USE AND CARE GUIDE
LARSON 52 INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Visual instruction of how to install this fan:
Visit www.homedepot.com and enter either the Item or Model number to nd
this fan and click the link of visual instruction in the product overview section.
THANK YOU
Item #1004 707 786
#1004 678 175
#1004 677 290
Model #AL420-BN
#AL420-MWH
#AL420-ORB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LARSON AL420-BN and is the answer not in the manual?

Questions and answers

Summary of Contents for HAMPTON BAY LARSON AL420-BN

  • Page 1 #AL420-ORB USE AND CARE GUIDE LARSON 52 INCH CEILING FAN Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Visual instruction of how to install this fan: Visit www.homedepot.com and enter either the Item or Model number to nd...
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............Operation ..............Pull Chain Operating Instructions .......... Safety Information ............Reverse Switch Operating Instructions ........Warranty ................. Care and Cleaning ............Pre-installation .............. Troubleshooting ............Specifications ................Service Parts ............... Tools Required ................. Hardware Included ..............
  • Page 3: Safety Information

    Safety Information To reduce the risk of electric shock, ensure electricity has However, there is no guarantee that interference will not occur been turned off at the circuit breaker or fuse box before in a particular installation. If this equipment does cause harmful beginning.
  • Page 4: Warranty

    Warranty The manufacturer warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. The manufacturer warrants the light kit (excluding any glass), to be free from defects in workmanship and material at the time of shipment from the factory for a period of three years after the date of purchase by the original purchaser.
  • Page 5: Hardware Included

    Pre-Installation (continued) HARDWARE INCLUDED HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Part Description Description Quantity Quantity Blade attachment screw and fiber washer Plastic wire nut Canopy mounting screw (preassembled) Clevis pin (preassembled) Cotter pin (preassembled) Collar setscrews (preassembled) Blade arm screw and lock washer (preassembled) Light kit mounting screw (preassembled) Pull chain and fob...
  • Page 6: Package Contents

    Pre-Installation (continued) PACKAGE CONTENTS PACKAGE CONTENTS Part Part Description Description Quantity Quantity Part Part Description Description Quantity Quantity Mounting bracket (preassembled) Fan motor assembly Canopy Blade Canopy bottom cover (preassembled) Blade arm Hanger ball/downrod assembly Light kit Coupling cover Glass shade...
  • Page 7: Installation

    Installation MOUNTING OPTIONS MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain proper WARNING: To reduce the risk of fire, electric shock, or blade clearance when installing on a steep, sloped ceiling. personal injury, mount the fan to an outlet box marked The maximum angle allowable is 18°...
  • Page 8: Assembly

    Assembly Preparing the canopy Preparing the motor □ □ Remove the canopy bottom cover (C) from the canopy Remove the cotter pin (EE) and clevis pin (DD), and (B) by turning the canopy bottom cover (C) loosen the two collar setscrews (FF) from the motor counterclockwise.
  • Page 9: Hanging The Fan

    Assembly — Hanging the Fan Hanging the fan to the Installing the mounting bracket mounting bracket to the electrical box WARNING: To reduce the risk of fire, electric shock or WARNING: The tab in the ring must rest in the groove of other personal injury, mount the fan only to an outlet box or the hanger ball (D).
  • Page 10 Assembly — Hanging the Fan (continued) Making the electrical connections Ground WARNING: To avoid possible electrical shock, be sure conductor Neutral electricity is turned off at the main fuse box before wiring. Black White WARNING: Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire nuts (except for the ground wire).
  • Page 11 Assembly — Hanging the Fan (optional) Single Switch Connections Dual Switch Connections □ On a single switch the fan and light can be turned on or On a dual switch the fan and light can be turned on or off off together.
  • Page 12 Assembly — Hanging the Fan (continued) Attaching the canopy Installing the canopy bottom cover NOTE: Adjust the canopy mounting screws (CC) as WARNING: Make sure the tab on the mounting bracket (A) properly sits in the groove in the hanger ball (D) before necessary until the canopy (B) and canopy bottom cover (C) are snug.
  • Page 13: Attaching The Fan Blades

    Assembly — Attaching the Fan Blades Removing the rubber Attaching the blades to packing mounts the blade arms □ □ The fan motor assembly (F) is shipped with rubber Attach the blades (G) to the blade arms (H) using the packing mounts (QQ) to prevent movement during three blade attachment screws and fiber washers transportation.
  • Page 14: Installing The Light Kit

    Assembly — Installing the Light Kit Attaching the light kit to the Installing the light bulbs switch housing □ Install two 9 watt LED bulbs (NN) (included). WARNING: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at the fuse box.
  • Page 15 Assembly — Installing the Light Kit (continued) Installing the glass shade □ While holding the glass shade (J), slip the pull chain (UU) from the switch housing into the outside hole in the glass shade (J). □ Feed the pull chain (VV) from the light kit stem through the eyelet in the glass shade (J).
  • Page 16 Assembly — Installing the Light Kit (continued) Installing the fan without the light kit (Optional) □ Disassemble the switch housing cover (WW) from the light kit (I). You can keep the light kit for future use. □ Attach the plastic plug (MM) to the switch housing cover (WW).
  • Page 17: Operation

    Operation PULL CHAIN OPERATING INSTRUCTIONS PULL CHAIN OPERATING INSTRUCTIONS Install two pull chains and fobs (II) onto the pull chains located in the switch housing and light kit (I). Turn on the power and check the operation of the fan. The pull chain controls the fan speed as follows: 1 pull - High, 2 pulls - Medium, 3 pulls - Low and 4 pulls - Off.
  • Page 18: Care And Cleaning

    Care and Cleaning Do Do Do not Do not □ □ Check the support connections, brackets, and blade Use water when cleaning. Water could damage the motor, attachments twice a year. Make sure they are secure. or the wood, or possibly cause an electrical shock. Because of the fan’s natural movement, some □...
  • Page 19 Troubleshooting (continued) Problem Problem Solution Solution □ Verify that all blades and blade bracket screws are secure (most fan wobble problems are caused by loose parts). Once the fan is properly installed, run the ceiling fan for 10 minutes to let the fan self-adjust.
  • Page 20: Service Parts

    Service Parts Part Part Description Description Part Part Description Description Mounting bracket (preassembled) Canopy mounting screw (preassembled) Canopy Clevis pins (preassembled) Canopy bottom cover (preassembled) Cotter pin (preassembled) Hanger ball/downrod assembly Collar setscrews (preassembled) Coupling cover Blade arm screw and lock washer (preassembled) Fan motor assembly Light kit mounting screw (preassembled) Blade...
  • Page 21 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
