transmits this
signal to your mobile phone via an alarm. This button is suitable for children, seniors, sick
and immobile users. It is easy to operate and thanks to the quick response of the control
panel it can serve as an assistant in health protection. Another possibility of use is for
shops and other environments where there is a risk of robbery.

Control

To pair with the control panel, follow the same procedure as for pairing the remote
controller. More in the control panel manual.
When the button is pressed, an SOS signal is sent immediately. To deactivate the SOS
alarm, deactivate the control panel or disarm it with the remote controller.

Parameters

Power supply: 1x 27 A 12 V
Range: up to 100 m in open space
Frequency: 433 Mhz
Operating temperature: -20 °C to +40 °C
Max. humidity: 90 % without condensation

Battery replacement

Check the battery level regularly, at least once every three months. To replace the battery,
unscrew the two screws on the bottom of the cover. Carefully remove the cover parts.
Remove the discharged battery and insert new one. Maintain the polarity indicated to avoid
damage to the device.

Disposal

The symbol of crossed out container on the product, in the literature or on the packaging means
that in the European Union all the electric and electronic equipment, batteries and accumulators
must be placed in separate waste after the end of their service life. Do not throw these products
into the unsorted municipal waste
