Crestron Eye-12 Manual

Partner: WolfVision
Model: Eye-12/14, VZ-3/3s/8light
xNEO/9P³/9.4L/9.4F/C3D/C6/C12
Device Type: Document Camera
GENERAL INFORMATION
SIMPLWINDOWS NAME:
CATEGORY:
VERSION:
SUMMARY:
GENERAL NOTES:
CRESTRON HARDWARE REQUIRED:
SETUP OF CRESTRON HARDWARE:
VENDOR FIRMWARE:
VENDOR SETUP:
CABLE DIAGRAM:
CONTROL:
Power_On/Off/Toggle
Zoom_<Wide/Tele>
Focus_<Near/Far>
Auto_Focus_<On/Off/Toggle>
Iris_<Open/Close>
Auto_Iris_<On/Off/Toggle>
Iris_Priority_<Auto/Manual/Toggle>
Image_Rotation_Off
WolfVision WolfProt TCP-IP v1.2
Camera
1.2
This module provides TCP-IP control of the WolfVision Document Cameras.
This module provides TCP-IP control of the WolfVision Eye-12 and VZ-9.4F. It should
also control the EYE-14, the VZ-3/3s, VZ-8light
#1008068 and higher, VZ-9plus
serial number #1009412, VZ-C32 with serial number #1011797 and higher, VZ-
C12 and VZ-32 . Some commands are not be available on all models.
3 3
2 or 3-Series Processor with Ethernet
TCP/IP
Port Number: 50915
N/A
None
Ethernet
D Pulse to turn the document camera on and off.
Press and hold to adjust the camera's zoom. Once zoomed all the way in, releasing
D and pressing the Zoom_Tele again will cause the camera to zoom in farther using
the digital zoom.
D Press and hold to adjust the camera's focus.
D Pulse to turn the auto focus on and off.
D Press and hold to adjust the camera's iris.
D Pulse to turn the auto iris on and off.
D Pulse to set the iris priority to auto or manual.
D Pulse to turn the image rotation off.
/8plus /
4 4
/C32
3 3
4 /plus 4 , VZ-9plus with serial number
3 , VZ-9.4L, VZ-xNEO, VZ-C6, C3D, VZ-C12² with
