Delfield ST4464N-12M Specifications

ST4464N MEGA TOP
Front-Breathing Self-Contained Compact Mega Top Refrigerators
MODELS:
❑ ST4464N-12M Two section with doors
Twelve pan capacity
❑ ST4464N-18M
Two section with doors
Eighteen pan capacity
Model STD4464N-18M
SPECIFICATIONS
Exterior top is one-piece 22-gauge stainless steel with
integral 2.12" (5.1cm) square nosing on the front.
Telescoping lid is constructed of 20-gauge stainless steel.
Top opening can accept 12, 18 or 24 1/6 size plastic
pans 4"-6" (10.1cm-15.2cm) deep. Adapter bars and
1/6 size pans are supplied by Delfield. Temperature
in top openings maintains 33°F (1°C) to 41°F (5°C),
with pans recessed 2.5" (6.4cm) at 86°F ambient room
temperature, meeting NSF 7 requirements. One 64" x 8"
x .5" (162.9cm x 20.3cm x 1.3cm) polyethulene cutting
board treated with antimicrobial agent is mounted on the
top at the front edge.
Exterior back and bottom are two-piece 24-gauge
galvanized steel. Exterior ends are stainless steel.
Interior sides are thermoformed ABS plastic with
shelf supports. Base is fully insulated with high-density
foamed in place polyurethane.
❑ STD4464N-12M Two section with drawers
❑ STD4464N-18M Two section with drawers
STANDARD FEATURES
• Patented air screen ensures product stays cold without drying it out
• All 4400 Series units are 100% front breathing, which allows the
unit to be pushed against a wall or built into a cabinet or an existing
line up
• Durable, rugged stainless steel sides, top and front
• Features Delfield's exclusive ABS interior (on sides). ABS is
extremely durable - it won't dent, chip or corrode and is backed by
a limited lifetime warranty
• Delfield supplies 1/6 size pans and adapter bars for top opening
• Mega top refrigerators are standard with 8" wide, dishwasher safe
polyethylene cutting board treated with anitmicrobial agent
• "D" prefix models feature Delfield's new drawer system. Drawers
are backed by a 10-year warranty on the track assembly
• Environmentally friendly R404A refrigerant
• High density foamed in place polyurethane keeps energy costs low
• Black recessed quick grip handle
• Standard on 2" casters for easy cleaning and installation
• 7' cord and plug supplied
• Cord spring relief - prevents cord rollover
• One epoxy coated wire shelf standard, installed per door section
• ACT solid state electronic control
• "ST" models have a 4" stainless steel backsplash
• One year parts and 90 day labor standard warranty.
Refrigeration system uses HFC-404A refrigerant.
Compressor is 1/2 H.P., with condenser coil and hot gas
condensate evaporator mounted on rear of the cabinet.
Evaporator coils and temperature control are located on
the interior rear wall of the cabinet. Refrigerant flow
is controlled by a capillary tube. Cabinet maintains an
interior cabinet temperature of 36°F to 40°F (2°C to
4°C).
ACT control. ACT electronic, solid state control,
mounted on the exterior rear of the cabinet, allows
unit to maintain precise temperatures in heavy duty
conditions.
Electrical connections are 115 volt, 60 Hertz, single
phase. Unit has a 7' (2.1m) long electrical cord and
NEMA 5-15P plug.
980 S. Isabella Road Phone: 800-733-8948
Mt. Pleasant, MI 48858 Fax: 800-669-0619
www.delfield.com Email: info@delfield.com
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
Twelve pan capacity
Eighteen pan capacity
OPTIONS AND ACCESSORIES
Flat lift off cover
❑
❑ 18" wide single tier overshelf
Stainless steel finish on back
❑
Plastic laminate on front
❑
Additional wire shelves
❑
Door lock
❑
❑ Exterior thermometer
Interior lights
❑
Glass door(s)
❑
*220V/50 Hertz electrical system
❑
*Inclusion of this option will alter electrical
specifications of the unit.
Casters: Equipment is mounted on 2" (5.08cm)
diameter plate casters with front two locking. Equipment
clearance above the floor is 2.5" (6.35cm).
Doors have a 24-gauge stainless steel exterior, with
thermoformed ABS plastic interior liner. Cabinet has one
adjustable epoxy-coated wire shelf per door opening.
Drawers have 24-gauge stainless steel exterior with
thermoformed ABS plastic interior liner. Drawer frames
are 12-gauge stainless steel. Drawer slides are 11-
gauge stainless steel with stainless steel bearings. Each
top drawer holds two 12" x 20" (30.5cm x 50.8cm)
pans 4"-6" (10.1cm-15.2cm) deep. Each bottom drawer
holds two 12" x 20" (30.5cm x 50.8cm) pans 4"
(10.1cm) deep. Pans are supplied by others.
Approval _________________
Date____________________
