BORETTI ROBUSTO User Manual page 32

Step 3
Slide the gas valve through the opening on the front of the side table.
Fasten the indication ring to the gas valve by means of the 2x M4x8 screws supplied.
Indica�on ring
M4x8 screw
Control bu�on
Step 4
Position the side burner from the top and angle the burner in such a way that the
tube connects to the gas valve (the connection is not air tight). Then fasten the
side burner with two M4x8 screws, two M4 rings and two M4 nuts. Check that the
burner is firmly secured to the side table. Afterwards place pan stand on the side
burner in the corresponding holes.
Side burner
Pan stand side burner
M4x8 screw
M4 ring
M4 nut
31
