Installation Instructions
ELEKTROMAT
ST 80.24-50,00
Model: 10003195 00001
Pos: null /BA_Module/BA_Seitenumbruch @ 0\mod_1190719383361_0.docx @ 550 @ @ 1
-en-
Status: 06.03.2020

Advertisement

loading
Need help?

Need help?

Do you have a question about the ELEKTROMAT ST 80.24-50,00 and is the answer not in the manual?

Questions and answers

Summary of Contents for GFA ELEKTROMAT ST 80.24-50,00

  • Page 1 Pos: null /BA_Module/BA_AA Deckblatt/BAAA000001_M003 @ 17\mod_1444211755814_28.docx @ 891110 @ @ 1 Installation Instructions ELEKTROMAT ST 80.24-50,00 Model: 10003195 00001 -en- Status: 06.03.2020 Pos: null /BA_Module/BA_Seitenumbruch @ 0\mod_1190719383361_0.docx @ 550 @ @ 1...
  • Page 2 Pos: null /BA_Module/BA_CA Leerblatt/BACA000001_M002 @ 15\mod_1416821436083_28.docx @ 864410 @ @ 1 GfA ELEKTROMATEN GmbH & Co. KG Wiesenstraße 81 D-40549 Düsseldorf www.gfa-elektromaten.de info@gfa-elektromaten.de Pos: null /BA_Module/BA_Seitenumbruch @ 0\mod_1190719383361_0.docx @ 550 @ @ 1...
  • Page 3: Table Of Contents

    Pos: null /BA_Module/BA_DA Inhaltsverzeichnis/BADA000001_M001 @ 0\mod_1192624580455_28.docx @ 710 @ @ 1 Table of contents General safety information ....................4     Technical Data ........................ 5     Mechanical installation ....................6     Electrical installation ..................... 10     Motor connection ......................11  ...
  • Page 4: General Safety Information

    Pos: null /BA_Module/BA_EA Sicherheitshinweise/BAEA000004_M003 @ 10\mod_1362389720702_28.docx @ 784840 @ 1 @ 1 1 General safety information Specified normal use The drive unit is intended for horizontally operating sliding doors. The safe operation is only guaranteed with specified normal use. The drive unit is to be protected from rain, moisture and aggressive ambient conditions.
  • Page 5: Technical Data

    Pos: null /BA_Module/BA_FA Technische Daten/BAFA001103_M001 @ 0\mod_1193237363659_28.docx @ 1290 @ 1 @ 1 2 Technical Data Type SG 115R Output torque Output speed Output shaft / hollow shaft 50,00 Maximum output speed open / close 42 / 42 for frequency inverter operation Maximum door weight 80000 Supply voltage...
  • Page 6: Mechanical Installation

    Pos: null /BA_Module/BA_GA Mechanische Montage/BAGA004301_M001 @ 10\mod_1365771756315_28.docx @ 788330 @ 1 @ 1 3 Mechanical installation Requirements The permissible loads on walls, mountings, connection and transmission elements must not be exceeded even for maximum holding or locking torque (▶ observe technical data). Connection elements ▶...
  • Page 7 Mounting 4 boreholes are provided for mounting. BAGAD0 4 3 0 1 _Z0 0 2...
  • Page 8 Installation The following descriptions refer to a door which is not further defined. The door manufacturer's specifications must also be observed. Warning – Injury or danger to life possible!  Use a lifting device with sufficient load-carrying capacity for installation tasks. ...
  • Page 9 Warning – Injury or danger to life possible!  Disconnect the electrical voltage for the setting of the slipping clutch. ▶ The slipping clutch acts as an overload BAGAE4 3 0 3 _Z0 0 2 protection. The factory setting for the tightening torque is 24Nm (ST 60) or 30Nm (ST 80).
  • Page 10: Electrical Installation

    Pos: null /BA_Module/BA_HA Elektrische Montage/BAHA190300_M001 @ 0\mod_1260284652159_28.docx @ 462982 @ 1 @ 1 4 Electrical installation Warning - Danger to life from electric current!  Switch the mains OFF and check that the cables are de-energised  Observe the applicable regulations and standards ...
  • Page 11: Motor Connection

    Pos: null /BA_Module/BA_MA Motoranschluss/BAMA010006_M001 @ 0\mod_1193124303992_28.docx @ 872 @ 1 @ 1 5 Motor connection BAMA010006_Z001 U1 V1 W1 Half-wave rectifier Motor X13 Motor plug Magnetic brake Pos: null /BA_Module/BA_NA Endschalteranschluss/BANA007002_M001 @ 0\mod_1263375075205_28.docx @ 477162 @ 1 @ 1 6 Limit switch connection BANA007002_Z001 Thermal contact Pos: null /BA_Module/BA_Seitenumbruch @ 0\mod_1190719383361_0.docx @ 550 @ @ 1...
  • Page 12: Completing Commissioning / Inspection

    Pos: null /BA_Module/BA_WA Abschluss Inbetriebnahme/ Wartung/BAWA000022_M001 @ 2\mod_1306311356433_28.docx @ 673256 @ 1 @ 1 7 Completing commissioning / inspection Check the following components and then install all covers. Gearbox Check the drive unit for loss of oil (a few drops can be neglected). Protect the output-shaft permanently against corrosion.
  • Page 13 Brake Warning - Potential injury or danger to life!  Carry out a brake test. Overrun depends on the door and its equipment. The specifications of the door manufacturer must be observed. In an environment that can affect the coefficient of friction of the brake pad (atmosphere with oil, solvents, detergents, etc.), class of protection IP65i must be adopted.
  • Page 14: Declaration Of Incorporation / Declaration Of Conformity

    EMC Directive 2014/30/EU within the meaning of RoHS Directive 2011/65/EU The following requirements from Appendix I of GfA ELEKTROMATEN GmbH & Co. KG the Machinery Directive 2006/42/EC are met: declare under our sole responsibility that the 1.1.2, 1.1.3, 1.1.5, 1.2.2, 1.2.3, 1.2.6, 1.3.2,...
