  • Page 1 DETECTIVE S4CIH7D DVR security monitoring system with four cameras User's Manual (EN)

  • Page 2: Production Introduction

    1 Production Introduction 1.1 Product overview The series DVR is designed especially for security and defense field which is an outstanding digital surveillance product. It introduces embedded LINUX operating system which is more stable. It introduces standard H.264mp video compressed format and G.711A audio compressed format which insures the high quality image, low error coding ratio and single frame playing.

  • Page 3: Open-Package Check And Cable Connections

     through USB interface such as USB equipment, removable hard disk and so on  through net download the files in the hard disk Playback  individual real-time video recording as well as searching, playback, network surveillance, recording check, downloading and so on ...

  • Page 4: Hard Disk Installation

    product type and serial number in the label. 2.2 Hard disk installation For the first use, please install the hard disk, this machine box can install two hard disk (no limited capacity). For the first use，please install the hard disk. 1.

  • Page 5: Rear Panel

    (1) IR remote receiver (2) Power indicator light (3) Previous file (4) HDD indicator light (5) Next file (6) PTZ (7) Slow play (8) HDD Info (9) Fast play (10) Backward pause (11) Record (12) Play and Pause (13) Function switch (14) Search video (15) USB (16) ESC...

  • Page 6: Full Connectivity Diagram

    2.5 Full Connectivity Diagram 2.6 Audio and video input and output connections 2.6.1 Video input connections The video input port is BNC connector plug. The demand of input signal is PAL/NTSC BNC(1.0V ,75Ω). The video signal must be accorded with the state standard which has the high signal to noise ratio, low aberration and low interference.

  • Page 7: Video Output Connections And Options

    transmit by fiber to insure the signal quality. The video signal line should be away from the electromagnetic Interference and other equipments signal lines. The high voltage current should be avoided especially. Insure the connection stable and credible The signal and shield lines should be firm and connected credible which avoid false and joint welding and oxidation.

  • Page 8: Ptz Connections

    3. Use fitment materials that absorb the sound to reduce reflection of the sound. 4. Adjust the layout of the sound box and the tone arm. 2.7 PTZ connections 1. PTZ decoder connections A. The grounding of the PTZ decoder and DVR must be shared otherwise the common-mode voltage will lead to the PTZ control failure.

  • Page 9: Basic Operation

    3 Basic operation Note: Any buttons that are displayed in gray indicates it is not supported. 3.1 Preview Picture3.1 4 Channel Preview You can right click your mouse to switch between the windows. The system date, time, channel name, surveillance video, and the alarm status are shown in each window.

  • Page 10: System Login

    3.2 System Login When the DVR boots up, the user must login and the system provides the corresponding functions with the user purview. There are two user settings. The names are admin, default and these names have no password default. admin is the super user purview;...
  • Page 11 Picture 3.2 Shortcut Menu 3.3.1 Main menu When you login, the system main menu is shown as below. Picture 3.3 Main Menu - 91 -...

  • Page 12: Record Control

    3.3.2 Guide Include IPONE APP/Android APP download link QR-CODE,and DVR ID number QR-CODE. 3.3.3 Record Control Please check current channel status: “○” means it is not in recording status, “●” means it is in recording status. You can use desktop shortcut menu or click [main menu]> [recording function]>...
  • Page 13 【Stop】Click the stop button and the according channel stops recording no matter the channel in any state. 3.3.4 Playback There are two methods for you to play the video files in the hard disk. 1. In the desktop shortcut menu. Main menu>Record->Playback - 93 -...
  • Page 14 Picture 3.4 video playback - 94 -...
  • Page 15 (1) Playback (2) Operation hint (3) Record (4) Time interval control mode choosing (5) Switch by time, (6) File searching (7) Channel (8) Date choosing file mode choosing (9) Storage device (10) File (11) Listed (12) Time searching choosing information files 【Listed files】Look up the listed files that accord with the searching criteria.
  • Page 16 button. The system can operate accurate playback play according to the searching time. Local zoom： You can drag your mouse in the screen to select a section and then left click mouse to realize local zoom. Double left click to exit. Note: The storage drive must be installed before the file can be backed-up.

  • Page 17: Ptz Control

    Picture 3.7 Recording backup Remove：Clear file information. Add：Show file information meeting the set file attributes. Start/Pause：Click the play button to start the backup and click the pause button to stop the backup. Cancel： During backup you can exit the page layout to carry out other functions.

  • Page 18: Special Functions

    Picture 3.10 PTZ setup 【Speed】Set the PTZ rotation range. Default range: 1 ~ 8. button to adjust the zoom multiple of the camera. 【Zoom】Click button to add and delete preset. 【Preset】Click button to adjust the iris of the camera. 【Iris】Click 【Hide】Current interface will be temporarily hidden after click it.
  • Page 19 preset Delete preset Edit Call preset preset Picture 3.11 Preset Settings 2. Tour between Points Multiple preset points connected cruise lines, call cruise between points, the PTZ run around on the line 1）Tour Between Points Settings Tour lines is connected by multiple preset points, setting procedure is as follows: Step 1: In Picture 3.12, Click to add one tour, click Settings button to...
  • Page 20 Tour Add tour Setup Run one tour Picture 3.12 Tour Between Points preset Delete preset Picture 3.13 Tour Between Points Settings - 100 -...
  • Page 21 2）The Calls of tour between Points Select tour number, click to call tour Pattern Setup pattern Picture 3.14 pattern Set camera move as a pattern, not all camera support this function Auto scan Call autoscan Picture 3.15 Scan Setup - 101 -...
  • Page 22 Other Picture 3.16 Auxiliary Function Control 【Intuitive Auxiliary Operation】 choose auxiliary equipment, select Open or Close button, switch control； 【 Auxiliary Number 】 The operation of corresponding auxiliary switch according to PTZ agreement； Picture 3.17 Camera menu Control Enter cmaera menu, not all camera support. - 102 -...

  • Page 23: Alarm Output

    3.3.6 Alarm output Please check current channel status: “○” means it is not in alarming status, “●” means it is in alarming status. You can use desktop shortcut menu or click [main menu]> [alarm function]> [alarm output] to enter the alarm output interface. Picture 3.9 alarm output 【Configuration】Alarm is on according to the configuration.

  • Page 24: Output Adjust

    Picture 3.18 Color Setting 3.3.8 Output Adjust Adjust TV output area parameters. You can use the desktop shortcut menu or enter [main menu]> [management tools]> [Output adjust]. Picture 3.19 Output Adjust - 104 -...

  • Page 25: Window Switch

    3.3.9 Logout Logout, shut down the system or reboot up. You can use the desktop shortcut menu or enter [main menu]. Picture 3.20 Logout/Shutdown/Reboot the system 【logout】Quit the menu. Offer password next entrance. 【shut down】Quit the system. Turn off the power supply. When press the shut down button, there is schedule hint.

  • Page 26: Main Menu Navigation

    4 Main menu 4.1 Main menu navigation Main menu Sub menu Function Record Config Set the recording configuration, recording type, recording time section playback Set recording search, recording play, video file storage backup Detect backup device, format device, back the selective files Alarm Motion...
  • Page 27 System General Set system time, data format, language, hard configuration configuration disk full time operation, machine number, video format, output mode, summertime, stay time Encode Set main (extra) coding parameter: code configuration mode, resolving ability, frame rate, code stream control, image quality type, code stream value, frame between value, video/audio enable, Network...
  • Page 28 Online user Break the connection with the already login user. Lock the account after break until booting up again. Output adjust Adjust upside, downside, nearside, starboard distance, black margin vertical & horizontal Automatic Set automatic reboot system and automatic maintenance deleting files.

  • Page 29: Record Configuration

    4.2.1 Record Configuration Set the recording parameters in the surveillance channel. The system is set 24 hours consecutive recording in the first startup. You can enter [main menu]> [recording function]> [recording setup] to set. Note: There is at least one read-write hard disk. Picture 4.1 Record Configuration 【Channel】Choose the corresponding channel number to set the channel.

  • Page 30: Alarm Function

    alarm)and time section. Manual:Click the button and the according channel is recording no matter the channel in any state. Stop:Click the stop button and the according channel stops recording no matter the channel in any state. 【Period】Set the time section of common recording, The recording will start only in the set range.
  • Page 31 Pic 4.4 【Channel】Choose the set motion detect channel. 【Sensitivity】Choose in the six options according to the sensitivity. 【Region】 Click [set] to enter the set area. Red block means the motion detect defensive area. White block means the unfenced area. You can set the area as followed, Drag the mouse and draw the area.
  • Page 32 Picture 4.5 Region 【Period】Trigger the motion detect signal in the set time section. You can set according to week or set uniformly. Each day is divided into four time sections.■ means the set valid. Picture 4.6 set the time section 【Interval】Only one alarm signal is turned on even there are several motion detect signals in the set interval.
  • Page 33 The range is 10~300 seconds. 【Record channel】 Choose the recording channel (multiple option supportive). Trigger the video signal when the alarm is turned on. Note: Set in the [recording setup] and perform the linkage recording. Start detecting video files in the corresponding time section. 【Tour】■...

  • Page 34: Video Blind

    4.3.2 Video Blind When the video image is influenced by the environment such as bad brightness or reaching the set sensitivity parameter, the camera mask function is turned on and the linkage function is turned on. Pic 4.8 Video blind Set method: refer to chapter 4.3.1.

  • Page 35: Alarm Input

    Pic 4.9 Video loss Set method: refer to chapter 4.3.1. Motion detect 4.3.4 Alarm input When the equipment obtains the external alarm signal, the alarm function is turned on. Note: "Advanced" button is the same as right click. - 115 -...
  • Page 36 Pic 4.10 Alarm input Set method: refer to chapter 4.3.1. Motion detect 4.3.5 Alarm output - 116 -...
  • Page 37 4.3.6 Abnormality Analysing and inspecting current software and hardware of the device: When some abnormal events happen, the device will make a relative answer such as show message and buzzer. Picture 4.11 Abnormal 【Event Type】selecting abnormity you want to inspect 【Enable】Select it to make sure abnormal function workable 【Show message】Automatically alarm cue dialog box come out of the main screen...

  • Page 38: System Setup

    【Mobile reported】push alarm message to mobile phone 【Send email】 send alarm email 4.4 System setup Set the system parameters such as General, Encode, Network, Net service, Display, PTZ configure, RS232, Tour setup, Digital. 4.4.1 General Picture 4.17 General setup 【System time】Set the system data and time. 【Date format】Choose the data format: YMD, MDY, DMY.

  • Page 39: Encode Setup

    corresponding DVR number is matched, the remote operation is valid. 【Video Standard】PAL or NTSC. 【Auto Logout】Set the latency time in 0-60. 0 means no latency time. 【Machine Name】Can setting the device's name. 【DST】 Choose the summer time option and pop the dialog box as followed. Picture 4.18 DST (week) Picture 4.19 DST (date) 4.4.2 Encode setup...
  • Page 40 Picture 4.20 Encode setup Independent channel code setting 【Channel】Choose the channel number. 【Compression】Standard H.264 main profile. 【Resolution】Video resolution. 【Frame Rate】P:1 frame/s~25 frame/s; N: 1 frame/s~30 frame/s 【Bit Rate Type】You can choose limited code stream or variable code stream. When you choose the variable code stream there are six image quality options. under the limited code stream，you can choose the code stream manually；...

  • Page 41: Network Setup

    enable video & audio. The resolution, frame rate, bit rate type settings is the same as main stream. 4.4.3 Network setup Picture4.21 Network 【DHCP Enable】Obtain IP address automatically(not suggested) 【IP address】Set the IP address. Default: 192.168.1.10. 【Subnet mask】Set the subnet mask code. Default: 255.255.255.0. 【Gateway】Set the default gateway.
  • Page 42 and fluency precedence. Fluency precedence and self-adaption are valid only when the assistant code stream is turned on. Otherwise image quality precedence is valid. 4.4.4 NetService Choose the network service option and click the set button to configure the advanced network functions or double click the service button to configure the parameters.
  • Page 43 Picture 4.23 PPPOE Enable：Reverse means choose, setting can become effective. Input the user name and password that ISP（Internet service provider） provides. After saving it reboot up your system. Then the DVR will build a network connection based on PPPoE. The IP address will change into dynamic IP address after above operation is well done.
  • Page 44 If the alarm is turned on or the alarm linkage photos are taken, send an email about the alarm information and the photos to appointed address. Picture 4.25 EMAIL SMTP server: Email server address. It could be an IP address or domain name. Domain name can be translated only it is the correct DNS configuration.
  • Page 45 time, the black list precedence is higher. Picture 4.26 IP FILTER 【DDNS】 Picture 4.27 DDNS setup It is the abbreviation of dynamic domain name server. Local domain name：Provide the domain name registered by DDNS. User name：Provide the account registered by DDNS. Password：Provide the password registered by DDNS.
  • Page 46 FTP is available only when alarm happens, or alarm activates record and snapshot, it will upload related record and snapshot pictures to FTP server. Picture 4.28 FTP setup 【Enable】Click Enable, then all settings will be available IP address for FTP server 【Server IP】...
  • Page 47 Picture 4.33 UPNP 【Enable】Choose Enable to make sure all UPNP settings available 【HTTP】 Route will automatically distribute HTTP port for the device, when IE viewing, it need this port 【TCP】Router will automatically distribute TCP port for the device, when monitoring via CMS, it need this port. 【Mobile Port】Router will automatically distribute Mobile Port for the device.
  • Page 48 Pic 4.35 RTSP setting 【Port】：the default port is 554 【Cloud】 【Enable】The user can enter http://xmeye.net to login device by serial number. Pic 4.29 cloud Enable this function, When you want to visit the DVR on internet, needn’t manually map port in router. - 128 -...
  • Page 49 【PMS】 When DVR get alarm, DVR send alarm message to mobile. 4.4.5 Display Configure the video output parameters including the front output mode and encode output mode. Front output：In the local preview mode include: channel title, time display, channel display, record status, alarm status, transparency and region cover. Encode output：In the network surveillance and video file mode include: channel title, time display, channel display, record status, alarm status, transparency and region cover.
  • Page 50 Pic 4.36 output mode 【Channel Title】Click the channel name modify button and enter the channel name menu. Modify the channel name. The 16 Chinese characters and 25 letters are supportive. 【Time Display】means the selective state. Display the system data and time in the surveillance window.

  • Page 51: Ptz Config

    enter the corresponding channel window. You can cover the arbitrary using mouse. (Black region is for output) 【Time display】and 【Channel display】 set the display position of channel title and time title. 4.4.6 PTZ config Pic 4.37 PTZ configure 【Channel】Choose the dome camera input channel. 【Protocol】...
  • Page 52 4.4.7 RS232 Pic 4.39 serial port setting 【Serial Port Function】Common serial port is used to debug and update program or set up specific serial port. 【Baud rate】Choose the corresponding baud rate length. 【Data bits】Include 5-8 options. 【Stop bits】Include 2 options. 【Parity】Include odd, even, mark, space, default is none.
  • Page 53 Pic 4.40 tour configure 【MD interval】Set the patrol switch interval. The set range is 5-120 seconds. 【Return after finished】After alarm, back to tour. 4.4.9 Digital Digital manage including digital channel, channel status, and channel mode - 133 -...
  • Page 54 Pic 4.42 channel manage interface Channel mode: - 134 -...
  • Page 55 4.5 Advanced Manage tools menu including: HDD manage, account manage, online user, output adjust, auto maintain, upgrade. 4.5.1 HDD Manage Configure and manage the hard disk. The menu displays current hard disk information: hard disk number, input port, type, status and overall capability. The operation include: setup the write-read disk, read-only disk, redundant disk, hard disk format, resume default.
  • Page 56 user team name. The blank ahead or behind the character string is invalid. The middle blank in the character string is valid. Legal characters include: letter, number, underline, subtraction sign, dot. 2. There is no limit in the user and user group. You can add or delete the user group according to user definition.
  • Page 57 Pic 4.48 modify password 【Add user】Add a user in the group and set the user purview. Enter the menu interface and input the user name and password. Choose the team and choose whether cover using the user. Cover using means that the account can be used by multiple users at the same time.
  • Page 58 Pic 4.49 Add User 【Add Group】Add a user group and set the purview. There are 33 different purviews: shut down the equipment, real time surveillance, playback, record setting, video backup and so on. Pic 4.50 add group 【Delete User】Delete the current user. Choose the user and click delete user button.

  • Page 59: Online User

    Pic 4.51 Delete Group 4.5.3 Online user To check the information of network user that connected with local device, also can tick the selected user to break up connection, then the user will be frozen after connection stopped, and will not log in until device reboot. Pic 4.52 online user - 139 -...

  • Page 60: Auto Maintain

    4.5.4 TV adjust 4.5.5 Auto Maintain The user can set the time to auto reboot and auto delete file. Picture 4.39 Auto maintain 4.5.6 Restore The system restore to the default . You can choose the items according to the menu.
  • Page 61 Pic 4.54 restore to default 4.5.7 Upgrade Pic 4.55 Upgrade 【Upgrade】choose USB interface. 【Upgrade file】choose the upgrade file. - 141 -...

  • Page 62: Device Info

    4.5.8 Device Info Provide device interface info like audio in, alarm in/out to be conveniently used for user. Pic 4.56 device info 4.5.9 Import / Export Users can export the log info and the configure file from device to connected flash stick, and also can import related configure file from flash stick to settings, which greatly bring convenience to the customers.
  • Page 63 4.57 Import / Export interface 4.6 Info Display the hard disk information, including HDD info, code stream statistic, log info, version info 4.6.1 HDD info Display the hard disk state: hard disk type, overall capability, residual capability, the recording time and so on. - 143 -...
  • Page 64 Pic 4.58 HDD info 4.6.2 BPS Display the code stream （Kb/S） and hard disk capability （MB/H） in real time. It displays as the wave sketch map. - 144 -...
  • Page 65 Pic 4.59 BPS 4.6.3 LOG To search log information base on the set search mode. Log information include: system operation, configuration operation, data management, alarm affair, recording operation, user management, file management and so on. Set the time section to look up and click the look up button.
  • Page 66 Pic: 4.60 Log information 4.6.4 Version Display the basic information such as hardware information, software version, issue date, serial number, NAT status and so on. Pic 4.61 version information - 146 -...

  • Page 67: Shut Down System

    4.7 Shut down system 5 FAQ 5.1 FAQ 1. The DVR can not boot up normally. Possible reasons are as followed: The power supply is not correct. Switch power supply line is not in good connection. Switch power supply is damaged. The program updating is wrong.
  • Page 68 the DVR. The hardware of the DVR is damaged. 3. System can not detect hard disk. Possible reasons are as followed: The hard disk power supply line is not connected. The cables of the hard disk are damaged. The hard disk is damaged. The SATA port of main board is damaged.
  • Page 69 Possible reasons are as followed: The image quality is too bad. The reading program is wrong. Reboot up the DVR. The data line of the hard disk is damaged. The hard disk is damaged. The hardware of the DVR is damaged. 8.
  • Page 70 reflection otherwise the PTZ control is not stable. The distance is too far. 12. The motion detect is not working, Possible reasons are as followed: The time range set is not correct. The motion detect area set is not correct. The sensitivity is too low.
  • Page 71 MAC address is conflicted. The net card of the DVR is bad. 16. There is something wrong with the USB backup or writing a CD. Possible reasons are as followed: The rewritable machine and the hard disk are shared the same data lines.

  • Page 72: Maintenance

    longer) to protect the hard disk. Please keep the DVR away from heat resource. Please keep the DVR ventilated for better heat radiator. 5.2 Maintenance 1. Please ensure the system is grounded to prevent video or audio signal interference and the DVR from static or inductive electricity. 2.

  • Page 73: Appendix 1. Remote Control Operation

    Appendix 1. Remote control operation Serial number Name Function Multi-window button Split screens button Numeric button Code input/number input/channel switch Exit button 【Esc】 Direction button Up, Down, Left, Right and Enter/Menu button. Record control Control the record Record mode Enter short menu as “record mode”...

  • Page 74: Appendix 2. Mouse Operation

    Appendix 2. Mouse operation The USB ports support mouse operations. NOTE: Units with front and rear mouse USB ports can only utilize one port at a time – if a USB device is connected to one of the ports the other is automatically deactivated.

  • Page 75: Appendix 3. Hard Disk Capability Calculation

    Appendix 3. Hard disk capability calculation Verify the following when installing the hard drive in the DVR for the first time: Hard disk capacity There is no limit for recording machine. We recommend 120G~ 250G sizes to keep better stability. Overall capacity option The hard disk capacity formula is: Overall capacity（M）= channel number*time（hour）*capacity in an hour（M/hour）...
  • Page 76 DETECTIVE S4CIH7D www.evolveo.eu...
