- Page 1 LTDN40K320UHK LTDN50K320UHK USER MANUAL Before using the TV, Please read this manual thoroughly, retain it for future reference. English ＲＳＡＧ２．０２５．４７６１ＳＳ 条形码定位框，长 ３５ｍｍ，高度请根 据长度等比例缩放。该定位框不做印 刷处理。物料号：...
- Page 2 Ｔｉｐｓ Before using the TV, Please read this manual thoroughly, retain it for future reference. Our company does not assume any liability for any accident arising from violation of the matters of attention and instruction on use in this manual. This product involves high voltage.
- Page 3 If you find abnormal sound or smell, or there is sound but no image, please turn off the TV and pull out the plug immediately and contact the Hisense Service. ・ Please do not press the power line and signal line with other things.
- Page 4 2 Maintenance ・ Do not clean this unit with volatile oils or dilution, which may cause cabinet deterioration or damage its coating surface. ・ If the cabinet becomes dirty, please clean it with a soft cloth which has neutral detergent wet with water. 3 LCD display instruction and maintenance LCD display panel is the advanced S&T product, composed of several millions of Movie transistors inside.
- Page 5 × Unsteady places. × Places suffering from easy vibration. × Places of lot of dust or moist places. × Places of high temperatures. ・ In the case where such substances that are painted with paint or organic solvent and grease, etc. on the surface of the TV cabinet, the chemical reaction may be occurred in between the rubber cushion on the base and such substances hereinbefore, which may cause a slight corrosion on the surface of the TV cabinet.
- Page 6 Install on the wall: Leave enough space around the set. ・ Never install the TV set as follows: Inadequate air circulation can lead to overheating of the TV and may cause damage to your TV or cause fire. Air circulation is blocked. Wall Wall...
-
Page 7: Table Of Contents
Contents Accessories List......................2 Installing the Stand ....................2 Remote Control ......................3 Control Panel ......................4 Terminal Introduction ....................5 Connection Description .................... 6 Using the TV for the First Time ................10 Others ........................11 Specifications ......................13... -
Page 8: Accessories List
Accessories List User Manual Remote Control AAA Battery Warranty Card Power line Ｓｃｒｅｗ Installing the Stand • Carefully place your TV face-up on a soft, flat surface to prevent damage to the TV or scratching to the screen. • Install the base stand with the provided screws in the accessory bag in case of causing damage to TV. -
Page 9: Remote Control
Remote Control Mute button Setting button Start/Exit the mute state Start/stop quick setup menu ＴＶ Ｅｎｔｅｒ Ｌｉｖｅ ＴＶ Standby button Ｍｅｄｉａ Enter standby/exit standby Ｅｎｔｅｒ ＶＯＤ Ｇａｍｅ ＴＶ Ｍｅｄｉａ Ｇａｍｅ Ａｐｐｓ Ｅｎｔｅｒ Ｇａｍｅ Home button Ａｐｐｓ Enter the television's Home Ｅｎｔｅｒ Ａｐｐｓ page Information ▲ ／ ／... -
Page 10: Control Panel
Control Panel Ｐｒｅｓｓ ｔｈｅ ｂｕｔｔｏｎｔｏ ｐｏｐ ｕｐ ｔｈｅ ｍｅｎｕ ｂｕｔｔｏｎ． Home Back Power Source Close Volume Up Settings Remote Volume Down Ｓｉｄｅ ｂｕｔｔｏｎ（４０＂） Ｓｉｄｅ ｂｕｔｔｏｎ（５０＂） Power button Ｎｏｔｅ： Ｔｈｉｓ ｍａｃｈｉｎｅ ｄｏｅｓ ｎｏｔ ｓｕｐｐｏｒｔ ｒｅｔｒｉｅｖｅ ｒｅｍｏｔｅ ｃｏｎｔｒｏｌ ｆｕｎｃｔｉｏｎｓ． remote control receiver window/ remote control receiver window/ Power indicator(50") Power indicator(40") Item Description Power button Turn on or off the TV set. Infrared remote control Receive remote signals from the remote control. -
Page 11: Terminal Introduction
Terminal Introduction ANTENNA Power Input HDMI ＨＤＭＩ HDMI 3 DEBUGGING ＤＥＢＵＧＧＩＮＧ HDMI AV IN COAXIAL VIDEO L AUDIO COMP HEADPHONE COAXIAL COMP/AV IN 【ＮＯＴＥＳ】 • As a result of time consumption of power down of power supply and system processing, please don't switch on and off continuously and fast, otherwise it may cause abnormal working. -
Page 12: Connection Description
The total current should be no more than 1900 mA when all the USB jacks are connected with external devices. Hisense warranty does not cover the TV damages and issues caused by the current overload.(Only USB 3 jack supports USB 3.0 devices) ・Connecting an Ex-Speaker... - Page 13 ・Ｃｏｎｎｅｃｔｉｎｇ ａｎ Ａ／Ｖ Ｄｅｖｉｃｅ With the HDMI Cable Ｓｅｔ－ｔｏｐ ｂｏｘ／Ｐｌａｙｅｒ／Ｃｏｍｐｕｔｅｒ／ＤＶＤ ＨＤＭＩ HDMI: HDMI is also called as high-definition multi-media port. As the latest generation of port, the digit audio signal and video signal can be transmitted with a cable without compressed. • HDMI supports multi-channel digital audio, HDMI port can be connected to external devices, such as: set-top boxes, players, computers with HDMI output and so on.
- Page 14 With the Component Cable AV IN VIDEO L AUDIO COMP （Ｗｈｉｔｅ） Ａｕｄｉｏ Ｌ （Ｒｅｄ） Ｖｉｄｅｏ Ｃａｍａｒａ／ＶＣＲ／Ｓｅｔ－ｔｏｐ ｂｏｘ／ Ａｕｄｉｏ Ｒ Ｓａｔｅｌｌｉｔｅ Ｒｅｃｅｉｖｅｒ／ＤＶＤ／ＶＣＤ Ｐ （Ｒｅｄ） Ｒ Ｐ （Ｂｌｕｅ） Ｂ Ｙ （Ｇｒｅｅｎ） ・ Connect the TV's COMPONENT jack to component video output jack (Y, PB, PR) of the external A/V devices (VCD, DVD, VCR or Camcorder). ・...
- Page 15 Connecting a network ・ LAN: It can be connected to the network cable for Internet access. Enter the setup menu, select Settings→System Settings→Network Settings, click into Network Settings menu. The wireless network connection Ｗｉｒｅｌｅｓｓ ｒｏｕｔｅｒ ＬＡＮ Ｎｅｔｗｏｒｋ ｊａｃｋ ｉｎ ｔｈｅ ｗａｌｌ The TV can directly receive network signals via wireless router. Select in the Network...
-
Page 16: Using The Tv For The First Time
Using the TV for the First Time Turning the TV On or Off Use an AC cord to connect the TV's Power input jack to 220V AC outlet. ・ Press the Power button on the TV set. When the TV is on, press the Standby ・... -
Page 17: Others
Others Trouble Shooting When there is something wrong with your TV, you can try turning off the TV and then restart it. You can also operate according to the following chart. If the problem still cannot be solved, please contact the professional technicians. Symptoms Possible Solutions ·... - Page 18 2 Instructions Ｔｈｅ ｔｅｒｍｓ ＨＤＭＩ ａｎｄ ＨＤＭＩ Ｈｉｇｈ－Ｄｅｆｉｎｉｔｉｏｎ Ｍｕｌｔｉｍｅｄｉａ Ｉｎｔｅｒｆａｃｅ， ａｎｄ ｔｈｅ ＨＤＭＩ Ｌｏｇｏ ａｒｅ ｔｒａｄｅｍａｒｋｓ ｏｒ ｒｅｇｉｓｔｅｒｅｄ ｔｒａｄｅｍａｒｋｓ ｏｆ ＨＤＭＩ Ｌｉｃｅｎｓｉｎｇ ＬＬＣ ｉｎ ｔｈｅ Ｕｎｉｔｅｄ Ｓｔａｔｅｓ ａｎｄ ｏｔｈｅｒ ｃｏｕｎｔｒｉｅｓ． Ｄｏｌｂｙ， Ｄｏｌｂｙ Ａｕｄｉｏ， ａｎｄ ｔｈｅ ｄｏｕｂｌｅ－Ｄ ｓｙｍｂｏｌ ａｒｅ ｔｒａｄｅｍａｒｋｓ ｏｆ Ｄｏｌｂｙ Ｌａｂｏｒａｔｏｒｉｅｓ． Ｍａｎｕｆａｃｔｕｒｅｄ ｕｎｄｅｒ ｌｉｃｅｎｓｅ ｕｎｄｅｒ Ｕ．Ｓ． Ｐａｔｅｎｔ＃＇ｓ： ５，４５１，９４２； ５，９５６，６７４； ５，９７４，３８０； ５，９７８，７６２； ６，４８７，５３５ ＆ ｏｔｈｅｒ Ｕ．Ｓ． ａｎｄ ｗｏｒｌｄｗｉｄｅ ｐａｔｅｎｔｓ ｉｓｓｕｅｄ ＆ ｐｅｎｄｉｎｇ． ＤＴＳ ａｎｄ ｔｈｅ Ｓｙｍｂｏｌ ａｒｅ ｒｅｇｉｓｔｅｒｅｄ ｔｒａｄｅｍａｒｋｓ， ＆ ＤＴＳ ２．０＋ Ｄｉｇｉｔａｌ Ｏｕｔ ａｎｄ ｔｈｅ ＤＴＳ ｌｏｇｏｓ ａｒｅ ｔｒａｄｅｍａｒｋｓ ｏｆ ＤＴＳ， Ｉｎｃ． Ｐｒｏｄｕｃｔ ｉｎｃｌｕｄｅｓ ｓｏｆｔｗａｒｅ． ＤＴＳ， Ｉｎｃ． Ａｌｌ Ｒｉｇｈｔｓ Ｒｅｓｅｒｖｅｄ． 【ＳＴＡＴＥＭＥＮＴＳ】 ・ The pictures and instructions in the user manual are only for reference, and may be different from appearance of actual products. Please make the object as the standard.
-
Page 19: Specifications
Ｓｐｅｃｉｆｉｃａｔｉｏｎｓ ＭＯＤＥＬ ＬＴＤＮ４０Ｋ３２０ＵＨＫ ＬＴＤＮ５０Ｋ３２０ＵＨＫ Without stand ９０２×５１５×８６ １１２４×６４９×８２ Dimension (WxHxD)(mm) With stand ９０２×５６０×１９２ １１２４×７０２×２４７ Without stand ８．７ １３．５ Weight(kg) With stand ８．９ １３．８ Active screen diagonal size (cm) １０２ １２６ Screen resolution ３８４０×２１６０ ３８４０×２１６０ Power consumption ８５Ｗ １４０Ｗ Audio power ７Ｗ＋７Ｗ... - Page 20 Below is the list of video format compatible: Video decoding Formats Audio decoding Ｆｒａｍｅ Resolution Bit rate Type ｒａｔｅ (max) (max) （max） ＡＣ３， ．ａｖｉ Ｘｖｉｄ １２８０×７２０ ４０Ｍｂｐｓ ３０ｆｐｓ ＭＰＥＧ１（Ｌａｙｅｒ１，２，３） ．ａｖｉ ．ｍｐｇ ＡＣ３， ＭＰＥＧ２ １９２０×１０８０ ４０Ｍｂｐｓ ３０ｆｐｓ ．ｔｓ ＭＰＥＧ１（Ｌａｙｅｒ１，２，３） ．ｔｓ ．ｍｋｖ ＡＣ３， ＡＡＣ， ．ａｖｉ ．ｍｐ４ ...
