- Page 1 Pos: null /BA_Module/BA_AA Deckblatt/BAAA000001_M003 @ 17\mod_1444211755814_28.docx @ 891110 @ @ 1 Installation Instructions ELEKTROMAT ST 80.15-50,00 Model: 10003374 00003 -en- Status: 06.03.2020 Pos: null /BA_Module/BA_Seitenumbruch @ 0\mod_1190719383361_0.docx @ 550 @ @ 1...
- Page 2 Pos: null /BA_Module/BA_CA Leerblatt/BACA000001_M002 @ 15\mod_1416821436083_28.docx @ 864410 @ @ 1 GfA ELEKTROMATEN GmbH & Co. KG Wiesenstraße 81 D-40549 Düsseldorf www.gfa-elektromaten.de info@gfa-elektromaten.de Pos: null /BA_Module/BA_Seitenumbruch @ 0\mod_1190719383361_0.docx @ 550 @ @ 1...
-
Page 3: Table Of Contents
Pos: null /BA_Module/BA_DA Inhaltsverzeichnis/BADA000001_M001 @ 0\mod_1192624580455_28.docx @ 710 @ @ 1 Table of contents General safety information ....................4 Technical Data ........................ 5 Mechanical installation ....................6 Electrical installation ..................... 10 Schematic of reversing contactor board ................ 12 ... -
Page 4: General Safety Information
Pos: null /BA_Module/BA_EA Sicherheitshinweise/BAEA000004_M003 @ 10\mod_1362389720702_28.docx @ 784840 @ 1 @ 1 1 General safety information Specified normal use The drive unit is intended for horizontally operating sliding doors. The safe operation is only guaranteed with specified normal use. The drive unit is to be protected from rain, moisture and aggressive ambient conditions. -
Page 5: Technical Data
Pos: null /BA_Module/BA_FA Technische Daten/BAFA001103_M001 @ 0\mod_1193237363659_28.docx @ 1290 @ 1 @ 1 2 Technical Data Type SG 115R Output torque Output speed Output shaft / hollow shaft 50,00 Maximum output speed open / close 26 / 26 for frequency inverter operation Maximum door weight 80000 Supply voltage... -
Page 6: Mechanical Installation
Pos: null /BA_Module/BA_GA Mechanische Montage/BAGA004301_M001 @ 10\mod_1365771756315_28.docx @ 788330 @ 1 @ 1 3 Mechanical installation Requirements The permissible loads on walls, mountings, connection and transmission elements must not be exceeded even for maximum holding or locking torque (▶ observe technical data). Connection elements ▶... - Page 7 Mounting 4 boreholes are provided for mounting. BAGAD0 4 3 0 1 _Z0 0 2...
- Page 8 Installation The following descriptions refer to a door which is not further defined. The door manufacturer's specifications must also be observed. Warning – Injury or danger to life possible! Use a lifting device with sufficient load-carrying capacity for installation tasks. ...
- Page 9 Warning – Injury or danger to life possible! Disconnect the electrical voltage for the setting of the slipping clutch. ▶ The slipping clutch acts as an overload BAGAE4 3 0 3 _Z0 0 2 protection. The factory setting for the tightening torque is 24Nm (ST 60) or 30Nm (ST 80).
-
Page 10: Electrical Installation
Pos: null /BA_Module/BA_HF Elektrische Montage WS905/BAHF061101_M001 @ 0\mod_1273059774879_28.docx @ 526823 @ 11 @ 1 4 Electrical installation Warning - Danger to life from electric current! Switch the mains OFF and check that the cables are de-energised Observe the applicable regulations and standards ... - Page 11 Performing electrical installation Remove the cover. Remove the cover. Open the cable conduit. Insert the mains supply cable. BAHFA07_Z001 BAHFF01_Z001 BAHFG01_Z001 Caution - Component damage can result! Use an appropriate tool to open the cable conduit. Sealing is ensured only if the hole in the cable conduit is smaller than the cable diameter.
-
Page 12: Schematic Of Reversing Contactor Board
5 Schematic of reversing contactor board BAHFH01_Z001 L1 L2 L3 Transformer 400 V AC, 230 V AC / 24 V A Terminal strip for the reversing contactor board Control fuse 6,3x32 0.5A, slow Functional wire-link Control fuse 6,3x32 0.5A, slow Transformer bridge Control fuse 5x20 0.5A, slow OPEN contactor... - Page 13 Wire link A: This wire link is used to control a magnetic interlock. Depending on the supply network, it can be connected between the following terminals: L4 and Br2 ≙ 3~400 V AC L4 and Br2 ≙ 3~230 V AC L4 and Br2 ≙...
- Page 14 Mains supply connection BAHFI01_Z001 Completing electrical installation Connect any control devices and/or safety devices. Mount the cable entries and/or cable glands. Pos: null /BA_Module/BA_Seitenumbruch @ 0\mod_1190719383361_0.docx @ 550 @ @ 1...
-
Page 15: Limit Switch Adjustment
Pos: null /BA_Module/BA_IA Endschaltereinstellung/BAIA061421_M001 @ 0\mod_1263474250872_28.docx @ 477630 @ 1 @ 1 6 Limit switch adjustment Adjust the limit switches to define the final limits positions for OPEN and CLOSE. Prerequisite The door must open when the OPEN pushbutton S11 of the reversing contactor board is operated. - Page 16 Check the position of the door: Close the door ① until the cam is free and open the door again ② at OPEN final limit position. Carry out fine adjustment to correct the OPEN final limit position. Check the door position after correction.
-
Page 17: Main Circuit
Pos: null /BA_Module/BA_JB Hauptstrom WS 905/BAJB001002_M001 @ 0\mod_1207730066248_28.docx @ 9430 @ 1 @ 1 7 Main circuit Functional wire-link Motor Fusing on the building supply side Main switch on building supply side F1-2 Control fuse 6.3x32 0.5A, slow Transformer Control fuse 5x20 0.5A, slow Connection cable Transformer bridge Motor plug... -
Page 18: Control Circuit
Pos: null /BA_Module/BA_KB Steuerstrom WS 905/BAKB100001_M001 @ 0\mod_1212473094846_28.docx @ 13920 @ 1 @ 1 8 Control circuit Motor temperature switch S10 Manual interlock safety switches Safety limit switch OPEN S11 OPEN pushbutton (PCB) Safety limit switch CLOSE S13 CLOSE pushbutton (PCB) OPEN operational limit switch X12 Terminal rail for reversing contactor CLOSE operational limit switch... -
Page 19: Motor Connection
Pos: null /BA_Module/BA_MA Motoranschluss/BAMA010034_M001 @ 0\mod_1210856551266_28.docx @ 9714 @ 1 @ 1 9 Motor connection Half-wave rectifier Motor Connection cable Motor / brake X13 Motor plug Magnetic brake Pos: null /BA_Module/BA_NA Endschalteranschluss/BANA001013_M001 @ 0\mod_1263371313853_28.docx @ 477048 @ 1 @ 1 10 Limit switch connection Thermal contact S10 Manual operation... -
Page 20: Connecting The Additional Limit Switch
Pos: null /BA_Module/BA_OB Zusatzendschalteranschluss WS 905/BAOB000002_M001 @ 0\mod_1228723611814_28.docx @ 132710 @ 1 @ 1 11 Connecting the additional limit switch The additional limit switches can be used in both directions of motion of the door. WS 905 Terminal rail X12 Limit switch board Auxiliary limit switch Auxiliary limit switch Connection cable... -
Page 21: Control Device Connections
Pos: null /BA_Module/BA_PA Befehlsgeräteanschluss/BAPA030001_M001 @ 0\mod_1265640856733_28.docx @ 493478 @ 1 @ 1 12 Control device connections ① Key-switch EMERGENCY OFF Key-switch Connection cable Motor / limit switch ② Key-switch with stop pushbutton Key-switch ③ Door control TS 950... - Page 22 ④ Key-switch ⑤ Key-switch with stop pushbutton ⑥ Door control TS 951 / TS 954 Pos: null /BA_Module/BA_Seitenumbruch @ 0\mod_1190719383361_0.docx @ 550 @ @ 1...
-
Page 23: Emergency Manual Operation (Emergency Hand Crank)
Pos: null /BA_Module/BA_UA Nothandbetätigung/BAUA000001_M003 @ 24\mod_1511866921360_28.docx @ 1061558 @ 1 @ 1 13 Emergency manual operation (emergency hand crank) The emergency manual operation is designed for opening or closing the door without power supply. Its activation interrupts the control voltage. Electrical operation is no longer possible. Warning –... - Page 24 Plug in the crank and turn until it engages (①). Open or close by turning the crank (②). After use, the crank may be attached to the drive unit. ▶ Attach as illustrated. Pos: null /BA_Module/BA_Seitenumbruch @ 0\mod_1190719383361_0.docx @ 550 @ @ 1...
-
Page 25: Completing Commissioning / Inspection
Pos: null /BA_Module/BA_WA Abschluss Inbetriebnahme/ Wartung/BAWA001222_M001 @ 2\mod_1306311084492_28.docx @ 673214 @ 1 @ 1 14 Completing commissioning / inspection Check the following components and then install all covers. Gearbox Check the drive unit for loss of oil (a few drops can be neglected). Protect the output-shaft permanently against corrosion. - Page 26 Brake Warning - Potential injury or danger to life! Carry out a brake test. Overrun depends on the door and its equipment. The specifications of the door manufacturer must be observed. In an environment that can affect the coefficient of friction of the brake pad (atmosphere with oil, solvents, detergents, etc.), class of protection IP65i must be adopted.
-
Page 27: Declaration Of Incorporation / Declaration Of Conformity
EMC Directive 2014/30/EU within the meaning of RoHS Directive 2011/65/EU The following requirements from Appendix I of GfA ELEKTROMATEN GmbH & Co. KG the Machinery Directive 2006/42/EC are met: declare under our sole responsibility that the 1.1.2, 1.1.3, 1.1.5, 1.2.2, 1.2.3, 1.2.6, 1.3.2,... - Page 28 === Ende der Liste für Textmarke Inhalt1 ===...
