Bauknecht GSF 5466 Quick Reference Manual

GSF 5466
GB
Water supply indicator
Check the appliance fills with water.
Lower spray arm block indicator
Release the spray arm.
"Water stop" device indicator
"Water stop" device not working.
Switch off the dishwasher and shut off the
water tap.
Rinse aid level indicator
Add rinse aid.
Salt level indicator
Add regeneration salt; only add regeneration
salt immediately before starting a wash
programme.
Programme Symbol
and Temperature
Crockery to be washed later.
Pre-wash
Lightly soiled crockery with no dried-on food.
Rapid 40° C
Normally soiled crockery.
Bio-Eco 50° C
2)
Normally or heavily soiled crockery with dried-on food.
Bio-Normal 50° C
3)
Normally or heavily soiled crockery with dried-on food.
Normal 65° C
Heavily soiled pans and saucepans.
Intensive 70° C
1) Values may vary in relation to usage, e.g.: different loads,
water temperatures - above or below 15° C - as well as water hardness and power supply voltage.
2) Programme recommended when using detergents of type B (enzyme-based detergents). Reference programme for energy label.
3) Programme recommended when using detergents of type A (non enzyme-based detergents).
Quick Reference Guide
Further indications are given in the pages to follow and in the user instructions.
Programme progress indicator
Pre-rinse/Pre-wash
Washing
Options
Half Load button
This function can be used with any programme. The
indicator lamp switches on: the wash cycle is activated
for the upper or lower rack only.
Delayed start buttons
The wash cycle can be programmed to start after 1-24 hours.
Then press the Start button. The dishwasher will start at
the set time.
Programme selection and
recommended load type
Drying
Programme end
Place the detergent in the:
small large
compartment compartment
Water
(Litres)
- - 5.0
- X 13.0
- X 12.0
X X 16.0
X X 16.0
X X 21.0
(We reserve the right to make technical modifications)
Time and failure display
Indicates in hours the time remaining until the start of
the wash cycle. Switches off when the programme has
started. Toward the end of the programme, during the
drying cycle, the display will indicate the time remaining
in minutes.
"F1-F9" Identification of faults for the service technician.
Start button
Indicator lamp lit while the dishwasher is operating.
Flashes when a fault occurs.
Switches off at the end of the programme.
On / Off Button
1)
Consumption
Normal load / (Half load)
Energy Time
(kWh) (Min.)
(4.2) 0.02 (0.02) 9
(13.0) 0.85 (0.75) 30
(10.0) 1.25 (1.19) 73
(14.5) 1.24 (1.10) 91
(13.4) 1.55 (1.37) 86
(18.0) 1.68 (1.57) 93
5019 100 90231
(9)
(30)
(71)
(88)
(80)
(90)
