SFA Sanifast ZH190 Operating & Installation Manual

Grey water pump

Download this manual

XXX

SaniX

11.2020

Sanifast

The SaniX is a compact grey water lifting

station designed for light - medium

commercial use. The unit is designed to

receive and pump away waste water from

a washing machine, kitchen sink, dishwasher,

bath, shower or basin.

ZH190 Commercial Grey Water Lifting Station

395 x 233 x 389mm (W x H x D)

50mm

Up to 10 meters

Up to 100 meters

40-90°C (Short period)

220 - 240 V / 50 Hz

850 W

DN25

Included

3.7A

White

2 years

Optional external vent connection

URATION AND DIMENSIONS

Grey water pump • Operating/installation manual

PAGE 1

Need help?

Do you have a question about the Sanifast ZH190 and is the answer not in the manual?

Page 1 water pump SaniX 11.2020 Sanifast The SaniX is a compact grey water lifting station designed for light - medium commercial use. The unit is designed to receive and pump away waste water from a washing machine, kitchen sink, dishwasher, bath, shower or basin. ZH190 Commercial Grey Water Lifting Station 395 x 233 x 389mm (W x H x D) 50mm...
Page 2 1. SAFETY DISCONNECT ELECTRICAL POWER BEFORE WORKING ON THE PUMP ! Plumbers/Contractors, please ensure a copy of the installation instructions is left with the end user for future reference. 2. RECOMMENDEND USE The Sanifast is a compact grey water lifting station designed for light - medium commercial use. The unit is designed to receive and pump away waste water from a washing machine, kitchen sink, dishwasher, bath, shower or basin.
Page 3 4. INSTALLATION • The lifting station should be installed to allow full access in the event that servicing or removal is required. • The unit must be located on the same floor as the fittings it is to service. • All incoming pipework must have a constant gradient of 1:40. •...
Page 4 5. COMMISSIONING • Once ALL connections are secure and before you switch the power on, run the cold water tap for short period and allow water to enter the pump. • Then switch the power to the pump ON. Your pump should immediately activate and begin discharging into the discharge pipe system.
