Summary of Contents for Buhler Landscape Rake FK349
-
Page 3: Table Of Contents
TABLE OF CONTENTS DESCRIPTION WARRANTY... 1 INTRODUCTION ... 2 SAFETY... 2 Safety ... 2 General Safety ... 3 Start Up Safety ... 3 Operation Safety ... 3 Transport Safety ... 3 Service and Maintenance Safety ... 3 Storage Safety... 4 Safety Signs ... -
Page 4: Warranty
Land Rake WARRANTY POLICY Buhler Manufacturing products are warranted for a period of twelve (12) months (90 days for commercial application) from original date of purchase, by original purchaser, to be free from defects in material and workmanship under correct, normal agricultural use and proper applications. -
Page 5: Introduction
The Buhler Farm King Land Rake is available in 5’, 6’, 7’ & 8’ models. The rake swivels to five positions. The shank bar has welded wedges to maintain spacing. Optional gauge wheels are available. This product is also quick hitch compatible. Keep this manual handy for frequent reference. -
Page 6: General Safety
Read and understand the Operator’s Manual and all safety signs before operating, servicing, adjusting, repairing, or unplugging the equipment. Do not attempt any unauthorized modifications to your Buhler product as this could affect function or safety, and could affect the life of the equipment. Inspect and clean the working area before operating. -
Page 7: Storage Safety
Store the unit in an area away from human activity. Do not permit children to play on or around the stored machine. Support the frame on stands and blocks to provide a secure base. The following illustration shows the approximate location and detail of safety signs. Keep all safety signs clean and legible and replace any that are damaged or missing. -
Page 8: Start-Up Instructions
START-UP Park on a dry level area clear of debris. Stop engine and set brake after lowering the three point arms so they line up with the mounting pins on the blade. Mount the lower lift pins first and then adjust the rake angle using the turnbuckle on the top link. -
Page 9: Operating Instructions
Clear the area of bystanders and foreign objects before starting. Use the float position on the three-point control to follow the contour of the ground. The weight of the blade will keep it down. Maintain a speed that allows you to maintain control of your machine. The 1”... -
Page 10: Parts Drawings
Land Rake MAINTENANCE... -
Page 11: Land Rake Parts List
WHEN ORDERING PARTS Always give your dealer the Model, Color and Serial Number of your machine to assist him in ordering and obtaining the correct parts. Use the exploded view and tabular listing of the area of interest to exactly identify the required part. ITEM PART # F0351... - Page 12 902277 Stand 901435 1/2" x 2 1/2" Clevis Pin (pl) 81626 1/2" x 2 3/4" Hex Bolt NC (pl) 961012 Hair Pin Clip #16 812364 1/2" Lock Nut (pl) 966729 3/16" Linch Pin (pl) 81593 3/8" Lock Washer (pl) 81592 3/8"...
-
Page 13: Shipping Kit And Bundle Numbers
SHIPPING KIT AND BUNDLE NUMBERS The following is a list of Kit Numbers for this product and the Bundle Numbers, Descriptions, and Quantities for each Kit. QUANTITY BUNDLE NO. Y60RR 60” LAND RAKE F0351 F0362 F6557 F0364 Y72RR 72” LAND RAKE F0351 F0362 F6558... - Page 14 NOTES...
- Page 16 (604) 864-2665 AB, Edmonton (780) 962-6991 SK, Regina (306) 781-2300 ON, Woodstock (519) 539-0435 QC, Dorion (450) 455-4840 Buhler Manufacturing 301 Mountain Street S. Morden MB. R6M 1X7 Ph.: (204) 822-4467 Fax: (204) 822-6348 www.buhler.com U.S. WAREHOUSES AR, West Memphis...
