Delfield ST4460N-8 Specifications

ST4460 SALAD TOP
Front-Breathing Self-Contained Compact Salad Top Refrigerators
MODELS:
❑ ST4460N-8 Two section with doors
Eight pan capicity
Model STD4460N-8
SPECIFICATIONS
Exterior top is one-piece 22-gauge stainless steel
with integral 2.12" (5.1cm) square nosing at the front.
Top has openings to accept 8 or 12 1/6-size 4"- 6"
(10.2cm - 15.2cm) deep plastic pans. Adapter bars and
1/6 pans are supplied by Delfield. Temperature in top
opening to maintain 33°F (1°C) to 41°F (5°C), with
pans recessed 2.5" (6.4cm) at 86°F ambient room
temperature, meeting NSF 7 requirements. One 60"
x 10" x .5" (152cm x 25.4cm x 1.3cm) polyethylene
cutting board treated with antimicrobial agent is
mounted on the top at the front edge.
Exterior back and bottom are two-piece 24-gauge
galvanized steel. Exterior ends are stainless steel.
Interior sides are thermoformed ABS plastic with shelf
supports. Base is fully insulated with high-density foamed
in place polyurethane.
❑ STD4460N-8
STANDARD FEATURES
• Patented air screen ensures product stays cold without drying it out
• All 4400 Series units are 100% front breathing, which allows the
unit to be pushed against a wall or built into a cabinet or an existing
line up
• Durable, rugged stainless steel sides, top and front
• Features Delfield's exclusive ABS interior (on sides). ABS is
extremely durable - it won't dent, chip or corrode and is backed by
a limited lifetime warranty
• Delfield supplies 1/6 size pans and adapter bars for top opening
• Salad top refrigerators are standard with 10" wide, dishwasher safe
polyethylene cutting board treated with anitmicrobial agent
• "D" prefix models feature Delfield's new drawer system. Drawers
are backed by a 10-year warranty on the track assembly
• Environmentally friendly R404A refrigerant
• High density foamed in place polyurethane keeps energy costs low
• Black recessed quick grip handle
• Standard on 2" casters for easy cleaning and installation
• 7' cord and plug supplied
• Cord spring relief - prevents cord rollover
• One epoxy coated wire shelf standard, installed per door section
• ACT solid state electronic control
• "ST" models have a 4" stainless steel backsplash
• One year parts and 90 day labor standard warranty.
Refrigeration system uses HFC-404A refrigerant.
Compressor is 1/2 H.P., with condenser coil and condensate
evaporator mounted on rear of the cabinet. Evaporator
coils and temperature control are located on the interior
rear wall of the cabinet. Refrigerant flow is controlled by
a capillary tube. Cabinet maintains an interior cabinet
temperature of 36°F to 40°F (2°C to 4°C).
ACT control. ACT electronic, solid state control,
mounted on the exterior rear of the cabinet, allows
unit to maintain precise temperatures in heavy duty
conditions.
Electrical connections are 115 volt, 60 Hertz, single
phase. Unit has a 7' (2.1m) long electrical cord and NEMA
5-15P plug.
Casters: Equipment is mounted on 2" (5.08cm) diameter
casters, with front three locking. Equipment clearance above
the floor is 2.5" (6.35cm).
980 S. Isabella Road Phone: 800-733-8948
Mt. Pleasant, MI 48858 Fax: 800-669-0619
www.delfield.com Email: info@delfield.com
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
Two section with dawers
Eight pan capacity
OPTIONS AND ACCESSORIES
❑ Flat lift off cover
18" wide single tier overshelf
❑
Stainless steel finish on back
❑
Plastic laminate on front
❑
Additional wire shelves
❑
❑ Door lock
Exterior thermometer
❑
Interior lights
❑
Glass door(s)
❑
*220V/50 Hertz electrical system
❑
*Inclusion of this option will alter electrical
specifications of the unit.
The following applies to two door models only
Doors have a 24-gauge stainless steel exterior, with
thermoformed ABS plastic interior liner. Cabinet has
one adjustable epoxy-coated wire shelf per door
opening.
The following applies to four drawer models only
Drawer fronts have a 24-gauge stainless steel exterior, with
thermoformed ABS plastic interior liner. Drawer frames
are 12-gauge stainless steel. Drawer slides are 11-gauge
stainless steel with Delrin bearings. Each section has
two drawers. Each top drawer holds one full size 12"
x 20" (30.5cm x 50.8cm) pan, three 1/6 size and
three 1/9 size 4"-6" (10.6cm -15.2cm) deep pans.
Each bottom drawer holds one 12" x 20" (30.5cm x
50.8cm) pan, three 1/6 size and three 1/9 size 4"
(10.6cm) deep pans. Pans supplied by others.
Approval _________________
Date____________________
