- Page 1 Built-in Oven User & Installation manual NV75T9549** NV8300T_NV75T9549CD_SW_DG68-01201C-00_EN.indd 1 2020-01-20 7:09:20...
-
Page 2: Table Of Contents
Contents Cooking Smart Using this manual Manual cooking The following symbols are used in this user manual Auto Cook programmes Safety instructions Special Function Test dishes Important safety precautions Collection of frequent Auto Cook recipes Correct Disposal of This Product (Waste Electrical & Electronic Equipment) Auto energy saving function Maintenance Installation... -
Page 3: Using This Manual
Using this manual Safety instructions Thank you for choosing SAMSUNG Built-In Oven. Installation of this oven must be performed only by a licensed electrician. The This User Manual contains important information on safety and instructions installer is responsible for connecting the appliance to the mains power supply in intended to assist you in the operation and maintenance of your appliance. - Page 4 Safety instructions The method of fixing stated is not to depend on the use of If this appliance has cleaning function, excess spillage must be adhesives since they are not considered to be a reliable fixing removed before cleaning and all utensils should not be left in means.
- Page 5 If your oven needs repair, contact damage to the enamel surface. a SAMSUNG Service center or your dealer. The oven door must be closed during cooking. Electrical leads and cables should not be allowed to touch the oven.
-
Page 6: Correct Disposal Of This Product (Waste Electrical & Electronic Equipment)
This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product-specific regulatory obligations, e.g. REACH, WEEE, Batteries, visit : samsung.com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/data_ corner.html... -
Page 7: Installation
Make sure all parts and accessories are included in the product package. If you Wire rack Wire rack insert * Baking tray * have a problem with the oven or accessories, contact a local Samsung customer centre or the retailer. Oven at a glance Universal tray *... -
Page 8: Power Connection
If installing the oven in a built-in cabinet, the cabinet must have its plastic surfaces Plug the oven into an electrical socket. If and adhesive parts resistant to temperatures in accordance to EN 60335. Samsung a plug-type socket is not available due to allowable current limitations, use a multi- is not responsible for damage to furniture from the oven’s heat emission. - Page 9 Oven (mm) Oven (mm) 495.5 Oven (mm) Built-in cabinet (mm) Min. 550 Min. 560 Min. 50 Min. 590 - Max. 600 Min. 460 x Min. 50 NOTE The built-in cabinet must have vents (E) to ventilate heat and circulate the air. English 9 NV8300T_NV75T9549CD_SW_DG68-01201C-00_EN.indd 9 2020-01-20...
- Page 10 Installation Under-sink cabinet (mm) Mounting the oven Make sure to leave a gap (A) of at least Min. 550 5 mm between the oven and each side of Min. 560 the cabinet. Min. 600 Min. 460 x Min. 50 NOTE •...
-
Page 11: Before You Start
Before you start After installation is complete, remove the protective film, tape, and other packing Control panel material, and take out the provided accessories from inside the oven. To remove The oven’s control panel features a full touch display, dial knob and touch buttons the oven from the cabinet, first disconnect power to the oven and remove 2 to control the oven. -
Page 12: Initial Settings
When you turn on the oven for the first time, the Welcome screen appears with Tap Next. the Samsung logo. Follow the on-screen instructions to complete the initial NOTE settings. You can change the initial settings later by accessing the Settings screen. -
Page 13: New Oven Smell
Soft closing door (gentle, safe, and silent) For better cooking experience, familiarise yourself with how to use each accessory. The Samsung Built-in Oven features a soft closing door that gently, safely, and silently closes. The wire rack is designed for grilling and roasting. - Page 14 Before you start Extra-deep tray * The extra-deep tray (depth: 50 mm) is used for Divider The divider is designed to separate the oven in two roasting with or without the wire-tray insert. Put zones. Use the divider with Dual cook mode. the slanted side to the front.
-
Page 15: Operations
Operations Oven modes Tap Cook Time to set the desired 12:00 cooking time. Conventional On the main screen, tap Convection 12:00 • Maximum cooking time is 200°C to select the desired cook mode. (For 23 hours and 59 minutes. Convection Fast Preheat On detailed information of each mode, see After setting the cooking time, select... - Page 16 Operations NOTE Temperature Default Fast Meat Mode range (°C) temperature (°C) Preheat probe • You can change the temperature, Fast Preheat option, and cooking time during cooking. 100-300 • During cooking, you can tap OFF and then OK to cancel cooking. The small-area grill emits heat.
-
Page 17: Dual Cook Modes
Dual cook modes Temperature Default Fast Meat Mode range (°C) temperature (°C) Preheat probe You can use the provided divider to separate the cooking chamber in the upper and lower zones. This allows users to enable two different cooking modes 30-275 simultaneously, or to simply choose one zone to cook with. -
Page 18: Cooking With The Meat Probe (Applicable Models Only)
Operations Cooking with the meat probe (applicable models only) Upper NOTE 12:00 Once you started cooking in the either The meat probe measures the internal temperature of meat while it’s cooking. Convection • When the temperature reaches the target temperature, the oven stops and finishes zone, you can tap the zone indicator on the top-middle of the screen and cooking. -
Page 19: Special Function
Special Function Set the desired cooking settings. 12:00 • Refer to “Oven mode descriptions” Convection On the main screen, tap Convection for the modes you can use the 12:00 and then Special Function. 50°C >>> 160°C meat probe. Convection • Refer to steps 1-3 of “Oven 30°C >>>... - Page 20 Operations Special Function description Tap Ready at to set the desired end 12:00 time. < Keep Warm Default Temperature • When you set the cooking time, 80°C Mode temperature Descriptions the oven displays the time cooking range (°C) 1hr 30min (°C) will end.
-
Page 21: Auto Cook
Auto Cook Select the weight. 12:00 • This step may not apply to some The oven offers 50 Auto Cook programmes. Take advantage of this feature to < Herb roasted lamb chops programs. save your time or shorten your learning curve. The cooking time, power level and •... -
Page 22: Favourites
Operations Favourites Renaming the favourite cook settings Touch the button on the control panel, and then tap Favourites. You can add up to 10 frequently used cook settings to the Favourites list to easily apply them in the future. On the Favourites screen, tap Tap Rename on the right side of the favourite cook setting you want to Adding the new cook settings to the Favourites rename. -
Page 23: Timer
Timer Deleting the Timer Touch the button on the control panel, and then tap Timer. Adding the new Timer On the Timer screen, tap Tap Delete on the right side of the Timer you want to delete. Touch the button on the control panel, and then tap Timer. On the Timer screen, tap Tap Done. -
Page 24: Cleaning
Operations Cleaning Settings Touch the button on the control panel, and then tap Settings to change various Steam Clean settings for your oven. Please refer to the following table for detailed descriptions. This is useful for cleaning light soiling with steam. Menu Submenu Description... -
Page 25: Lock
Menu Submenu Description Menu Submenu Description You can change the brightness of the display Volume You can adjust the volume of the oven. Brightness screen. Troubleshooting You can check the troubleshooting. You can turn the screen saver on or off. Help Guide for first You can check the simple instructions on basic... -
Page 26: Cooking Smart
Cooking Smart Manual cooking Baking We recommend to preheat the oven for best results. WARNING on acrylamide Type of Temp. Time Food Accessory Level Acrylamide produced while baking starch-contained food such as potato chips, heating (°C) (min.) French fries, and bread may cause health problems. It is recommended to cook Wire rack, these foods at low temperatures and avoid overcooking, heavy crisping, or Sponge cake... - Page 27 Type of Temp. Time Type of Temp. Time Food Accessory Level Food Accessory Level heating (°C) (min.) heating (°C) (min.) Wire rack, Poultry (Chicken/Duck/Turkey) Apple pie 160-170 65-75 Ø 20 cm tin Wire rack + Chicken, whole, Universal tray (to 60-80 * Chilled pizza Universal tray...
- Page 28 Cooking Smart Grilling Frozen ready-meal We recommend preheat the oven using Large Grill mode. Turn over after half of Type of Temp. Time time. Food Accessory Level heating (°C) (min.) Type of Temp. Time Frozen pizza, Food Accessory Level Wire rack 200-220 15-25 heating...
- Page 29 Pro-Roasting Dual cook Before using dual cook function insert the divider into the oven. We recommend This mode includes an automatic heating-up cycle up to 220 °C. The top heater preheat the oven for best results. and the convection fan are operating during the process of searing the meat. After The following table presents 5 dual cook guides we recommend for cooking, this stage the food is cooked gently by the low temperature of pre-selection.
- Page 30 Cooking Smart You can also use upper or lower zone only to save power. The cooking time can be Type of Temp. Time Zone Food Accessory Level extended when you use separated zone. We recommend preheat the oven for best heating (°C) (min.)
- Page 31 Eco Convection Meat probe (applicable models only) This mode uses the optimized heating system so that you save the energy during Type of food Core temperature (°C) cooking your dishes. The times of this category are suggested to not be preheated Rare 45-50 before cooking for saving more energy.
-
Page 32: Auto Cook Programmes
Cooking Smart Auto Cook programmes Food Weight (kg) Accessory Level 0.8-1.2 Wire rack CAUTION Prepare fresh vegetable gratin using an ovenproof dish, Foods that can easily spoil (such as milk, eggs, fish, meat, or poultry) should not Vegetable gratin 22-24 cm. Start programme, after preheating beep sounds, stand in the oven for more than 1 hour before cooking begins, and should be put dish on the centre of rack. - Page 33 Food Weight (kg) Accessory Level Food Weight (kg) Accessory Level 0.3-0.4 Universal tray 1.0-1.1 Universal tray Walnut bread Put apple puff pastries on baking paper on universal tray. Prepare dough as 4 pieces and distribute on the universal Apple puff pastry Start programme, after preheating beep sounds, put tray tray.
- Page 34 Cooking Smart Roast Food Weight (kg) Accessory Level We recommend fresh chilled meat, poultry and fish for better taste. We 0.7-0.8 Wire rack recommend thawing frozen ingredients thoroughly if you use the them. The auto Prepare cake batter and put into a black metal rectangular programmes don’t include the preheating and turning over.
- Page 35 Food Weight (kg) Accessory Level Food Weight (kg) Accessory Level Poultry Fish Wire rack 0.3-0.7 Universal tray 1.0-1.4 Trout fillet, baked Universal tray Put trout fillets with the skin side up on the universal tray. Chicken, whole Rinse and clean chicken. Brush chicken with oil and spices. Wire rack 0.3-0.7 Put it breast side down on the rack.
- Page 36 Cooking Smart Side Dishes Convenience The auto programmes don’t include the preheating. Use the fresh vegetables. The auto programmes don’t include the preheating. Use the frozen pre-cooked conveniences. Food Weight (kg) Accessory Level Food Weight (kg) Accessory Level 0.3-0.7 Universal tray 0.3-0.7 Universal tray Rinse and prepare slices of courgette, aubergine, pepper,...
- Page 37 Pizza & Dough Dual cook The Auto Cook programmes include preheating during baking and display the The following table presents 20 auto programmes for cooking, roasting and preheating progress. Start programme, after preheating beep sounds, insert food. baking. You can use only upper cavity or lower cavity and use the upper and lower Always use oven gloves while taking out food.
- Page 38 Cooking Smart Lower Food Weight (kg) Accessory Level 0.5-0.6 Universal tray Food Weight (kg) Accessory Level Put scones (5-6 cm diameter) on baking paper on universal 1.2-1.4 Wire rack Scones tray. Start programme, after preheating beep sounds, put Prepare apple pie using a 20-24 cm round metal baking Apple pie tray into the oven.
-
Page 39: Special Function
Special Function Food Weight (kg) Accessory Level 0.8-0.9 Wire rack Defrost Prepare dough and put into a black metal round baking Cheesecake This mode is used for defrosting frozen products, baking goods, fruit, cake, cream tin (20-24 cm). Start programme, after preheating beep and chocolate. -
Page 40: Test Dishes
Cooking Smart Test dishes Prove Dough This mode is used for proving the dough and making the homemade yogurt. According to standard EN 60350-1. Food Accessory Level Temp. (°C) Time (min.) 1. Baking Pizza dough Wire rack 30-40 30-40 The recommendations for baking refer to a preheated oven. Do not use the Fast Cake/Bread dough Wire rack, oven dish 30-40... -
Page 41: Collection Of Frequent Auto Cook Recipes
Collection of frequent Auto Cook recipes 2. Grilling Preheat the empty oven for 5 minutes using Large Grill function. Potato gratin Type of Temp. Time Type of food Accessory Level heating (°C) (min.) Ingredients 800 g potatoes, 100 ml milk, 100 ml cream, 50 g beaten whole White bread egg, 1 tbsp each of salt, pepper, nutmeg, 150 g grated cheese, Wire rack... - Page 42 Cooking Smart Lasagne Apple pie Ingredients 2 tbsp olive oil, 500 g minced beef, 500 ml tomato sauce, 100 ml Ingredients • Pastry: 275 g flour, tbsp salt, 125 g white castor sugar, beef stock, 150 g dried lasagne sheets, 1 onion (chopped), 200 g 8 g vanilla sugar, 175 g cold butter, 1 egg (beaten).
- Page 43 Quiche Lorraine Homemade pizza Ingredients • Pastry: 200 g plain flour, 80 g butter, 1 egg. Ingredients • Pizza dough: 300 g flour, 7 g dried yeast, 1 tbsp olive oil, • Filling: 75 g cubed fatless bacon, 125 ml cream, 125 g 200 ml warm water, 1 tbsp sugar and salt.
-
Page 44: Maintenance
Cooking smart Maintenance Herb roasted lamb chops Cleaning Ingredients 1 kg lamb chops (6 pieces), 4 large garlic cloves (pressed), 1 tbsp WARNING fresh thyme (crushed), 1 tbsp fresh rosemary (crushed), 2 tbsp • Make sure the oven and accessories are cool before cleaning. salt, 2 tbsp olive oil. - Page 45 Catalytic enamel surface (applicable models only) When done, follow steps 1 to 2 above in the reverse order to reinstall the The removable parts are coated with dark grey catalytic enamel. They can be door. Make sure the clips are hinged on soiled with oil and fat spattered by the circulating air during convection heating.
- Page 46 Maintenance Remove the second sheet from the door Ceiling (applicable models only) in the arrow direction. Put down the grill heater. For this, turn Clean the glass with soapy water and a the circular nut anticlockwise while clean cloth. holding the grill heater. The grill heater is not a removable part.
-
Page 47: Replacement
Use only 25-40 W / 220-240 V, 300 °C heat-resistant bulbs. You can purchase Clean both side racks. approved bulbs at a local Samsung service center. Always use a dry cloth when handling a halogen bulb. This is to prevent the •... -
Page 48: Troubleshooting
The power turns off • If continuous cooking • After cooking for a suggestions. If the problem continues, contact a local Samsung service centre. during operation. takes a long time long time, let the oven • If the cooling fan does cool. - Page 49 Problem Cause Action Problem Cause Action There is electricity • If the power supply is • Check whether the The oven does not • If the door is open • Close the door and coming from the not properly grounded power supply is heat.
-
Page 50: Information Codes
Button problem them. Turn off the oven and try C-d0 Occurs when a button is pressed and again. If the problem continues, held for a period of time. contact a local Samsung service centre. 50 English NV8300T_NV75T9549CD_SW_DG68-01201C-00_EN.indd 50 2020-01-20 7:09:28... -
Page 51: Technical Specifications
Technical specifications SAMSUNG strives to improve its products at all times. Both the design Code Meaning Action specifications and these user instructions are thus subject to change without notice. The divider must not be removed during cooking in Dual Connection voltage 230-240 V ~ 50 Hz cook mode. -
Page 52: Appendix
Priduca daaa sheea Energy saving tips • During cooking, the oven door should remain closed except for turning food SAMSUNG SAMSUNG over. Do not open the door frequently during cooking to maintain the oven temperature and to save energy. Model identification NV75T9549** •... -
Page 53: Open Source Announcement
It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-ROM; a minimal charge will be required. The following URL http://opensource.samsung.com/opensource/OVEN_R18_TZ4/ seq/0 leads to the download page of the source code made available and open source license information as related to this product. - Page 54 Memo NV8300T_NV75T9549CD_SW_DG68-01201C-00_EN.indd 54 2020-01-20 7:09:29...
