Media Card Reader

For information on using the Media Card Reader, see "Using a Media Card Reader (Optional)" on
page 20.

Removing a Media Card Reader

CAUTION:
Before you begin any of the procedures in this section, follow the safety instructions located in the
Product Information Guide.
NOTICE:
To prevent static damage to components inside your computer, discharge static electricity from your
body before you touch any of your computer's electronic components. You can do so by touching an unpainted
metal surface on the computer chassis.
1 Follow the procedures in "Before You Begin" on page 59.
2 Remove the drive panel (see "Removing the Drive Panel" on page 83).
*1
*
Not present on all computers.
1
2
Media Card Reader 2 cable
