Built-in Oven
User & Installation manual
NV75K5541RS / NV75K5541RB / NV75K5541BS /
NV75K5541BB
NV75K5541RB_EU_ DG68-00745A-00_EN.indd 1
2016-01-26
6:50:49

Advertisement

Table of Contents
loading

Related Manuals for Samsung NV75K5541RS

Summary of Contents for Samsung NV75K5541RS

  • Page 1 Built-in Oven User & Installation manual NV75K5541RS / NV75K5541RB / NV75K5541BS / NV75K5541BB NV75K5541RB_EU_ DG68-00745A-00_EN.indd 1 2016-01-26 6:50:49...

  • Page 2: Table Of Contents

    Contents Cooking smart Using this manual Manual cooking The following symbols are used in this User Manual: Auto cook programmes Safety instructions Test Dishes Collection of frequent Auto cook recipes Important safety precautions Correct Disposal of This Product (Waste Electrical & Electronic Equipment) Maintenance Auto energy saving function Cleaning...

  • Page 3: Using This Manual

    Using this manual Safety instructions Thank you for choosing SAMSUNG Built-In Oven. Installation of this oven must be performed only by a licensed electrician. The This User Manual contains important information on safety and instructions installer is responsible for connecting the appliance to the mains power supply in intended to assist you in the operation and maintenance of your appliance.
  • Page 4 Safety instructions The method of fixing is not to depend on the use of adhesives The appliance and its accessible parts become hot during use. since they are not considered to be a reliable fixing means. Care should be taken to avoid touching heating elements. During use the appliance becomes hot.
  • Page 5 If your oven needs repair, contact trays or tins on it. The aluminum foil blocks the heat, which may result in damage a SAMSUNG Service center or your dealer. to the enamel surfaces and cause poor cooking results.

  • Page 6: Correct Disposal Of This Product (Waste Electrical & Electronic Equipment)

    Make sure all parts and accessories are included in the product package. If you of with other household waste at the end of their working have a problem with the oven or accessories, contact a local Samsung customer life. To prevent possible harm to the environment or human centre or the retailer.

  • Page 7: Power Connection

    (earthgrounding), which must be longer than the others. If Shashlik * you use a plug-type socket, the plug must remain accessible after the oven is installed. Samsung is not responsible for accidents caused by missing or faulty earthgrounding. NOTE Availability of accessories with an asterisk (*) depends on the oven model.

  • Page 8: Cabinet Mount

    If installing the oven in a built-in cabinet, the cabinet must have its plastic surfaces and adhesive parts resistant up to 90 °C, and adjacent furniture must be resistant Min. 560 up to 75 °C. Samsung is not responsible for damage to furniture from the oven’s Min. 50 heat emission.
  • Page 9 Mounting the oven After installation is complete, remove the protective film, tape, and other packing material, and take out the provided accessories from inside the oven. To remove Make sure to leave a gap (A) of at least the oven from the cabinet, first disconnect power to the oven and remove 5 mm between the oven and each side of 2 screws on both sides of the oven.

  • Page 10: Before You Start

    Before you start Initial settings Smart safety mechanism When you power on the oven for the first time, the default time of “12:00” appears If you open the door while the oven is operating, the oven light turns on and on the display where the hour element (“12”) blinks.
  • Page 11 Basic use Rotisserie spit Put the tray at rack position 1 to collect cooking juices, or For better cooking experience, familiarise yourself with how to use each accessory. and Shashlik * on the bottom of the oven for a large serving of meat. It is recommended to use the spit accessories for meat under Wire rack The wire rack is designed for grilling and roasting.

  • Page 12: Dual Cook Mode

    Before you start Operations Dual cook mode Control panel You can use both the upper and lower compartments to cook two different recipes, The front panel comes in a wide range of materials and colours. For improved or simply choose one compartment to cook with. quality, the actual appearance of the oven is subject to change without notice.

  • Page 13: Common Settings

    Common settings 10 Oven light Press to turn the internal light on or off. The oven light turns on automatically when the door is open It is common to change the default temperature and/or cooking time across all or when the oven operation starts. And it turns off cooking modes.
  • Page 14 Operations Cooking time End time 1. Turn the mode selector to choose a mode 1. Turn the mode selector to choose a mode or function. or function. 2. Press the button, and then turn the 2. Press twice, and turn the value dial to value dial to set a desired time up to 23 set a desired end time.
  • Page 15 Delay End To clear the cooking time Delay End is designed to make cooking more convenient. You can clear the cooking time. This is useful if you want to stop the oven manually at any time during the process. Case 1 1.

  • Page 16: Cooking Modes (Except For Grill)

    Operations Cooking modes (except for Grill) To clear the end time You can clear the end time. This is useful if you want to stop the oven manually at 1. Turn the mode selector to select an any time during the process. cooking mode.
  • Page 17 Dual cook mode The oven starts preheating with icon until the internal temperature reaches the You can use the provided divider to separate the cooking chamber in the upper target temperature. and lower compartments. This allows users to enable two different cooking modes Preheating is recommended for all cooking simultaneously, or to simply choose one compartment to cook with.

  • Page 18: Cooking Modes (Grill)

    Operations Cooking modes (Grill) Temperature range (°C) Suggested Mode temperature Dual 1. Turn the mode selector to select Single (°C) Upper Lower * 40-250 40-250 Bottom heat + The bottom heating element generates heat, which is convection evenly distributed by the convection fan. Use this mode 2.

  • Page 19: Dual Cook Mode Temperature Setting Range

    Dual cook mode temperature setting range Dual cook mode Grilling with Dual cook mode is useful for small serving sizes to save power. By You can use both the upper and lower compartments simultaneously for different default, only the Large grill option in the upper compartment is available because cooking operations.

  • Page 20: To Stop Cooking

    Operations To stop cooking Upper compartment is limited to (°C)) If Lower is set to (°C) Minimum Maximum While cooking is in process, turn the mode selector to “ ”. The oven turns off in a few seconds. This is because, to avoid accepting incorrect commands by users, the oven waits a few seconds so that they can correct their selection.

  • Page 21: Special Function

    Special function Auto cook Add special or additional functions to improve your cooking experience. Special For inexperienced cooks, the oven offers a total of 50 auto cooking recipes. Take functions are not enabled in Dual cook mode. advantage of this feature to save you time or shorten your learning curve. The cooking time and temperature will be adjusted according to the selected recipe.

  • Page 22: Steam Cleaning

    Operations Steam cleaning Dual cook mode 1. Insert the divider in level 3 to activate This is useful for cleaning light soiling with steaming. This function saves you time by removing the need for regular manual cleaning. The remaining time appears on Dual cook mode.

  • Page 23: Timer

    Timer WARNING Do not open the door before the cycle is complete. The water inside the oven is Timer helps you check the time or operating duration while cooking. very hot, and it can cause a burn. 1. Press NOTE •...

  • Page 24: Cooking Smart

    Cooking smart Manual cooking Baking We recommend to preheat the oven for best results. WARNING on acrylamide Type of Food Accessory Level Temp. (°C) Time (min.) Acrylamide produced while baking starch-contained food such as potato chips, heating French fries, and bread may cause health problems. It is recommended to cook Wire rack, 160-170 35-40...
  • Page 25 Type of Type of Food Accessory Level Temp. (°C) Time (min.) Food Accessory Level Temp. (°C) Time (min.) heating heating Apple pie Wire rack, 160-170 65-75 Poultry(Chicken/Duck/Turkey) Ø 20 cm tin Chicken, Whole, Wire rack + 80-100 Chilled pizza Universal tray 180-200 5-10 1.2 kg*...
  • Page 26 Cooking smart Grilling Frozen ready-meal We recommend preheat the oven using large grill mode. Turn over after half of Type of time. Food Accessory Level Temp. (°C) Time (min.) heating Type of Frozen pizza, 0.4- Wire rack 200-220 15-25 Food Accessory Level Temp.
  • Page 27 Pro-Roasting ECO convection This mode includes an automatic heating-up cycle up to 220 °C. The top heater This mode uses the optimized heating system so that you save the energy during and the convection fan are operating during the process of searing the meat. After cooking your dishes.
  • Page 28 Cooking smart Dual cook You can also use upper or lower compartment only to save power. The cooking Before using dual cook function insert the divider into the oven. We recommend time can be extended when you use separated compartment. We recommend preheat the oven for best results.

  • Page 29: Auto Cook Programmes

    Auto cook programmes Code Food Weight (kg) Accessory Level 1.2-1.5 Wire rack Single cook Put ingredients for Ratatouille in casserole dish with The following table presents 40 auto programmes for cooking, roasting and Ratatouille lid. Start programme, after preheating beep sounds, baking.
  • Page 30 Cooking smart Code Food Weight (kg) Accessory Level Code Food Weight (kg) Accessory Level 0.3-0.5 Universal tray 0.7-0.8 Wire rack Prepare rolls (chilled ready dough). Put on baking paper Prepare dough using a 20-24cm ovenproof dish. Start A 12 Bread rolls A 19 Brownies on Universal tray.
  • Page 31 Code Food Weight (kg) Accessory Level Code Food Weight (kg) Accessory Level 0.9-1.1 0.3-0.5 Wire rack + Universal tray Universal tray 1.1-1.3 0.5-0.7 A 32 Sole A 26 Chicken, whole Rinse and clean chicken. Brush chicken with oil and Put Sole on baking paper on the universal tray. Cut spices.
  • Page 32 Cooking smart Dual cook Code Food Weight (kg) Accessory Level The following table presents 10 auto programmes for cooking, roasting and 0.3-0.6 baking. You can use only upper cavity or lower cavity and use the upper and lower Wire rack cavity at the same time.

  • Page 33: Test Dishes

    Test Dishes Code Food Weight (kg) Accessory Level According to standard EN 60350-1 0.3-0.5 Universal tray Frozen oven 0.5-0.7 chips 1. Baking The recommendations for baking refer to a preheated oven. Do not use the fast Distribute frozen oven chips evenly on tray. preheat function.

  • Page 34: Collection Of Frequent Auto Cook Recipes

    Cooking smart Collection of frequent Auto cook recipes 2. Grilling Preheat the empty oven for 5 minutes using Large Grill function. Potato gratin Type of Temp. Type of food Accessory Level Time (min.) heating (°C) Ingredients 800 g potatoes, 100 ml milk, 100 ml cream, 50 g beaten whole Wire rack White bread egg, 1 tbsp each of salt, pepper, nutmeg, 150 g grated cheese,...
  • Page 35 Lasagne Apple pie Ingredients 2 tbsp olive oil, 500 g minced beef, 500 ml tomato sauce, 100 Ingredients • Pastry: 275 g flour, tbsp salt, 125 g white castor sugar, 8 g ml beef stock, 150 g dried lasagne sheets, 1 onion (chopped), vanilla sugar, 175 g cold butter, 1 egg(beaten) 200 g grated cheese, 1 tsp each of dried parsley flakes, oregano, •...
  • Page 36 Cooking smart Quiche Lorraine Homemade pizza Ingredients • Pastry: 200 g plain flour, 80 g butter, 1 egg Ingredients • Pizza dough: 300 g flour, 7 g dried yeast, 1 tbsp olive oil, 200 • Filling: 75 g cubed fatless bacon, 125 ml cream, 125 g crème ml warm water, 1 tbsp sugar and salt fraiche, 2 eggs, beaten, 100 g grated cheese from Switzerland, •...

  • Page 37: Maintenance

    Maintenance Cleaning Rack of Pork rib Ingredients 2 racks pork spare ribs, 1 tbsp black peppercorns, 3 bay leaves, WARNING 1 onion (chopped), 3 garlic cloves (chopped), 85 g brown sugar, • Make sure the oven and accessories are cool before cleaning. 3 tbsp Worcestershire sauce, 2 tbsp Tomato puree, 2 tbsp olive •...
  • Page 38 Maintenance Door Door glass Do not remove the oven door unless for cleaning purposes. To remove the door for Depending on the model, the oven door is equipped with 3-4 sheets of glass cleaning, follow these instructions. placed against each other. Do not remove the door glass unless for cleaning purposes.
  • Page 39 WARNING If you encounter a water leak from the water collector, contact us at a local 01 Water collector Samsung service center. 01 Support clip 1 02 Support clip 2 Ceiling (applicable models only) 03 Support clip 3 1.

  • Page 40: Replacement

    • Use only 25-40 W/220-240 V, 300 °C heat-resistant bulbs. You can purchase 4. Clean both side runners. approved bulbs at a local Samsung service center. 5. When done, follow steps 1 to 2 above • Always use a dry cloth when handling a halogen bulb. This is to prevent the...

  • Page 41: Troubleshooting

    If you encounter a problem with the oven, first check the table below and try the The oven exterior • If the oven is installed • Keep the gaps specified suggestions. If the problem continues, contact a local Samsung service centre. is too hot during in a place without good in the product installation operation.
  • Page 42 Troubleshooting Problem Cause Action Problem Cause Action Cooking is finished, • The fan automatically runs • This is not a product The oven does not • If the door is often • Do not frequently open but the cooling fan for a certain amount of malfunction, so there is no cook properly.

  • Page 43: Information Codes

    Button problem them. Turn off the oven and try C-d0 Occurs when a button is pressed and again. If the problem continues, held for a period of time. contact a local Samsung service centre. English 43 NV75K5541RB_EU_ DG68-00745A-00_EN.indd 43 2016-01-26 6:51:02...

  • Page 44: Appendix

    75 L 34 L 32 L Type of oven Built-in NV75K5541RS / NV75K5541RB: 41.0 kg Mass of the appliance(M) NV75K5541BS / NV75K5541BB: 40.6 kg Data determined according to standard EN 60350-1 and Commission Regulations (EU) No 65/2014 and (EU) No 66/2014.
