POWERSPORTS
OWNER'S MANUAL
Never allow any child under the age of 13 to operate this Mini
Bike. Persons age 13 to 16 should operate this mini bike only
under continual adult supervision.
Provincial / Municipal governments have different regulations
pertaining to owning and operating an off-road vehicle, learn the
regulations in your area.
(888)-405-8725 Coleman Powersports
1775 E. University Dr. 85281
www.colemanpowersportsusa.com
RB200
061120

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RB200 and is the answer not in the manual?

Questions and answers

Related Manuals for Coleman Powersports RB200

Summary of Contents for Coleman Powersports RB200

  • Page 1 Bike. Persons age 13 to 16 should operate this mini bike only under continual adult supervision. Provincial / Municipal governments have different regulations pertaining to owning and operating an off-road vehicle, learn the regulations in your area. (888)-405-8725 Coleman Powersports 1775 E. University Dr. 85281 www.colemanpowersportsusa.com...
  • Page 2 Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust , carbon monoxide, phthalates, and lead, which are known to the state of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service...
  • Page 3 To the Owner Congratulations on your purchase of a Coleman Powersports Off-Road Mini Bike. This Owner’s/Operator’s manual will provide you information regarding safe operation, operational instructions, maintenance and care. Fully understanding this manual and following all of the instructions herein will provide the knowledge needed to have safe and enjoyable operation.
  • Page 4 The second part will describe WHAT COULD HAPPEN if the warning or caution is ignored. Coleman Powersports is concerned about the environment and believes in conserving and protecting all natural resources. For this reason, owners should recycle, trade in, or dispose as appropriate, oil and tires.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS COLEMAN POWERSPORTS WARRANTY.. 2 AIR FILTER........18 IMPORTANT SAFETY LABELS....4 SPARK PLUG........19 LOCATION ........4 ENGINE OIL ........20 LABELS......... 5 CHECKING......20 SAFETY ..........6 CHANGING......20 DESCRIPTION AND PART LOCATIONS... 7 DESCRIPTION AND PART FUNCTIONS..

  • Page 6: Coleman Powersports Warranty

    90 days from the date of purchase shown on the sales receipt. During this period of time Coleman Powersports will, at its option, either repair, refund purchase amount, or replace any original Coleman Powersports unit/part which is covered by this warranty and is proven to be defective in workmanship or material.
  • Page 7 5. Any product which has been altered or modified in a manner not consistent with the original design of the product or in a manner not approved by Coleman Powersports. 6. Tires 7.

  • Page 8: Important Safety Labels

    IMPORTANT LABELS LOCATION...

  • Page 9: Labels

    • Check the throttle to ensure it works properly and FOR SERVICE AND REPAIR, PLEASE "snaps back" prior to starting the mini bike. CALL COLEMAN POWERSPORTS • be seated before attempting to start the mini bike. TOLL FREE 888-405-8725 • continually supervise children...

  • Page 10: Safety

    SAFETY This Mini Bike is recommend- Never traverse, climb or go ed for riders 13 and older. down a hill that is too steep. Avoid hills with loose or Always wear a certified DOT slippery terrain. motorcycle type helmet that fits properly, over the ankle Never attempt wheelies, boots, eye protection, gloves,...

  • Page 11: Description And Part Locations

    DESCRIPTIONS AND PART LOCATIONS 1. 1. Rear Fender 2. 2. Seat 3. 3. Air filter assembly 4. 4. Fuel Tank and Cap 5. 5. Front Fender 6. 6. Front Wheel 7. 7. Starter Recoil Cord 8. 8. Fuel Valve 9. 9. Choke Lever 10.

  • Page 12: Description And Part Functions

    DESCRIPTION AND PART FUNCTIONS Throttle Grip : The engine speed is regulated by the position of the right throttle grip. Throttle is increased by turning the throttle grip toward the operator. Engine speed is decreased by turning the throttle grip away from the operator.

  • Page 13: Choke Operation

    DESCRIPTION AND PART FUNCTIONS Choke operation Choke Lever (1): If the engine is cold, the choke can help start the engine by placing the choke lever to the “ON” (left) position. Once engine has warmed up, place choke lever to the “OFF” (right) position. Fuel Valve operation Fuel Valve (2): To start the engine and run the mini bike, the fuel valve needs to be...

  • Page 14: Fuel And Oil

    FUEL AND OIL FUEL WARNING Never use leaded gasoline in this product. It could affect the engine’s Fuel and fuel vapor are highly emissions and damage the engine. flammable and toxic. You can Mini Bike requires clean unleaded be burned or poisoned while regular gasoline with a minimum octane rating of 86 or higher.

  • Page 15: Pre Ride Inspection

    PRE-RIDE INSPECTION Inspecting and checking the condition of WHAT CHECK FOR the Mini Bike before each ride is important. Following the pre-ride check CHECK list will help insure the you do not have mechanical problems which could result in Steering • Smoothness injury or becoming stranded.

  • Page 16: Riding Mini Bike

    RIDING THE MINI BIKE HELMET, EYE PROTECTION, PROTECTIVE CLOTHING Always wear a DOT or SNELL certified motorcycle helmet (1). A helmet helps protect against serious head injuries in the event of an accident. A helmet is the most important safety gear item you can wear. Consult with a motorcycle dealer for the correct size and type of motorcycle helmet that is right for you.

  • Page 17: Starting The Engine

    RIDING THE MINI BIKE STARTING ENGINE To start the engine 1. Place the fuel valve (1) in the “ON” (right) position. 2. If engine is cold, place the choke lever (2) in the “ON” (left) position. 3. Place the ON/OFF switch (3), located on the handlebars, in the (on)position.

  • Page 18: Starting Off

    RIDING THE MINI BIKE STARTING OFF 1. Start and warm up the engine according to the instructions in this manual. 2. Place the side kick stand in the up position. WARNING 3. Apply the throttle gradually to Removing hands from the handle- start riding.

  • Page 19: Load Guidelines

    For Mini Bike could become affected. Some questions, contact your dealer. accessories may make the Mini Bike unsafe to ride. If you have a question about a modification or accessory, contact your dealer or call Coleman Powersports.

  • Page 20: Maintenance

    MAINTENANCE For maintenance, your mini bike may be maintained by an authorized Coleman Powersports service dealer or a repair shop of your choosing. Following the proper maintenance CAUTION procedures and time table for maintenance listed in this manual is Failing to perform recommended...

  • Page 21: Maintenance Chart

    MAINTENANCE CHART Every20 Every Every hours of First 5 operation hours of hours hours or 1 operation Before ITEM or 3 or 6 month each ride months months Exhaust pipe nuts and muffler bolts Air cleaner element Valve Clearance** Spark Plug Fuel Line Idle speed Condition of throttle and...

  • Page 22: Air Filter

    MAINTENANCE Air Filter CAUTION The air cleaner element needs to be Clean air filter frequently if Mini cleaned or replaced periodically (see chart Bike is driven in wet, muddy or for cleaning/replacement intervals). The dusty conditions. air filter element will need to be cleaned more often if Mini Bike is ridden in muddy, Driving in the above conditions wet, or dusty conditions.

  • Page 23: Spark Plug

    MAINTENANCE Spark Plug This Mini Bike comes equipped with a F6TC spark plug. To inspect the spark plug, remove the air filter cover and element to gain access. Remove spark plug cap (1) then remove the spark plug from the engine with the spark plug tool provided.

  • Page 24: Engine Oil

    MAINTENANCE Engine Oil WARNING The proper amount and grade of engine oil will have a great impact on the life of the engine. Checking New and used oil can be the oil daily and changing the oil as hazardous listed in the maintenance schedule is the most important maintenance Children and pets can be procedure for the engine.

  • Page 25: Throttle Cable Adjustment

    MAINTENANCE Throttle Cable adjustment It is important that the throttle grip have a .078 - .24 in certain amount of free play so the throttle does not rise when the handlebars are (2-6 mm) turned from left to right. The hand grip throttle free play (2) should be .078 - .24 in (2-6 mm) To adjust free play WARNING...

  • Page 26: Brakes

    MAINTENANCE BRAKES This Mini Bike is equipped with rear hydraulic disk brakes WARNING Failing to inspect brakes before each use could be hazardous Inspect brakes before each use according to the pre- ride check list, make sure to follow the maintenance schedule and procedures.

  • Page 27: Chain And Sprocket

    MAINTENANCE Chain Chain lubrication Chain and Sprocket Lubricating the chain before each ride will help to ensure maximum life Inspection of the chain and sprockets. Inspect the drive chain for wear, rust, bound links, proper lubrication and Instructions for cleaning proper tension.

  • Page 28: Cleaning And Lubrication

    MAINTENANCE Centrifugal Clutch Cleaning and lubrication To help ensure the maximum life out of the Centrifugal clutch. It is important to clean and lubricate the clutch after every 5 hours of operation. To Clean and lubricate, follow the instructions below 1.

  • Page 29: Tires

    MAINTENANCE Tires Inspect tires before each ride, this should include the following: 1. Inspect for cracks or leaks Minimum tread 2. Inspect tread depth. If tread depth is 4mm (.16 in.) below 4mm (.16 in.) replace the tire. 3. Check tire pressure. Incorrect tire pressure can affect the handling, rider comfort, steering, tire life and traction.

  • Page 30: Storage

    Storage If the Mini Bike is left unused for an extended period of time proper storage maintenance is required. 1. Wash Mini Bike thoroughly, then wax painted parts with a non abrasive auto wax. Coat vinyl seat and rubber parts with a vinyl/ rubber protectant.

  • Page 31: Washing The Mini Bike

    Washing the Mini Bike 1. Wash mud and dirt off Mini Bike with low pressure water from a hose. Do not use high pressure nozzles, this could allow water to enter the engine causing damage. 2. Wash Mini Bike using a mild detergent or car soap using a sponge, soft rag or brush.

  • Page 32: Troubleshooting

    TROUBLESHOOTING Trouble Possible cause Solution Engine will • Fill with fresh fuel • Low fuel not start • Have a service center flush and • Stale or contaminated fuel. fill with fresh fuel. • Fuel valve is in the “OFF” position •...

  • Page 33: Specifications

    SPECIFICATIONS Engine Tires Displacement 196cc Front Tire Size AT19x7-8 Starting Recoil Cord Rear Tire Size AT19x7-8 Spark Plug Type F6TC Cooling Air cooled Dimensions and Weights Ignition Type T.C.I Length 63.5in (1615mm) Cylinder head config. Number of Cylinder Single Height 36in.

  • Page 34: Frame And Engine Number Location

    FRAME AND ENGINE NUMBER LOCATION The Vehicle identification number and the engine number are needed when calling for parts, service center help or when registering your Mini Bike. Locate the numbers and list the numbers below for reference. VIN# The 17 digit Vehicle Identification Number (VIN) is located on the vertical tube on the neck of the mini bike Vehicle Identification Number...

  • Page 35: Emission Control System Warranty

    EMISSION CONTROL SYSTEM WARRANTY Below is the emission control system warranty printed in the owner’s manual, the copy of the owner’s manual is available upon your request. YOUR WARRANTY RIGHTS AND OBLIGATIONS The U.S. Environmental Protection Agency, and Tao Motor Inc. (hereinafter “Tao Motor”) are pleased to explain the emission control system warranty on your 2021 Model Year OFMC.
  • Page 36 If you use your vehicle in any type of sanctioned competitive event, this warranty is immediately and completely void. If you have any questions regarding your warranty rights and responsibilities, you should contact Tao Motor Inc., 2201 Luna Road, Carrollton, TX 75006,TEL: 972-512-8866 Tao Motor warrants that each new 2021 and later Tao Motor’s OFMC: A.
  • Page 37 III. Limited Liability A. The liability of Tao Motor under this emission control system warranty is limited solely to the remedying of defects in material or workmanship by an authorized Tao Motor’s dealer at its place of business during customary business hours. This warranty does not cover inconvenience or loss of use of the vehicle or transportation of the vehicle to or from the Tao Motor’s dealer.
  • Page 38 POWERSPORTS (888)-405-8725 Coleman Powersports 1775 E. Universtiy Dr . Tempe, AZ. 85281 www.colemanpowersportsusa.com www.facebook.com/Colemanpowersportusa www.instagram.com/colemanpowersports_usa...
