Buhler Round Bale Carrier 1500 Specification Sheet

Round Bale Carrier Specifications
MODEL
Shipping weight (approx.)
Hitch weight
Transportation width
Deck length / overall length
Hydraulics:
• Lift cylinder
• Tilt cylinder
Tires
Tractor requirements
Hand held remote control
Capacity
1500
2,498 kg (5,495 lb)
Empty vertical drawbar load 6,071N (1,365lbf )
2.6 m (8.5')
11.3 m (37') / 13.4 m (44')
Two double acting circuits required
One - 3" diameter
One - 3" diameter
Hydraulic motors: (two) 22.0 cu.in
(Four) 12.5L x 15FI tires, load range F,
intermittent unloaded highway use
Capacity: 2,130 kg (4,680 lb) at 90 PSI inflation
Hub: 6 bolt with twine guard
Wheel: heavy-duty implement style
45 kW (60 HP) at 5,660 kg (12,480 lb)
Maximum recommended speed when loaded is
32 km/hr (20 mph)
Power: 12v
Fuse: 15 amp
GVW: 8,491 kg (18,720 lb)
Eight - 4' wide bales
Seven - 5' wide bales
2500
4,252 kg (9,375 lb)
Empty vertical drawbar load 10,653N (2,395lbf )
3.9 m (12.75')
11.3 m (37') 13.7 m (45')
Two double acting circuits required
Two - 3" diamether
Two - 3" diameter
Hydraulic motors: (four) 22.0 cu.in
(Eight) 12.5L x 15FI tires, load range F,
intermittent unloaded highway use
Capacity: 2,130 kg (4,680 lb) at 90 PSI inflation
Hub: 6 bolt with twine guard
Wheel: heavy-duty implement style
60 kW (80 HP) at 11,340 kg (25,000 lb)
Maximum recommended speed when loaded is
32 km/hr (20 mph)
Power: 12v
Fuse: 15 amp
GVW: 16,983 kg (37,440 lb)
Sixteen - 4' wide bales
Fourteen - 5' wide bales
