LG Remote Jack Pack Mounting Bracket
Models: HX632-LG-RJP, HX637-LG-RJP, HX642-LG-RJP
MODEL
HX632 LG RJP
HX637 LG RJP
HX642 LG RJP
Before you begin, make sure all parts shown are included with your product.
Parts may appear slightly different than illustrated.
Parts List
Description
mounting bracket
A
B
LG Remote Jack Pack (RJP 202B)
M4 x 35 mm socket pin screw
C
M4 x 35 mm socket pin
D
serrated washer head screw
1/4" aluminum spacer
E
F
4 mm security allen wrench
A
Visit the Peerless Web Site at www.peerlessmounts.com
LG DISPLAY
COMPATIBILITY
32LC5DC
32LC50C
37LC5DC
37LC50C
42LC5DC
42LC50C
Qty.
HX632-LG-RJP
1
090-T1744
1
600-0068
2
520-1097
2
510-1097
2
560-0204
560-9646
1
B
1 of 2
HX637-LG-RJP
HX642-LG-RJP
090-T1745
090-T1746
600-0068
600-0068
520-1097
520-1097
510-1097
510-1097
560-0204
560-0204
560-9646
560-9646
C
F
ISSUED: 07-22-08 SHEET #: 120-9053-1
For customer care call 1-800-865-2112 or 708-865-8870.
E
D
